Fighter Aircraft Maintenance Volume 4. A-10/u-2/uav (rq-1)

100 Questions

Settings
Please wait...
Aircraft Maintenance Quizzes & Trivia

Aircraft maintenance Journeyman CDC.


Questions and Answers
  • 1.
    The A-10 Fuselage components the redistribute loads around cutouts and provide redundant load paths are
    • A.

      Stingers

    • B.

      Spars

    • C.

      Auxillary longerons

    • D.

      Ribs

  • 2.
    To prevent potential tank explosion during combat, the Z-10's integral fuel tanks are filled with
    • A.

      Rubber

    • B.

      Ballistic foam

    • C.

      Polyurethane foam

    • D.

      Composite materials

  • 3.
    The danger associated with a functioning lift transducer on the A-10 is
    • A.

      Radiation

    • B.

      Extreme heat

    • C.

      Electrical shock

    • D.

      Sudden movement

  • 4.
    After engine shutdown, A-10 engine exhaust areas are considered hazardous for
    • A.

      10 minutes

    • B.

      15 minutes

    • C.

      20 minutes

    • D.

      25 minutes

  • 5.
    The A10 main landing gear strut component that transmits torque loads from the wheel to the strut cylinder is the
    • A.

      Trunnion

    • B.

      Shock strut

    • C.

      Torque arms

    • D.

      Piston assembly

  • 6.
    On the A-10, the main landing gear uplock cylinder hydraulically releases the uplock
    • A.

      Hooks

    • B.

      Rollers

    • C.

      Switch

    • D.

      Mechanism

  • 7.
    The number of fusible plugs incorporated in each A-10 main landing gear wheel is
    • A.

      Two

    • B.

      Three

    • C.

      Four

    • D.

      Five

  • 8.
    The A-10 nose wheel steering is initiated in the commanded direction by the movement of the rudder pedals in conjunction with a steering command signal generated by the
    • A.

      Steering switch

    • B.

      Steering collar assembly

    • C.

      Position transducer potentiometer

    • D.

      Steering unit

  • 9.
    If electrical power is lost, the operable A-10 nose wheel steering mode is
    • A.

      Steering

    • B.

      Fail-safe

    • C.

      Auxiliary

    • D.

      Damper-caster

  • 10.
    The brake system of the A-10 consist of a normal, an emergency, and an
    • A.

      Electronic stability system

    • B.

      All-weather system

    • C.

      All-terrain system

    • D.

      Anti-skid systerm

  • 11.
    Should the left and right hydraulic systems fail, emergency braking power for the A-10 is provided by
    • A.

      The dual power brake valve

    • B.

      The auxiliary power unit

    • C.

      The cable assembly

    • D.

      An accumulator

  • 12.
    The A-10 anti-skid caution light on the A-10 comes on when the system
    • A.

      Is engaged

    • B.

      Is disengaged

    • C.

      Has a malfunction

    • D.

      Engages the brakes

  • 13.
    On the A-10, hydraulic pressure from the left system is directed to the nose drag strut actuators by
    • A.

      Uplock cylinder

    • B.

      Landing gear control valve

    • C.

      Weight-on-wheels switch

    • D.

      Downlock override

  • 14.
    During auxiliary landing gear extension on the A-10, the left hydraulic system reservoir bootstrap pressure is ported
    • A.

      Overboard

    • B.

      To the return

    • C.

      To the accumulator

    • D.

      To the uplock cylinders

  • 15.
    The position the A-10 feel and trim devices provide the stick to represent any trim set into the elevator actuator is
    • A.

      Aft load

    • B.

      Lateral load

    • C.

      Positive load

    • D.

      Neutral (zero load)

  • 16.
    The components of the A-110 pitch and roll flight control systems that free the control stick from a control path jam are the pitch and roll
    • A.

      Tab shifters

    • B.

      Trim actuators

    • C.

      Disconnectors

    • D.

      Geared servo tabs

  • 17.
    The actuator type A-10 speed brakes use is
    • A.

      Dual-acting pistons

    • B.

      Unbalanced pistons

    • C.

      Balanced pistons

    • D.

      Tandem pistons

  • 18.
    The number of hydraulic power supply systems on the A-10 is
    • A.

      One

    • B.

      Two

    • C.

      Three

    • D.

      Four

  • 19.
    The two components that make up the A-10 hydraulic power supply package are the bootstrap hydraulic
    • A.

      Reservoir and balanced relief valve

    • B.

      Accumulator and balanced relief valve

    • C.

      Reservoir and supply module

    • D.

      Accumulator and supply module

  • 20.
    The A-10 hydraulic system component that allows fluid to pass to and charge the accumulator is the
    • A.

      Hydraulic pressure switch

    • B.

      Balanced relief valve

    • C.

      Fill rate restrictor

    • D.

      Supply module

  • 21.
    When hydraulic pressure is not being supplied by the auxiliary power unit (APU), small amounts of hydraulic fluid are directed the APU-driven hydraulic pump from the
    • A.

      Left hydraulic reservoir

    • B.

      Right hydraulic reservoir

    • C.

      Left engine hydraulic pump

    • D.

      Right engine hydraulic pump

  • 22.
    You reset the A-10hydraulic filter differential pressure (ΔP) indicator after it has actuated by
    • A.

      Pushing the ΔP indicator in

    • B.

      Removing the filter bowl, inverting it, and depressing the button

    • C.

      Removing the filter bowl, and then resetting the button

    • D.

      Changing out the filter bowl assembly

  • 23.
    The percentage of engine thrust the A-10's TF34-GE-100A engine fan bypass stream accounts for is
    • A.

      75

    • B.

      80

    • C.

      85

    • D.

      90

  • 24.
    The number of ignigors installed on the combustor of the A-10's TF34-GE-100A engine is
    • A.

      One

    • B.

      Two

    • C.

      Three

    • D.

      Four

  • 25.
    Continuous oil flow is supplied to the number three bearing if the A-10's TF34-GE-100A engine during zero- or negative-G maneuvers by the
    • A.

      Scavenge pump

    • B.

      Auxiliary lubrication system

    • C.

      B-sump

    • D.

      C-sump

  • 26.
    On the A-10's fire extinguishing system, the fire extinguishing discharge switch is a
    • A.

      Two-position, single-throw, center-off toggle switch

    • B.

      Two-position, double-throw, center-off toggle switch

    • C.

      Three-position, single-throw, center-on toggle switch

    • D.

      Three-position, double-throw, center-off toggle switch

  • 27.
    The A-10's fire extinguisher container fired when the extinguisher discharge switch is placed to the right is the
    • A.

      Auxiliary power unit

    • B.

      Foward and aft

    • C.

      Forward

    • D.

      Aft

  • 28.
    The A-10's external tank fuel feed system component that prevents the external tank from collapsing when the air pressure within the tank is less than the ambient pressure is the
    • A.

      Pylon pressure air line

    • B.

      Fuel vent pressure tank

    • C.

      Fuel vent pressure tube

    • D.

      Negative pressure relief valve

  • 29.
    The interface between the A-10's external fuel tanks and pylon-refueling manifold is provided by the
    • A.

      Boost pumps

    • B.

      Fuel system test box

    • C.

      Fuel control pannel

    • D.

      Fuel disconnects

  • 30.
    The A-10's fuel system component that diffuses the fuel spray to reduce static buildup caused by the fuel pouring into the fuel tanks during refueling is the
    • A.

      Pitot tube

    • B.

      Vent tube

    • C.

      Drain tube

    • D.

      Piccolo tube

  • 31.
    The component that allows verification of the operational status of the A-10's refueling system is the
    • A.

      Pilot valves

    • B.

      Refueling manifold

    • C.

      Fuel management panel

    • D.

      Test box asembly

  • 32.
    The A-10 can be refueled in flight by a tanker aircraft equipped with a
    • A.

      Static boom

    • B.

      Flying boom

    • C.

      Refueling basket

    • D.

      Refueling drogue

  • 33.
    The A-10's integrated drive generator oil supply circuit component that attracts ferrous metals particles is the
    • A.

      Filter

    • B.

      Air oil cooler

    • C.

      Pressure fill port

    • D.

      Magnetic chip detector

  • 34.
    The external power monitor on the A-10 measures the frequency, voltage sequence, and phase sequence of external AC power applied to the aircraft and
    • A.

      Converts the voltage to that of the aircraft

    • B.

      Sends the power to the generator control unit

    • C.

      Makes the power compatible with the aircraft DC system

    • D.

      Determines whether the power is compatible with the aircraft electrical system

  • 35.
    The A-10's DC electrical system component that is an air-cooled transformer-rectifier is the
    • A.

      Inverter

    • B.

      Converter

    • C.

      Integrated drive generator

    • D.

      DC motor-driven AC generator

  • 36.
    The A-10's emergency power system consists of a battery and a(n)
    • A.

      Directional control unit

    • B.

      Inverter

    • C.

      Generator control unit

    • D.

      Converter

  • 37.
    The two exterior lights mounted as an assembly on the wingtips of the A-10 are the
    • A.

      Anti-collision and position

    • B.

      Nose floodlights and formatoin

    • C.

      Formation and position

    • D.

      Anti-collision and nose floodlights

  • 38.
    The nose illumination lights on the A-10 are used for
    • A.

      In-flight refueling

    • B.

      Tower identification

    • C.

      In-flight visual checks

    • D.

      Crew chief identifcation

  • 39.
    The oxygen regulator supply lever on the A-10 is
    • A.

      Red

    • B.

      Blue

    • C.

      Green

    • D.

      White

  • 40.
    During inhalation,the A-10's oxygen regulator flow indicator should show
    • A.

      White

    • B.

      Black

    • C.

      Red

    • D.

      Green

  • 41.
    The four mount pads on the U-2 center section, aside from being attach points for the RG130 ground handling cart, are used for aircraft
    • A.

      Jacking

    • B.

      Towing

    • C.

      Hoisting

    • D.

      Tie down

  • 42.
    The aft portion of the U-2 canopy is coated with four coats of paint to
    • A.

      Provide shade and prevent night blindness

    • B.

      Provide insulation from low temperatures

    • C.

      Combat solar radiation and glare

    • D.

      Reduce solar heat signature

  • 43.
    To signal that the emergency start system has been activated in flight, the pilot of a U-2
    • A.

      Turns on the anti-collision lights

    • B.

      Turns on the main landing gear lights

    • C.

      Leaves the speed brakes open

    • D.

      Shuts the aircraft down at the end of the runway

  • 44.
    The automated weight and balance program used on the U-2 is maintained by
    • A.

      The crew chief

    • B.

      Quality assureance

    • C.

      Factory representives

    • D.

      The Senior Year program officer

  • 45.
    All items, not part of the basic weight, installed on the U-2 aircraft are recorded on the
    • A.

      AFTO Form 781A, Maintenance Discrepancy and Work Document

    • B.

      AFTO Form 781C, Avionics Configuration and Load Status Document

    • C.

      WR-ALC/LR Form 52, Automated Weight and Balance Form

    • D.

      LR Form 52, Manual Weight and Balance Form

  • 46.
    The U-2 aircraft's automated weight and balance programs daily data is gathered form the AFTO Form
    • A.

      781A

    • B.

      781C

    • C.

      781H

    • D.

      781J

  • 47.
    The main landing gear strut on the U-2 is constructed of
    • A.

      Aluminum alloy

    • B.

      Stainless steel

    • C.

      Composites

    • D.

      Titanium

  • 48.
    The auxiliary landing gear on the U-2 are called
    • A.

      Wing skids

    • B.

      Outriggers

    • C.

      Pagos

    • D.

      Outboard gear

  • 49.
    If total hydraulic failure occurs on the U-2, the number of full brake applications the emergency brake accumulator supplies hydraulic pressure for is
    • A.

      Three

    • B.

      Five

    • C.

      Seven

    • D.

      Nine

  • 50.
    During normal landing gear extension on the U-2, the main landing gear actuator pressure buildup is delayed until the uplock acuator has unlocked the gear by a(n)
    • A.

      Check valve

    • B.

      Orifice valve

    • C.

      Control valve

    • D.

      Selector valve

  • 51.
    The U-2 ailerons are adjusted the neutral position by a
    • A.

      Linear actuator connected the the left aileron tab

    • B.

      Trim motor attached to the left aileron

    • C.

      Trim motor attached to the rifht aileron

    • D.

      Linear actuator connected to the right aileron tab

  • 52.
    On the U-2, you set the aileron trim tabs to neutral if they are slightly warped by
    • A.

      Bending the tabe until it is straight

    • B.

      Installing a jig to realign the wing

    • C.

      Replacing the tab and rig the roll control system

    • D.

      Aligning the tabs as close to the middle as possible

  • 53.
    The U-2 flight control system that reduced the wing and empennage structural loading during high speed or rough air operation by shifting both aileron wing surfaces and wing flaps upward is the
    • A.

      Stability augmentation

    • B.

      Gust control

    • C.

      Pitch trim

    • D.

      Roll trim

  • 54.
    The wing flaps on the U-2 are controlled
    • A.

      Electrically

    • B.

      Hydraulically

    • C.

      Mechanically

    • D.

      Pneumatically

  • 55.
    The U-2 aircraft lift spoilers are used to assist in landing and
    • A.

      Reduced speed

    • B.

      Increased speed

    • C.

      Ascent to altitude

    • D.

      Descent from altitude

  • 56.
    On the U-2, the speed brakes are located on
    • A.

      Each side of the aft fuselage

    • B.

      The bottom of each wing

    • C.

      Top of the center fuselage

    • D.

      Top of each wing

  • 57.
    Except during system maintenance, the U-2 hydraulic reservoir should remain pressuirzed to
    • A.

      Ensure the system seals do not dry out between flights

    • B.

      Reduce the time required to prepared the aircraft for a mission

    • C.

      Reduce the wear on the pressurization system during engine start

    • D.

      Eliminate the possibility of air and contaminants entering the system

  • 58.
    The U-2 hydraulic pump is allowed to vary the volume of fluid delivered to compensate for changes in demand by a(n)
    • A.

      Increase or decrease in engine revolutions per minute

    • B.

      Change in the angle between the pressure compensator and actuating cylinder

    • C.

      Increase or decrease in the aircraft mounted accessory drive

    • D.

      Change in the angle between the yoke and pump shaft axis

  • 59.
    The hydraulic tubing for the U-2 horizontal stabilizer trim is color-coded to
    • A.

      Show it is a flight control line

    • B.

      Identify the type of tubing used

    • C.

      Show the tubing is not twisted or spliced

    • D.

      Prevent cross-connection of lines during maintenance

  • 60.
    The allowable leakage for static seals on the U-2 is
    • A.

      None

    • B.

      A few drops overnight

    • C.

      Two drops per minute when pressurized

    • D.

      Two drops per minute when not pressurized

  • 61.
    The acceptable leakage for the flap dynamic seals on the U-2 is
    • A.

      None

    • B.

      A few drops overnight

    • C.

      Two drops per minute when pressurized

    • D.

      Two drops per minute when not pressurized

  • 62.
    The U-2 exhaust system consists of the tail pipe and
    • A.

      Accessory gear box

    • B.

      Main engine control

    • C.

      Low pressure turbine

    • D.

      Fan flow adapter diverter

  • 63.
    The three operating modes of the U-2 aircraft mounted accessory drive are
    • A.

      Overdrive, straight drive, and subsystem checkout

    • B.

      Engine-starting, accessory drive, and subsystem checkout

    • C.

      Engine-starting, accessory drive, and underdrive

    • D.

      Overdrive, underdrive, and straight drive

  • 64.
    The U-2 cockpit indicator that provides an indication of high-pressure compressor rotor operation is the
    • A.

      N1 RPM

    • B.

      N2 RPM

    • C.

      Fan discharge sensor

    • D.

      Engine pressure ratio

  • 65.
    When refueling the U-2, the fuel tank filled first is the
    • A.

      Left outboard wing

    • B.

      Left inboard wing

    • C.

      Fuselage sump

    • D.

      External

  • 66.
    The U-2's sump tank manifolds are checked for moisture during which inspection?
    • A.

      Baisc post flight

    • B.

      Thru-flight

    • C.

      Pre-flight

    • D.

      Periodic

  • 67.
    The light that illuminates on the U-2 aircraft when the fuel sump reads 38 (±3) gallons remaining is the
    • A.

      FUEL TRANSFER

    • B.

      FUEL UNEQUAL

    • C.

      FUEL LEVEL LOW

    • D.

      FUEL IMBALANCE

  • 68.
    A momentary hammering sound when the U-2 fuel transfer valves are actuated is caused by
    • A.

      A malfunctioning valve

    • B.

      High fuel pressure

    • C.

      Air in the system

    • D.

      Low fuel level

  • 69.
    The external DC power required to power the monitored AC bus contactor coil on the U-2 is provided through
    • A.

      Pin E of the external AC power receptacle

    • B.

      The transformer-rectifier

    • C.

      A 28-VDC external power cable

    • D.

      The A, B, and C pins of the external power receptacle

  • 70.
    The U-2 DC generator is cooled by
    • A.

      Engine bleed air through the aircraft mounted accessory drive

    • B.

      Engine bleed air through the colling turbine

    • C.

      Ram air through the left engine air inlet

    • D.

      Ram air through the right air inlet

  • 71.
    The U-2 exterior lights consist of landing, anti-collision and
    • A.

      Strip lights

    • B.

      Parking lights

    • C.

      Formation lights

    • D.

      Navigation lights

  • 72.
    The navigation lights on the U-2 consist of a
    • A.

      Red light on the left wingtip, a green light on the right wingtip, and two clear lights on the upper vertical stabilizer

    • B.

      Green light on the left wingtip, a red light on the right wingtip, and a clear light on the upper vertical stabilizer

    • C.

      Red light on the left wingtip, a green light on the right wingtip, and a clear light on the upper vertical stabilizer

    • D.

      Green light on the left wingtip, a green light on the right wingtip, and two amber lights on the upper vertical stabilizer

  • 73.
    It is critically important on the U-2 that you check the turbine bypass switch to prevent
    • A.

      Valve wear

    • B.

      Battery drain

    • C.

      Compartment fire

    • D.

      Indicator light failure

  • 74.
    The number of liquid oxygen converters on the U-2 is
    • A.

      One

    • B.

      Two

    • C.

      Three

    • D.

      Four

  • 75.
    The U-2 technical manual section that provides you with a description of the aircraft, aircraft stations, access provisions, and drain and vent points is
    • A.

      System

    • B.

      General information

    • C.

      Master drawing index

    • D.

      Explanation of contents

  • 76.
    The headings of the U-2 troubleshooting tables are
    • A.

      ROOT CAUSE, INDICATED PROBLEM, AND SOLUTIONS

    • B.

      ROOT CAUSE, ISOLATION PROCEDURE, AND SOLUTION

    • C.

      PROBABLE CAUSE, ISOLATION OF MALFUNCTION, AND REMEDY

    • D.

      PROBABLE CAUSE, ISOLOATION PROCEDURE, AND REMEDY

  • 77.
    Peculiar maintenance procedures exist for the U-2 because of the
    • A.

      Need to maintain its lightweight characteristics

    • B.

      Standard reconnaissance design philosophy

    • C.

      Special purpose of the aircraft

    • D.

      Its flight characteristics

  • 78.
    The reference that lists suitable substitutes for U-2 aircraft is the
    • A.

      SP 1977, Engineering Standards Procurement Manual

    • B.

      Consolidated Aircraft Maintenance System database listing

    • C.

      Spare parts and Application Data List

    • D.

      Engineering Master Drawing Index

  • 79.
    The compression ratio of the RQ-1's Rotax 914F engine is
    • A.

      4.0:1

    • B.

      6.0:1

    • C.

      8.0:1

    • D.

      9.0:1

  • 80.
    The purpose of valve lead and valve lag in the valve mechanism used on the RQ-1's reciprocating engine is to
    • A.

      Decrease head pressure and slow the rate of incoming intake air into the cylinder

    • B.

      Increase the volumetric efficiency and lower the temperature of the cylinder

    • C.

      Increase the volumetric efficiency and lower cylinder head compression

    • D.

      Decrease head pressure and prevent valve contact with the pistons

  • 81.
    What type carburetors are installed on the RQ-1's engine?
    • A.

      16-millimeter, variable depression, cross-draft butterfly valve

    • B.

      32-millimeter, constant depression, cross-draft butterfly valve

    • C.

      32-millimeter, variable depression, venturi-free, in-line sliding gate valve

    • D.

      101-millimeter, variable depression, venturi-free, in-line sliding gate valve

  • 82.
    On RQ-1's engine, oil is forced out of the sump in the crankcase and back to the oil reservoir by
    • A.

      Blow-by gases

    • B.

      A camshaft-driven pump mounted in crankcase

    • C.

      An electrically operated pump mounted in crankcase

    • D.

      An electrically operated suction pump mounted inside the reservoir

  • 83.
    Ignition power for the spark plugs on the RQ-1's engine is provided by a
    • A.

      Dual breaker-less capacitive discharge ignition system

    • B.

      Dual breaker-type constant discharge ignition system

    • C.

      Single breaker-type constant discharge ignition system

    • D.

      Single breaker-less capacitive discharge ignition sysem

  • 84.
    Which spark plugs are driven by power box 1 in the RQ-1's engine ignition system?
    • A.

      Top spark plugs in all cylinders

    • B.

      Bottom spark plugs in all cylinders

    • C.

      All spark plugs in the left bank of cylinders

    • D.

      Top spark plugs in cylinders 1 and 2, and the bottom spark plugs in cylinders 3 and 4

  • 85.
    To disable ignition power box 1 when performing a test of ignition power box 2 in the RQ-1's ignition test circuit, ignition test relay
    • A.

      1 must be de-energized

    • B.

      2 must be de-energized

    • C.

      1 must be energized

    • D.

      2 must be energized

  • 86.
    What type of mechanism is incorporated on the RQ-1's variable pitch propeller assembly to facilitate or perform pitch movement of the propeller blades?
    • A.

      Rack and pinion

    • B.

      Ring gear and drive gear

    • C.

      Ring gear and splined shaft

    • D.

      Gear and chain

  • 87.
    The RQ-1 is equipped with
    • A.

      Disc brakes actuated by electrical servos

    • B.

      Disc brakes actuated by pneumatic pressure

    • C.

      Drum-and-shoe brakes actuated by electrical servos

    • D.

      Mutiple disc brakes actuated by hydraulic pressure

  • 88.
    On the RQ-1, what is the range in degrees that the nose wheel steering operates from either side of center?
    • A.

      5

    • B.

      8

    • C.

      15

    • D.

      45

  • 89.
    Under normal conditions, the RQ-1's gear-retract servos stop driving the landing gear
    • A.

      After the gear has fully retracted, regardless of the amount of swing time required

    • B.

      After a stop-detect signal is received or after driving for the maximum expected swing time

    • C.

      Four minutes after the maximum expected swing time

    • D.

      Three minutes after the minimum expected swing time

  • 90.
    The purpose of decambering the ailerons and flaps on the RQ-1 is to
    • A.

      Provide additional lift and increase takeoff speed

    • B.

      Provide improved high-speed flight characteristics

    • C.

      Provide improved low-speed flight characteristics and increase lift

    • D.

      Increase ptiching moment of the wing and decrease the amount of elevator movement required during flight

  • 91.
    The component that algebraically adds simultaneous pitch and yaw commands to determine the required tail positions on the RQ-1 is the
    • A.

      Secondary control module

    • B.

      Primary control module

    • C.

      Network junction board

    • D.

      Air data terminal

  • 92.
    What type fuel tanks are used on the RQ-1?
    • A.

      Conformal

    • B.

      Rubberized fuel bladders mounted in the fuselage

    • C.

      External fuselage tanks

    • D.

      Integral wing tanks

  • 93.
    The fuel level sensors used in the RQ-1's fuel system are
    • A.

      Mechanical type with a single-level float and diaphragm

    • B.

      Mechanical type with a dual-level float and diaphragm

    • C.

      Capacitance-type probes provided a 12-VDC reference voltage from the SCM

    • D.

      Capacitance-type probes provided an 18-VAC reference voltage from the secondary control module (SCM)

  • 94.
    When the RQ-1's fuel system is in the normal operating mode, what are proper positions for the valves on the main and return fuel trays?
    • A.

      Aft tank valve open on main fuel tray; forward tank valve open on return fuel tray

    • B.

      Aft tank valve open on main fuel tray; aft tank valve open on return fuel tray

    • C.

      Forward tank valve open on main fuel tray; aft tank valve open on return fuel tray

    • D.

      Forward and aft tank valves open on main fuel tray; forward and aft tank valves closed on return fuel tray

  • 95.
    What is the approximate front tank to back tank fuel ratio on the RQ-1?
    • A.

      1:1

    • B.

      1:2

    • C.

      2:3

    • D.

      3:2

  • 96.
    At what engine speed (in revolutions per minute [RPM]) does the starter/alternator automatically start acting as an alternator on the RQ-1?
    • A.

      550

    • B.

      1,150

    • C.

      1,600

    • D.

      2,200

  • 97.
    If the alternator on the RQ-1 fails, backup power is provided by
    • A.

      Two lead-acid batteries

    • B.

      Two dry-cell nickel-cadmium batteries

    • C.

      An air turbine generator powered by ram air

    • D.

      Two silver-zinc, rechargeable, alkaline-type batteries

  • 98.
    On the RQ-1, the payload power distribution module is used to power the
    • A.

      Ignition test relays

    • B.

      Engine bay cooling fan

    • C.

      Fuel system pumps and relays

    • D.

      Primary control module and the components in the forward fuselage

  • 99.
    The feature on the RQ-1 which, through the primary control module, automatically switches the aircraft lights on is the
    • A.

      Proximity Detector

    • B.

      Airfield Approach

    • C.

      LIghts-Off Range

    • D.

      Collision Avoidance

  • 100.
    The ice detector probe on the RQ-1 detects ice
    • A.

      Through temperature calculations

    • B.

      Through a change in its resonant frequency

    • C.

      By calculating probe deflection caused by the excess mass of ice

    • D.

      By calculating the electrical resistance of the super-cooled probe surface
