1. What is the most widely used semiconductor material?

Explanation

Silicon is the most widely used semiconductor material due to its abundance, affordability, and excellent electrical properties. It is a fundamental component of almost all modern electronic devices, including microchips, transistors, and solar cells. Silicon's ability to efficiently conduct electricity and its compatibility with existing manufacturing processes have made it the preferred choice for the semiconductor industry. Germanium and GaAs are also used in specific applications, but silicon dominates the market due to its superior overall performance and cost-effectiveness. Boron, on the other hand, is not commonly used as a semiconductor material.

Submit
Please wait...
About This Quiz
Electronics Quizzes & Trivia

The SEMICON quiz assesses knowledge on semiconductor basics, including types of materials, atomic structure, and electrical properties. It's designed for learners interested in electronics and material science, enhancing understanding of fundamental concepts in semiconductor technology.

2. What do you call impurites with five valence electrons?

Explanation

Pentavalent refers to impurities with five valence electrons. In chemistry, valence electrons are the outermost electrons in an atom that participate in chemical bonding. Pentavalent impurities have five electrons in their outermost shell, allowing them to form bonds with other atoms by sharing or transferring electrons. This term is commonly used to describe elements or compounds that exhibit this valence state, indicating their ability to form five bonds in chemical reactions.

Submit
3. According to the classical ______, the atom is viewed as having a planetary-type structure with electrons orbiting at various distances around the central nucleus.

Explanation

The correct answer is the Bohr model. The Bohr model is a representation of the atom that suggests electrons orbit the nucleus in specific energy levels or shells. This model was proposed by Niels Bohr in 1913 and is based on the principles of quantum mechanics. It was an important development in understanding atomic structure and helped explain the stability of atoms and the emission and absorption of light.

Submit
4. What is the smallest particle that retains the characteristics of its element?

Explanation

An atom is the smallest particle that retains the characteristics of its element. Atoms are composed of protons, neutrons, and electrons. Protons have a positive charge, neutrons have no charge, and electrons have a negative charge. The number of protons in an atom determines its atomic number and defines the element. The arrangement and number of electrons in an atom determine its chemical properties. Therefore, atoms are the fundamental building blocks of matter and retain the unique characteristics of their respective elements.

Submit
5. What is the basic particle of negative electrical charge?

Explanation

The basic particle of negative electrical charge is the electron. Electrons are subatomic particles that orbit around the nucleus of an atom. They carry a negative charge and are responsible for the flow of electricity. Protons carry a positive charge, neutrons are neutral, and ions can carry either a positive or negative charge depending on the number of electrons they have gained or lost.

Submit
6. WHat type of material have very few free electrons and do not conduct current at all?

Explanation

Insulators are materials that have very few free electrons and do not conduct current at all. Unlike conductors, which have a high number of free electrons that can easily move and carry electric charge, insulators have tightly bound electrons that are not able to move freely. This lack of free electrons makes it difficult for electric current to flow through insulators, resulting in their non-conductive properties. Semiconductors, conductors, and crystals, on the other hand, have varying degrees of electron mobility and conductivity.

Submit
7. What type of materials has very large number of free electrons and conducts current very well?

Explanation

Conductors are materials that have a very large number of free electrons and conduct current very well. These materials have electrons that are loosely bound to their atoms, allowing them to move freely and carry electric charge. This high number of free electrons enables conductors to easily conduct electricity, making them ideal for applications such as electrical wiring and circuitry.

Submit
8. Which one is electrically neutral?

Explanation

A neutron is electrically neutral because it has no charge. Unlike electrons, which have a negative charge, and protons, which have a positive charge, neutrons have a neutral charge. This means that the number of positively charged protons in an atom is balanced by the number of negatively charged electrons, with neutrons adding no additional charge. Therefore, a neutron does not contribute to the overall electrical charge of an atom or molecule, making it electrically neutral.

Submit
9. An electron in the outermost shell of an atom is called

Explanation

Valence electrons are the electrons present in the outermost shell of an atom. These electrons are involved in the formation of chemical bonds and determine the reactivity and chemical properties of an element. They are responsible for the atom's ability to gain, lose, or share electrons with other atoms, thus forming compounds. Valence electrons play a crucial role in understanding the behavior of elements in chemical reactions and their ability to form stable compounds.

Submit
10. A semiconductor is an element with a valence of

Explanation

A semiconductor is an element with a valence of four because it has four valence electrons in its outermost energy level. These valence electrons can participate in bonding with other atoms, allowing the semiconductor to form covalent bonds. This property is important in semiconductors as it enables them to conduct electricity under certain conditions, making them useful in electronic devices such as transistors and diodes.

Submit
11. What is the process of adding pentavalent or trivalent impurities to semiconductors?

Explanation

Doping is the process of intentionally adding impurities, such as pentavalent or trivalent elements, to semiconductors. This is done to modify the electrical properties of the semiconductor material, such as its conductivity. The added impurities introduce extra electrons or holes into the semiconductor lattice, which can increase or decrease its conductivity, depending on the type of impurity added. Doping is a crucial technique in semiconductor manufacturing, as it allows for the creation of different types of semiconductor devices with specific electrical characteristics.

Submit
12. There is current through the pn junction only when it is ____________.

Explanation

When a pn junction is forward-biased, the positive terminal of the battery is connected to the p-region and the negative terminal is connected to the n-region. This creates an electric field that allows the majority charge carriers (electrons in the n-region and holes in the p-region) to move across the junction and combine, resulting in current flow. In contrast, when the junction is reverse-biased, the positive terminal is connected to the n-region and the negative terminal is connected to the p-region, which creates a barrier that prevents the majority carriers from crossing the junction, thus no current flows.

Submit
13. What is the barrier potential of silicon at 25 degree celcius?

Explanation

The barrier potential of silicon at 25 degrees Celsius is 0.7V. The barrier potential refers to the voltage required to overcome the potential barrier at the junction of a p-n diode. In this case, the silicon material has a barrier potential of 0.7V at room temperature.

Submit
14. The mass of proton is __________ times the mass of electron.

Explanation

The mass of a proton is 1836 times the mass of an electron. This means that a proton is significantly heavier than an electron. The mass of an electron is very small compared to the mass of a proton, and this difference in mass is a fundamental property of these subatomic particles.

Submit
15. What is the charge of the proton?

Explanation

The charge of the proton is +1.602 x 10^-19. This value represents the elementary charge, which is the fundamental unit of electric charge. Protons are positively charged particles found in the nucleus of an atom. They have a charge equal in magnitude but opposite in sign to the electron's charge. The given answer is the correct value for the charge of a proton, expressed in scientific notation.

Submit
16. The atomic number of an atom is determined by the number of _______ in the nucleus.

Explanation

The atomic number of an atom is determined by the number of protons in the nucleus. This is because the atomic number represents the number of protons in an atom, which determines its identity and place on the periodic table. The number of neutrons, ions, and electrons may vary in an atom, but the number of protons remains constant for a specific element.

Submit
17. What refers to the rapid multiplication of current carriers in reverse breakdown?

Explanation

Avalanche refers to the rapid multiplication of current carriers in reverse breakdown. In reverse breakdown, the voltage across a diode increases beyond its breakdown voltage, causing a sudden increase in the number of charge carriers. This multiplication process is known as avalanche, where the charge carriers collide with other atoms and release more charge carriers in the process. This rapid multiplication results in a significant increase in current flow through the diode.

Submit
18. IN an n-type semiconductor, holes are called

Explanation

In an n-type semiconductor, the majority carriers are electrons, which are responsible for the conduction of current. On the other hand, the minority carriers are the less abundant charge carriers, which in this case are called holes. Holes are essentially the absence of an electron in the valence band, and they can move through the crystal lattice in a manner similar to positive charges. Therefore, the correct answer is "minority carriers".

Submit
19. THe nucleus of an atom is composed of

Explanation

The nucleus of an atom is composed of protons and neutrons. Protons have a positive charge, while neutrons have no charge. These two particles are tightly packed together in the center of the atom, forming the nucleus. Electrons, on the other hand, are negatively charged particles that orbit around the nucleus in specific energy levels. Ions are atoms or molecules that have gained or lost electrons, resulting in a positive or negative charge. Therefore, the correct answer is proton and neutron.

Submit
20. A free electon will eventually lose energy and fall back into a hole. This is called ___________.

Explanation

Recombination refers to the process in which a free electron loses energy and falls back into a hole. This occurs when an electron in a higher energy state combines with a hole (an empty state in the valence band) in a lower energy state, resulting in the recombination of the electron-hole pair. This process is important in semiconductors and plays a crucial role in the functioning of devices such as transistors and solar cells.

Submit
21. What is the atomic number of germanium?

Explanation

Germanium has an atomic number of 32. The atomic number represents the number of protons in an atom's nucleus. Since germanium has an atomic number of 32, it means that it has 32 protons in its nucleus.

Submit
22. What is the barrier potential of germanium at 25 degree celcius?

Explanation

The barrier potential of germanium at 25 degrees Celsius is 0.3V.

Submit
23. When a neutral atom gains an electron, the atom becomes _______/

Explanation

When a neutral atom gains an electron, it becomes a negative ion. This is because the atom now has more electrons than protons, resulting in a net negative charge. The extra electron(s) added to the atom creates an imbalance in the positive and negative charges, making it negatively charged.

Submit
24. What are majority carriers in a p-type semiconductor?

Explanation

In a p-type semiconductor, majority carriers are holes. A p-type semiconductor is created by adding impurities with fewer valence electrons than the host material, creating holes in the crystal lattice. These holes act as positive charge carriers, effectively moving through the material in the opposite direction to the movement of electrons. Therefore, holes are the majority carriers in a p-type semiconductor.

Submit
25. What are majority carriers in an n-type semiconductor?

Explanation

In an n-type semiconductor, majority carriers are free electrons. N-type semiconductors are doped with impurities that introduce extra electrons into the crystal lattice, creating an excess of negative charge. These extra electrons are free to move throughout the material, making them the majority charge carriers. Valence electrons are electrons in the outermost shell of an atom and are not necessarily free to move. Holes are the absence of an electron in the valence band and are considered minority carriers in an n-type semiconductor. Protons are positively charged particles and are not carriers in a semiconductor.

Submit
26. What are the  minority carriers in an n-type semiconductors?

Explanation

In an n-type semiconductor, the majority carriers are free electrons, which are generated due to the presence of impurity atoms with extra valence electrons. However, the minority carriers are holes. Holes are essentially the absence of an electron in the valence band, and they behave as positively charged particles. These holes can move through the crystal lattice, contributing to the conductivity of the material.

Submit
27. An extrinsic semiconductor is a

Explanation

An extrinsic semiconductor is a type of semiconductor that has been intentionally doped with impurities to alter its electrical properties. Doping involves adding small amounts of impurities, such as atoms from Group III or Group V elements, to the semiconductor crystal lattice. This process introduces additional charge carriers, either electrons or holes, into the material, which significantly increases its conductivity compared to a pure semiconductor. Therefore, the correct answer is "doped semiconductor."

Submit
28. IN an n-type semiconductor, free electrons are called

Explanation

In an n-type semiconductor, majority carriers refer to the majority of charge carriers present in the material, which are electrons. These electrons are considered majority carriers because they are the dominant charge carriers in n-type semiconductors, where the material is doped with impurities that introduce extra electrons into the crystal lattice. Minority carriers, on the other hand, refer to the less abundant charge carriers in the material, which are holes in the case of n-type semiconductors. Valence electrons are not specifically associated with n-type semiconductors, and the term "charge carriers" is a general term that encompasses both majority and minority carriers.

Submit
29. Typical leakage current in a pn junction is in the order of

Explanation

The typical leakage current in a pn junction is in the order of microamperes (uA). Leakage current refers to the small amount of current that flows through a pn junction even when it is reverse biased. This current is caused by minority carriers that are thermally generated and diffuse across the junction. The leakage current is usually very small, on the order of microamperes, which is why the correct answer is uA.

Submit
30. What is the energy gap of silicon?

Explanation

The energy gap of silicon is 1.1eV. The energy gap refers to the energy difference between the valence band and the conduction band in a material. In the case of silicon, this energy gap is 1.1eV, which means that it requires 1.1eV of energy for an electron to move from the valence band to the conduction band and become a free charge carrier. This property of silicon makes it a semiconductor, as it can conduct electricity under certain conditions.

Submit
31. What is the atomic number of silicon?

Explanation

The atomic number of an element represents the number of protons in the nucleus of its atom. In the case of silicon, the atomic number is 14. This means that a silicon atom has 14 protons in its nucleus.

Submit
32. What is the energy gap of germanium?

Explanation

The energy gap of germanium is 0.67eV. The energy gap refers to the difference in energy between the valence band and the conduction band in a semiconductor. It represents the minimum amount of energy required for an electron to move from the valence band to the conduction band and become a free charge carrier. In the case of germanium, this energy gap is 0.67eV, which means that it requires 0.67eV of energy for an electron to transition from the valence band to the conduction band and contribute to electrical conductivity.

Submit
33. Which of the following is the equivalent circuit for a diode for third approximation?

Explanation

The equivalent circuit for a diode in third approximation includes a switch in series with a battery in series with a resistance. This is because the third approximation model of a diode takes into account the forward voltage drop across the diode and the resistance associated with it. The switch represents the diode being forward biased, allowing current to flow through the circuit. The battery represents the forward voltage drop, and the resistance represents the internal resistance of the diode.

Submit
34. Typical leakage current in a pn junction is in the order of

Explanation

The typical leakage current in a pn junction is in the order of microamperes (uA). This means that the amount of current that leaks across the junction is in the range of microamperes, which is equivalent to one millionth of an ampere. Leakage current occurs due to the flow of minority charge carriers across the junction, even when it is not forward biased. This small current is typically measured in microamperes and is important to consider in electronic devices to ensure proper functioning and minimize power consumption.

Submit
35. What do you call materials containing more than one element such as GaAs, AlAs or GaP?

Explanation

Compound semiconductors are materials that consist of two or more elements. They are formed by combining different elements, such as GaAs, AlAs, or GaP. These materials have unique electronic properties that make them suitable for various applications in electronics and optoelectronics. Unlike elemental semiconductors, which are made up of a single element, compound semiconductors offer a wider range of possibilities for controlling and manipulating their electrical characteristics. Therefore, the term "compound semiconductor" accurately describes materials containing more than one element.

Submit
36. When a neutral atom losses an electron, the atom becomes ______.

Explanation

When a neutral atom loses an electron, it results in a positive ion. This is because the atom now has more protons than electrons, giving it a net positive charge. The loss of an electron creates an imbalance in the atom's charge, leading to a positive ion formation.

Submit
37. What do you call the bonds that hold the crystals together?

Explanation

Covalent bonds are the type of bonds that hold crystals together. In a covalent bond, atoms share electrons, resulting in a strong bond between them. This type of bond is commonly found in non-metallic elements and compounds. Ionic bonds involve the transfer of electrons, whereas covalent bonds involve the sharing of electrons. Mighty bond and semicon bond are not recognized terms for describing bonds.

Submit
38. What are the minority carriers in a p-type semiconductor?

Explanation

In a p-type semiconductor, the majority carriers are holes, which are essentially the absence of electrons in the valence band. Minority carriers, on the other hand, are the opposite charge carriers to the majority carriers. Since the majority carriers in a p-type semiconductor are holes (positive charge), the minority carriers would be free electrons (negative charge). These free electrons are present in small numbers and are generated due to thermal excitation or impurity doping.

Submit
39. An LED and a phototransistor is equivalent to a/an

Explanation

An optocoupler is a device that consists of an LED and a phototransistor. It is used to transfer electrical signals between two isolated circuits by using light. The LED emits light when current flows through it, and this light is detected by the phototransistor, which then generates a corresponding electrical signal. This allows for electrical isolation and protection between the input and output circuits. Therefore, an LED and a phototransistor combined together form an optocoupler.

Submit
40. What do you call single element semiconductor materials such as silicon and germanium?

Explanation

Single element semiconductor materials such as silicon and germanium are called elemental semiconductors. This is because they consist of a single element in their pure form and exhibit semiconductor properties, meaning they can conduct electricity under certain conditions. These materials are widely used in electronic devices and integrated circuits due to their ability to control and manipulate electrical currents.

Submit
41. What refers to the absence of an electron in the valence band?

Explanation

A hole refers to the absence of an electron in the valence band. In a semiconductor material, when an electron moves from the valence band to the conduction band, it leaves behind a vacant space called a hole. This hole can behave as a positively charged particle and can move through the material in a manner similar to how an electron moves. Holes play a crucial role in the conduction of electricity in semiconductors and are important for understanding the behavior of electronic devices.

Submit
42. Each pair of positive and negative ions at the junction is called a/an

Explanation

A dipole is formed by a pair of positive and negative ions at a junction. In a dipole, the positive and negative charges are separated, creating a polar molecule with a positive end and a negative end. This separation of charges creates an electric field, which is the defining characteristic of a dipole. Therefore, the correct answer is dipole.

Submit
43. THe folowing are the advantages of semiconductor devices over vacuum tubes except

Explanation

Semiconductor devices have several advantages over vacuum tubes, including smaller size, lower working voltage, and light weight. However, they are not able to withstand high voltages as well as vacuum tubes. This means that semiconductor devices are more susceptible to damage or failure when exposed to high voltage conditions.

Submit
44. When temperature increased, barrier potential

Explanation

When the temperature increases, the barrier potential in a semiconductor decreases. This is because as the temperature rises, more electrons gain sufficient energy to overcome the potential barrier and move across the junction. This results in a decrease in the barrier potential.

Submit
45. A __________ is one that has acquired enough energy to break away from the valence band of the parent atom.

Explanation

A free electron is one that has acquired enough energy to break away from the valence band of the parent atom. When an electron gains sufficient energy, it can overcome the attractive forces of the nucleus and become detached from its parent atom. This allows the electron to move freely within the material, making it a free electron. Free electrons play a crucial role in various physical phenomena, such as electrical conductivity and the behavior of semiconductors.

Submit
46. An atom has discrete bands of energy called

Explanation

An atom has discrete bands of energy called shells. Shells are the regions surrounding the nucleus of an atom where electrons can be found. These shells are organized into different energy levels, with each level capable of holding a specific number of electrons. The electrons occupy the shells in a specific order, with the innermost shell being filled first before moving on to the outer shells. The concept of shells helps explain the arrangement and behavior of electrons in an atom.

Submit
47. What is the hypothetical particle having a fractional electrical charge and are thought to be constituents of other subatomic particles?

Explanation

Quarks are hypothetical particles that have a fractional electrical charge and are believed to be the building blocks of other subatomic particles. They are fundamental particles that combine to form protons and neutrons, which in turn make up the nucleus of an atom. Quarks come in six different types or flavors, each with a different electrical charge. This explanation fits the question as it describes the hypothetical particle with fractional electrical charge and their role as constituents of other subatomic particles.

Submit
48. The resistance of a forward biased pn junction is in the order of

Explanation

The resistance of a forward biased pn junction is typically in the order of ohm. In a forward biased pn junction, the p-side is connected to the positive terminal of the battery and the n-side is connected to the negative terminal. This causes the majority carriers to move towards the junction, resulting in a low resistance path for the current flow. The resistance is typically in the order of ohms because the pn junction is designed to have a low resistance in the forward biased condition.

Submit
49. The removal by electronic means of one extremity of an input waveform is called

Explanation

Clipping refers to the removal of one extremity of an input waveform using electronic means. This process involves cutting off or limiting the amplitude of the waveform at a certain threshold level. It is commonly used in audio processing to prevent distortion or overload of signals that exceed the maximum allowed amplitude. Clipping helps to maintain the shape of the waveform by removing only the extreme portions, resulting in a more controlled and balanced output signal.

Submit
50. The diffused impurities with three valence electrons are called _______

Explanation

Acceptor atoms are diffused impurities with three valence electrons. These atoms have an electron deficiency and can accept an extra electron from the surrounding material, creating a positive charge. This property makes them useful in the creation of p-type semiconductors, where they contribute to the formation of electron holes, which play a crucial role in the conduction of electric current.

Submit
51. The mass of neutron is __________ times the mass of electron.

Explanation

The mass of a neutron is 1839 times the mass of an electron.

Submit
52. What is created by adding impurity atoms with three valence electrons?

Explanation

When impurity atoms with three valence electrons are added to a semiconductor, it creates a p-type semiconductor. In this type of semiconductor, the impurity atoms (also known as acceptor atoms) create "holes" in the crystal lattice structure. These holes act as positive charge carriers, allowing for the movement of positive charges within the material. This results in a material with an excess of positive charge carriers (holes) and a deficiency of negative charge carriers (electrons), hence creating a p-type semiconductor.

Submit
53. What is formed when part of a material is doped n-type and part of it is doped p-type?

Explanation

When part of a material is doped n-type and part of it is doped p-type, a pn junction is formed. In a pn junction, the n-type region has an excess of electrons while the p-type region has an excess of holes. This creates a depletion region at the junction where the electrons and holes combine, resulting in a barrier to current flow. The pn junction is the basic building block of various electronic devices, such as diodes, transistors, and solar cells.

Submit
54. The time taken by the diode to operate in reverse condition from forward conduction

Explanation

Reverse recovery time refers to the time it takes for a diode to switch from the forward conduction state to the reverse condition. During forward conduction, the diode allows current to flow in one direction, but when the polarity is reversed, it needs some time to block the current flow. This delay is known as the reverse recovery time. It is an important parameter to consider when designing circuits that involve diodes, as it affects the overall performance and efficiency of the system.

Submit
55. The resistance of a forward biased pn junction is in the order of

Explanation

The resistance of a forward biased pn junction is in the order of ohm. This is because when a pn junction is forward biased, the majority carriers (electrons in the n-region and holes in the p-region) are pushed towards the junction, reducing the width of the depletion region. As a result, the resistance of the junction decreases, allowing current to flow more easily. The resistance is typically in the order of ohms, which is the standard unit for measuring resistance.

Submit
56. The removal by electronic means of one extremity of an input waveform is called _______

Explanation

Clipping is the correct answer because it refers to the removal of one extremity of an input waveform using electronic means. This process involves cutting off or limiting the amplitude of the waveform at a certain threshold level. Clipping is commonly used in audio signal processing to prevent distortion and maintain signal integrity. It is different from filtering, amplifying, and clamping, which involve other types of waveform manipulation.

Submit
57. What is the mass of electron in grams?

Explanation

The mass of an electron is extremely small, and it is typically measured in kilograms or atomic mass units (amu). However, in this question, the mass of the electron is given in grams. Among the given options, the correct answer is 9.107 x 10^-28 grams.

Submit
58. Avalance effects occurs at

Explanation

Avalanche effects occur at higher reverse voltages. When a reverse voltage is applied to a diode, it creates a strong electric field across the depletion region. At higher reverse voltages, the electric field becomes so strong that it causes the electrons to gain enough energy to break free from the covalent bonds, leading to an avalanche breakdown. This breakdown can result in a large current flow, potentially damaging the diode if not properly controlled. Therefore, higher reverse voltages are associated with avalanche effects.

Submit
59. Barrier potential ______________ as temperature increases.

Explanation

As temperature increases, the barrier potential in a semiconductor decreases. This is because at higher temperatures, more thermal energy is available to free electrons and create electron-hole pairs. These additional charge carriers reduce the effectiveness of the barrier potential in preventing current flow, leading to a decrease in the barrier potential.

Submit
60. A silicon crystal is a/an ____________ of semiconductor if every atom in the crystal is a silicon atom.

Explanation

Intrinsic is the correct answer because in an intrinsic semiconductor, every atom in the crystal is of the same type (in this case, silicon). This means that there are no impurities or dopants added to the crystal structure. In an intrinsic semiconductor, the electrical behavior is determined solely by the properties of the silicon atoms themselves.

Submit
61. What is created by adding impurity atoms with five valence electrons?

Explanation

When impurity atoms with five valence electrons are added to a semiconductor, they create an excess of electrons in the material. This results in the formation of an n-type semiconductor. In an n-type semiconductor, the impurity atoms provide additional electrons that are free to move within the crystal lattice, increasing its conductivity. This excess of electrons is responsible for the n in n-type semiconductor.

Submit
62. A diode modeling circuit which considers, the threshold voltage, average resistance and switch as the diode's equivaltent circuit.

Explanation

The given answer, "piecewise linear model," is the correct choice because it accurately describes a diode modeling circuit that considers the threshold voltage, average resistance, and switch as the diode's equivalent circuit. In a piecewise linear model, the diode is represented by a combination of linear segments, each representing a different operating region of the diode. This model provides a more accurate representation of the diode's behavior compared to an ideal model or simplified model, which may not account for non-linear characteristics. A real model, on the other hand, would include additional complexities and non-idealities beyond the given circuit description.

Submit
63. The maximum reverse voltage that can be applied before current surges is called

Explanation

The reverse breakdown voltage refers to the maximum reverse voltage that can be applied to a device before it experiences a sudden surge in current. This voltage level is crucial as it helps determine the device's ability to withstand reverse voltage without damaging or causing a breakdown in its operation. It is an important parameter to consider when designing and selecting components for electronic circuits.

Submit
64. Why is a diode replaced accross the coild portion of a relay?

Explanation

A diode is placed across the coil portion of a relay to protect it from high voltage transients when the magnetic field collapses. When the relay coil is energized, it creates a magnetic field. When the power to the coil is suddenly turned off, the collapse of this magnetic field can generate a high voltage spike. This spike can potentially damage the relay or other components in the circuit. By placing a diode in reverse bias across the coil, it allows the current to flow in a loop and provides a path for the voltage spike to dissipate harmlessly.

Submit
65. The peak inverse voltage of a full wave center tapped rectifier circuit is equal to _____________ of the input signal./

Explanation

In a full wave center tapped rectifier circuit, the peak inverse voltage refers to the maximum voltage that appears across the diodes when they are reverse biased. This voltage is equal to twice the peak voltage of the input signal because during the positive half-cycle of the input signal, one diode conducts and the other is reverse biased, and during the negative half-cycle, the roles are reversed. This results in the voltage across the diodes being twice the peak voltage of the input signal.

Submit
66. Semiconductor atoms bond together to form a solid material called _____________

Explanation

Semiconductor atoms bond together to form a solid material called a crystal. A crystal is a regular, repeating arrangement of atoms, ions, or molecules in a three-dimensional pattern. In a crystal lattice, the atoms are arranged in a highly ordered structure, which gives the material its characteristic properties. Crystals have a unique arrangement of atoms that allows them to have specific electrical, optical, and mechanical properties, making them essential for various technological applications, including electronics and photonics.

Submit
67. Optocoupler is otherwise known as

Explanation

An optocoupler is a device that uses a combination of an LED (light-emitting diode) and a phototransistor or a photodiode to transfer electrical signals between two isolated circuits. It is used to provide electrical isolation and prevent interference between the input and output circuits. Therefore, the correct answer is optoisolators, as they accurately describe the function and purpose of an optocoupler.

Submit
68. What is the letter designation of the valence shell of a silicon atom?

Explanation

The letter designation of the valence shell of a silicon atom is M. In the electron configuration of silicon, the valence electrons occupy the third energy level, which is designated as the M shell. The M shell can hold a maximum of 18 electrons.

Submit
69. The creation of free electrons through zener effect is also known as

Explanation

The creation of free electrons through the Zener effect is known as avalanche emission. The Zener effect occurs when a high electric field is applied to a semiconductor material, causing a breakdown and the generation of free electrons. This avalanche effect is characterized by a rapid increase in the number of free electrons, leading to a significant current flow. The other options, thermionic emission, low-field emission, and high-field emission, refer to different mechanisms of electron emission but are not specifically related to the Zener effect.

Submit
70. What temperature is inside the diode, right at the junction of the p- and n-type materials?

Explanation

The correct answer is "junction temperature." The junction temperature refers to the temperature at the point where the p- and n-type materials of a diode are joined together. This temperature is crucial because it affects the performance and reliability of the diode. The junction temperature is typically higher than the ambient temperature, which is the temperature of the surrounding environment. The internal temperature of the diode may also be different from the junction temperature due to various factors, but the junction temperature is specifically related to the temperature at the diode's junction.

Submit
71. AN equivalent circuit of a diode in which it is represented as a switch in series with a barrier potential

Explanation

The second approximation represents the diode as a switch in series with a barrier potential. This approximation assumes that the diode is either fully conducting or fully non-conducting, depending on the polarity of the voltage applied across it. When the diode is forward-biased, it acts as a closed switch and allows current to flow through. When the diode is reverse-biased, it acts as an open switch and blocks the current. The barrier potential represents the voltage required to overcome the potential barrier at the junction of the diode. This approximation simplifies the analysis of circuits involving diodes.

Submit
72. The sum of the resistances of the p-region and the n-region is called

Explanation

The term "bulk resistance" refers to the combined resistance of both the p-region and the n-region in a junction. It accounts for the resistance encountered by the current as it passes through the entire region, including the depletion region. This term is used to describe the overall resistance experienced in the bulk of the semiconductor material, rather than the specific resistance at the junction itself.

Submit
73. When an electron breaks away to become free,  it leaves a hole in the valence band creating what is known as ___________.

Explanation

When an electron breaks away from the valence band, it leaves behind a positively charged "hole" in the valence band. This hole can attract and bind another electron, forming an electron-hole pair. Therefore, the correct answer is "electron-hole pair."

Submit
74. The direction of holes is opposite from the electrons because

Explanation

The direction of holes is opposite from the electrons because charge carriers, which can be either electrons or holes, flow continuously through a material. In a conductor, such as a metal, electrons are the majority charge carriers and flow in one direction. However, in a semiconductor, holes are the majority charge carriers, and they flow in the opposite direction of the electrons. This is because when an electron moves from one atom to another, it leaves behind a positively charged hole in the atom it left. Therefore, the movement of charge carriers, whether they are electrons or holes, is always from atom to atom.

Submit
75. What is the number of neutrons of copper atom?

Explanation

Copper has an atomic number of 29, which means it has 29 protons in its nucleus. The number of neutrons can be calculated by subtracting the atomic number from the atomic mass. Since the atomic mass of copper is approximately 63.5, the number of neutrons in a copper atom is approximately 34. Therefore, the correct answer is 34.

Submit
76. The temperature coefficient of resistance of a semiconductor is

Explanation

The temperature coefficient of resistance of a semiconductor being negative means that as the temperature increases, the resistance of the semiconductor decreases. This is because as the temperature rises, more charge carriers are generated in the semiconductor, leading to an increase in conductivity and a decrease in resistance.

Submit
77. A 20 Vp-p signal is applied to a positive clamper with a -2 volt dc bias. What is the output swing of the clamped signal?

Explanation

The output swing of the clamped signal is from -2V to 18V. This is because the positive clamper adds the DC bias voltage to the input signal. In this case, the DC bias is -2V, so when the input signal swings from 0V to 20V, the output signal will swing from -2V to -2V + 20V = 18V.

Submit
78. For either germanium or silicon diodes, the barrier potential decreases __________ for each celcius degree rise

Explanation

The barrier potential of germanium or silicon diodes decreases by 2 mV for each Celsius degree rise. This means that as the temperature increases, the barrier potential decreases by 2 millivolts. This is an important characteristic of diodes to consider when designing electronic circuits, as it affects their performance and behavior.

Submit
79. When doping increases, __________ of a semiconductor decreases.

Explanation

When doping increases in a semiconductor, the number of impurity atoms introduced into the material increases. These impurity atoms create additional energy levels in the band structure of the semiconductor, which can act as charge carriers. As a result, the concentration of charge carriers in the semiconductor increases, leading to an increase in conductivity. However, the increase in doping also leads to an increase in the number of scattering centers, which in turn increases the resistance of the semiconductor material. Therefore, as doping increases, the bulk resistance of the semiconductor decreases.

Submit
80. What type of current occurs as valance electrons move from hole to hole creating, in effect, a movement of holes in the opposite direction?

Explanation

Hole current occurs when valence electrons move from hole to hole, creating a movement of holes in the opposite direction. This phenomenon is commonly observed in semiconductors, where the absence of an electron in the valence band is treated as a positively charged particle called a hole. As electrons move from one hole to another, it appears as if the holes themselves are moving in the opposite direction, resulting in hole current.

Submit
81. The direction of holes if rom

Explanation

In a P-N junction, the movement of charge carriers occurs from the P-type material to the N-type material. This is because the P-type material is doped with acceptor atoms, creating holes as majority carriers. On the other hand, the N-type material is doped with donor atoms, creating free electrons as majority carriers. When the two materials are brought together to form a junction, the holes in the P-type material diffuse towards the N-type material, where they combine with the free electrons. This movement of holes from the P-type material to the N-type material is the direction of hole flow in a P-N junction.

Submit
82. Which is the principal charcetristics of a zener diode?

Explanation

A zener diode is a type of diode that is designed to operate in the reverse breakdown region, where it exhibits a constant voltage drop across its terminals. This means that even if the current through the diode varies, the voltage across it remains relatively constant. This characteristic makes zener diodes suitable for voltage regulation applications, where a stable voltage is required despite changes in current. Therefore, the correct answer is "constant voltage under conditions of varying current".

Submit
83. At room temperature, a silicon crystal acts approximately like a/an

Explanation

At room temperature, a silicon crystal acts approximately like an insulator. Insulators are materials that do not conduct electricity easily, and they have high resistance to the flow of electric current. Silicon is a semiconductor material, which means that its conductivity lies between that of conductors and insulators. However, at room temperature, silicon behaves more like an insulator as its atoms are tightly bonded, preventing the free flow of electrons. This makes it suitable for use in electronic devices where it can be used to control and manipulate the flow of electricity.

Submit
84. A diode is a nonlinear device because

Explanation

A diode is a nonlinear device because it produces a non-linear graph. In a linear device, the current would be directly proportional to the voltage, meaning that the graph would be a straight line. However, in a diode, the relationship between current and voltage is not linear. This can be observed in the graph of a diode, where the current increases rapidly once a certain voltage threshold is reached. Therefore, the non-linear graph produced by a diode is what classifies it as a nonlinear device.

Submit
85. Diffusion or storage capcitance is the term used to refer to the

Explanation

The forward bias capacitance of a diode refers to the capacitance that exists between the p-n junction of the diode when it is forward biased. When a diode is forward biased, it allows current to flow through it, and this current causes the depletion region to shrink. As the depletion region decreases, the capacitance between the p-n junction increases. This capacitance is known as the forward bias capacitance. It is important to consider this capacitance when designing circuits involving diodes, as it can affect the overall performance and behavior of the circuit.

Submit
86. The reverse bias diode capacitance is termed as

Explanation

The reverse bias diode capacitance is called the transition region capacitance because it refers to the capacitance that exists in the transition region between the depletion region and the neutral region of a diode. When a diode is reverse biased, this transition region becomes wider, resulting in an increase in the capacitance. This capacitance is important to consider in high-frequency applications, as it can affect the overall performance of the diode.

Submit
87. How are electon-hole pairs produced?

Explanation

Electron-hole pairs are produced thermally when thermal energy is absorbed by a material, causing an electron to move from the valence band to the conduction band, leaving behind a positively charged hole in the valence band. This process occurs in certain semiconductors or insulators at high temperatures, where the thermal energy is sufficient to promote electrons to higher energy levels. Doping, covalent bonding, and recombination are not direct mechanisms for the production of electron-hole pairs.

Submit
88. Avalance occurs in a reverse-biased pn-junction if the bias voltage _______________ the breakdown voltage.

Explanation

Avalanche occurs in a reverse-biased pn-junction if the bias voltage is greater than or equal to the breakdown voltage.

Submit
89. What is the typical bulk resistance of a rectifier diodes?

Explanation

The typical bulk resistance of a rectifier diode is greater than 1 ohm. This is because the bulk resistance refers to the resistance offered by the semiconductor material itself, which is typically higher than 1 ohm in a rectifier diode. The bulk resistance is influenced by factors such as the doping level, but it is generally greater than 1 ohm.

Submit
90. What is the process by which an atom are persistently losing and then regaining electrons?

Explanation

Ionization is the process by which an atom persistently loses and then regains electrons. During ionization, an atom either gains or loses electrons to form ions. This process occurs when atoms are exposed to high energy, such as heat or electricity, causing the outermost electrons to be either removed or added to the atom. Once the atom becomes an ion, it can regain or lose electrons to achieve a stable electron configuration. Ionization is a fundamental process in chemistry and physics, playing a crucial role in various phenomena, such as the behavior of gases, the formation of plasma, and chemical reactions.

Submit
91. Two pn silicon diodes are connected in series opposing. A 5V voltage is impressed upon them. Find the voltage across each junction at room temperature when nVt= 0.052V.

Explanation

When two pn silicon diodes are connected in series opposing, the voltage across each junction can be found using the formula V = nVt * ln(I/I0 + 1), where V is the voltage across the junction, nVt is the thermal voltage (given as 0.052V), ln is the natural logarithm, I is the current through the diode, and I0 is the reverse saturation current. In this case, since the diodes are connected in series opposing, the current through each diode is the same. Therefore, the voltage across one junction is 0.036V and the voltage across the other junction is 4.964V.

Submit
92. Semiconductors have electrical resistivities between____________ and ____________ ohm-meter.

Explanation

Semiconductors have electrical resistivities between 10^-5 and 10^5 ohm-meter. This means that semiconductors have resistivities that are higher than conductors (which typically have resistivities on the order of 10^-8 ohm-meter) but lower than insulators (which typically have resistivities on the order of 10^12 ohm-meter). This range of resistivities allows semiconductors to exhibit unique electrical properties, such as the ability to conduct electricity under certain conditions and act as insulators under others.

Submit
93. Semiconductors are usually materials which have energy-band gaps smaller than _________ eV.

Explanation

Semiconductors are materials that have energy-band gaps smaller than 3 eV. The energy-band gap refers to the energy difference between the valence band and the conduction band in a material. In semiconductors, this gap is smaller compared to insulators and larger compared to conductors. This characteristic allows semiconductors to conduct electricity under certain conditions, making them ideal for applications in electronics and technology.

Submit
94. Each atom in a silicon crystal has how many valence electrons?

Explanation

Each atom in a silicon crystal has 8 valence electrons. Valence electrons are the electrons in the outermost shell of an atom, and they determine the atom's chemical properties and bonding behavior. Silicon, being in Group 14 of the periodic table, has 4 valence electrons in its outermost shell. However, in a crystal structure, each silicon atom forms covalent bonds with four neighboring silicon atoms, resulting in a shared electron arrangement where each atom effectively has 8 valence electrons. This allows silicon to form a stable crystal lattice structure.

Submit
95. What is an unimportant factor concerning the frequency at which a p-n junctoin will work effectively?

Explanation

The capacitance with reverse bias is an unimportant factor concerning the frequency at which a p-n junction will work effectively. This means that the frequency at which the junction operates effectively is not affected by the capacitance when the junction is under reverse bias. Other factors such as the type of semiconductor material, cross-sectional area of the junction, and the reverse current may have an impact on the junction's effectiveness at different frequencies.

Submit
96. What is the most important spectifictaion for semiconductor diode?

Explanation

The current capacity is the most important specification for a semiconductor diode. This refers to the maximum amount of current that the diode can handle without getting damaged. It is crucial to ensure that the current flowing through the diode does not exceed its current capacity, as this can lead to overheating and failure of the diode. Therefore, selecting a diode with an appropriate current capacity is essential for the proper functioning and longevity of the device.

Submit
97. Zener effect depends only on the

Explanation

The Zener effect refers to the phenomenon where a reverse-biased pn junction experiences a sudden increase in current when the electric field across the junction reaches a critical value. This effect occurs due to the impact ionization of minority carriers, which are carriers that are present in smaller quantities compared to the majority carriers. The high-speed minority carriers gain enough energy from the electric field to collide with the valence electrons, creating electron-hole pairs and resulting in an increase in current. Therefore, the Zener effect depends on the high-speed minority carriers.

Submit
98. A negative clamper clamps which extrimity of the output signal to zero volt?

Explanation

A negative clamper clamps the most positive extremity of the output signal to zero volt. This means that it shifts the entire waveform downwards so that the highest point of the signal is at zero volts. This is achieved by adding a DC bias in such a way that the peak of the waveform is aligned with the zero voltage reference level.

Submit
99. One of the important diode parameters which gives the magnitude of current the diode can handle without burning

Explanation

Forward current is the correct answer because it refers to the magnitude of current that a diode can handle without burning. When a diode is forward biased, it allows current to flow in the forward direction, and the forward current rating indicates the maximum current that the diode can safely handle without getting damaged. This parameter is crucial in ensuring the proper functioning and longevity of the diode in various electronic circuits.

Submit
100. A depletion region forms starting at the junction that is devoid of any majority carriers. The depletion region is formed by ___________.

Explanation

The correct answer is recombination. A depletion region forms at the junction of a semiconductor device when there is a lack of majority carriers. This occurs through a process called recombination, where electrons from the n-type region and holes from the p-type region combine and neutralize each other, creating the depletion region. This region is devoid of any majority carriers, leading to a barrier to the flow of current in the device.

Submit
View My Results

Quiz Review Timeline (Updated): Mar 19, 2023 +

Our quizzes are rigorously reviewed, monitored and continuously updated by our expert board to maintain accuracy, relevance, and timeliness.

  • Current Version
  • Mar 19, 2023
    Quiz Edited by
    ProProfs Editorial Team
  • Nov 17, 2011
    Quiz Created by
    Toinkxz77
Cancel
  • All
    All (100)
  • Unanswered
    Unanswered ()
  • Answered
    Answered ()
What is the most widely used semiconductor material?
What do you call impurites with five valence electrons?
According to the classical ______, the atom is viewed as having a...
What is the smallest particle that retains the characteristics of its...
What is the basic particle of negative electrical charge?
WHat type of material have very few free electrons and do not conduct...
What type of materials has very large number of free electrons and...
Which one is electrically neutral?
An electron in the outermost shell of an atom is called
A semiconductor is an element with a valence of
What is the process of adding pentavalent or trivalent impurities to...
There is current through the pn junction only when it is ____________.
What is the barrier potential of silicon at 25 degree celcius?
The mass of proton is __________ times the mass of electron.
What is the charge of the proton?
The atomic number of an atom is determined by the number of _______ in...
What refers to the rapid multiplication of current carriers in reverse...
IN an n-type semiconductor, holes are called
THe nucleus of an atom is composed of
A free electon will eventually lose energy and fall back into a hole....
What is the atomic number of germanium?
What is the barrier potential of germanium at 25 degree celcius?
When a neutral atom gains an electron, the atom becomes _______/
What are majority carriers in a p-type semiconductor?
What are majority carriers in an n-type semiconductor?
What are the  minority carriers in an n-type semiconductors?
An extrinsic semiconductor is a
IN an n-type semiconductor, free electrons are called
Typical leakage current in a pn junction is in the order of
What is the energy gap of silicon?
What is the atomic number of silicon?
What is the energy gap of germanium?
Which of the following is the equivalent circuit for a diode for third...
Typical leakage current in a pn junction is in the order of
What do you call materials containing more than one element such as...
When a neutral atom losses an electron, the atom becomes ______.
What do you call the bonds that hold the crystals together?
What are the minority carriers in a p-type semiconductor?
An LED and a phototransistor is equivalent to a/an
What do you call single element semiconductor materials such as...
What refers to the absence of an electron in the valence band?
Each pair of positive and negative ions at the junction is called a/an
THe folowing are the advantages of semiconductor devices over vacuum...
When temperature increased, barrier potential
A __________ is one that has acquired enough energy to break away from...
An atom has discrete bands of energy called
What is the hypothetical particle having a fractional electrical...
The resistance of a forward biased pn junction is in the order of
The removal by electronic means of one extremity of an input waveform...
The diffused impurities with three valence electrons are called...
The mass of neutron is __________ times the mass of electron.
What is created by adding impurity atoms with three valence electrons?
What is formed when part of a material is doped n-type and part of it...
The time taken by the diode to operate in reverse condition from...
The resistance of a forward biased pn junction is in the order of
The removal by electronic means of one extremity of an input waveform...
What is the mass of electron in grams?
Avalance effects occurs at
Barrier potential ______________ as temperature increases.
A silicon crystal is a/an ____________ of semiconductor if every atom...
What is created by adding impurity atoms with five valence electrons?
A diode modeling circuit which considers, the threshold voltage,...
The maximum reverse voltage that can be applied before current surges...
Why is a diode replaced accross the coild portion of a relay?
The peak inverse voltage of a full wave center tapped rectifier...
Semiconductor atoms bond together to form a solid material called...
Optocoupler is otherwise known as
What is the letter designation of the valence shell of a silicon atom?
The creation of free electrons through zener effect is also known as
What temperature is inside the diode, right at the junction of the p-...
AN equivalent circuit of a diode in which it is represented as a...
The sum of the resistances of the p-region and the n-region is called
When an electron breaks away to become free,  it leaves a hole in...
The direction of holes is opposite from the electrons because
What is the number of neutrons of copper atom?
The temperature coefficient of resistance of a semiconductor is
A 20 Vp-p signal is applied to a positive clamper with a -2 volt dc...
For either germanium or silicon diodes, the barrier potential...
When doping increases, __________ of a semiconductor decreases.
What type of current occurs as valance electrons move from hole to...
The direction of holes if rom
Which is the principal charcetristics of a zener diode?
At room temperature, a silicon crystal acts approximately like a/an
A diode is a nonlinear device because
Diffusion or storage capcitance is the term used to refer to the
The reverse bias diode capacitance is termed as
How are electon-hole pairs produced?
Avalance occurs in a reverse-biased pn-junction if the bias voltage...
What is the typical bulk resistance of a rectifier diodes?
What is the process by which an atom are persistently losing and then...
Two pn silicon diodes are connected in series opposing. A 5V voltage...
Semiconductors have electrical resistivities between____________ and...
Semiconductors are usually materials which have energy-band gaps...
Each atom in a silicon crystal has how many valence electrons?
What is an unimportant factor concerning the frequency at which a p-n...
What is the most important spectifictaion for semiconductor diode?
Zener effect depends only on the
A negative clamper clamps which extrimity of the output signal to zero...
One of the important diode parameters which gives the magnitude of...
A depletion region forms starting at the junction that is devoid of...
Alert!

Advertisement
