Security + Network Infrastructure

File Transfer Protocol (FTP) is used to transfer files from one host to another. Internet Control Message Protocol (ICMP) is used verify that remote hosts are reachable. Telnet is a protocol/service that allows remote users to access a system using terminal emulation. Domain Name Service (DNS) is used to resolve host names to IP addresses.

The Class C address range is from 192.168.0.0 to 192.168.255.255. The Class B private address range is from 172.16.0.0 to 172.31.255.255. The Class A private address range is from 10.0.0.0 to 10.255.255.25. The 127.0.86.1 address is incorrect because all addresses beginning with 127 are reserved for loopback purposes.

An intranet is a private internal network implemented and maintained by an individual company or organization. An extranet is a private network that also includes outside partners. A demilitarized zone (DMZ) is an area where public server access is made available to people you might not trust. The Internet is the global network connecting computers and individual networks.

Trivial File Transfer Protocol (TFTP) is an anonymous version of FTP. Simple Network Management Protocol (SNMP) is used to manage and monitor devices in a network. Internet Control Message Protocol (ICMP) is used to report errors and reply to requests from programs such as ping and traceroute. Internet Group Management Protocol (IGMP) is used to manage group or multicasting sessions.

Domain Name Service (DNS) is used to resolve host names to IP addresses. File Transfer Protocol (FTP) is used to transfer files from one host to another. Internet Control Message Protocol (ICMP) is used to verify that remote hosts are reachable. Telnet is a protocol/service that allows remote users to access a system using terminal emulation.

The Class C address range is from 192.168.0.0 to 192.168.255.255. The Class B private address range is from 172.16.0.0 to 172.31.255.255. The Class A private address range is from 10.0.0.0 to 10.255.255.25. The address 127.0.86.1 is invalid because all addresses beginning with 127 are reserved for loopback purposes.

An extranet is a private network that also includes outside partners. An intranet is a private internal network implemented and maintained by an individual company or organization. A demilitarized zone (DMZ) is an area where public server access is made available to people you might not trust. The Internet is the global network connecting computers and individual networks.

In a three-way handshake, the second message is SYN/ACK. The first message is SYN, and the third message is ACK. A message of RDRAM is not sent during any part of the process.

Telnet is a protocol/service that allows remote users to access a system using terminal emulation. FTP is used to transfer files from one host to another. Internet Control Message Protocol (ICMP) is used verify that remote hosts are reachable. Domain Name Service (DNS) is used to resolve host names to IP addresses.

A sniffer is a device that captures and displays network traffic. A scanner is a device that looks for open ports. Neither a freezer nor a watchdog is a valid network device used for this purpose.

The Class B private address range is from 172.16.0.0 to 172.31.255.255. The Class A private address range is from 10.0.0.0 to 10.255.255.25. The Class C address range is from 192.168.0.0 to 192.168.255.255. The address 127.0.86.1 is incorrect because any address beginning with 127 is reserved for loopback purposes.

The Class A private address range is from 10.0.0.0 to 10.255.255.25. The Class B private address range is from 172.16.0.0 to 172.31.255.255. The Class C address range is from 192.168.0.0 to 192.168.255.255. The address 127.0.86.1 is incorrect because any address beginning with 127 is reserved for loopback.

Packet sniffing is the process of monitoring data that is transmitted across a network. Footprinting is the process of systematically identifying a network and its security posture. Scanning is the process that attackers use to gather information about how your network is configured. Signal analysis/intelligence involves methods used to gain information about your environment including footprinting and scanning.

In a three-way handshake, the first message is SYN. The second message is SYN/ACK. The third message is ACK. A message of RDRAM is not sent during any part of the process.

Simple Network Management Protocol (SNMP) uses port 161. The NetBIOS name service uses port 137. The NetBIOS datagram service uses port 138. Traps use port 162.

A demilitarized zone (DMZ) is an area where public server access is made available to people you might not trust. An intranet is a private internal network implemented and maintained by an individual company or organization. An extranet is a private network that also includes outside partners. The Internet is the global network connecting computers and individual networks.

Denial-of-service (DoS) attacks target Internet Control Message Protocol (ICMP). Simple Network Management Protocol (SNMP) is used to manage and monitor devices in a network. Internet Group Management Protocol (IGMP) is used manage group or multicasting sessions; although it could potentially be exploited by a DoS attack, it is not the best answer. Trivial File Transfer Protocol (TFTP) is an anonymous version of FTP.

Windows-based operating systems use a Windows Socket (WinSock) to communicate with TCP/IP. The other options do not represent valid interfaces for this purpose.

Internet Control Message Protocol (ICMP) is used to report errors and reply to requests from programs such as ping and traceroute. Simple Network Management Protocol (SNMP) is used to manage and monitor devices in a network. Internet Group Management Protocol (IGMP) is used manage group or multicasting sessions. Trivial File Transfer Protocol (TFTP) is an anonymous version of FTP.

In a three-way handshake, the third message is ACK. The first message is SYN, and the second message is SYN/ACK. A message of RDRAM is not sent during any part of the process.

Address Resolution Protocol (ARP) operates at the Internet layer. All the other choices operate at the application layer.

Port 137 is used by the NetBIOS name service. Port 138 is used by the NetBIOS datagram service. Simple Network Management Protocol (SNMP) uses port 161, while traps use port 162.

The most recent version of Simple Network Management Protocol (SNMP) is SNMPv3. This is a new standard, but most systems still use SNMPv2, which was an upgrade to SNMP. SNMPv4, or subsequent versions, is not out yet.

The 802.11 standard defines wireless LANs transmitting at 1Mbps or 2Mbps using the 2.4GHz spectrum. The 802.11a standard provides wireless bandwidth of up to 54Mbps in the 5GHz spectrum. The 802.11b standard provides for bandwidth up to 11Mbps in the 2.4GHz spectrum. The 802.11g standard provides for bandwidth up to 54Mbps in the 2.4GHz frequency spectrum.

SMTP operates at the application layer of the TCP/IP architecture. TCP operates at the host-to-host layer of the TCP/IP architecture. IP operates at the Internet layer of the TCP/IP architecture. UDP operates at the host-to-host layer of the TCP/IP architecture.

A smurf attack, like many other UDP-based attacks, uses ICMP. The purpose is to overload the victim with ICMP responses and wreak havoc on the system. The other choices do not represent valid broadcasts/protocols used by smurf attacks.

Secure FTP (SFTP) uses Secure Shell (SSH) as the protocol for securing connections between the client and the server. The other protocols listed do not provide this functionality with SFTP.

Port 138 is used by the NetBIOS datagram service. Port 137 is used by the NetBIOS name service. Simple Network Management Protocol (SNMP) uses port 161, while traps use port 162.

IP operates at the Internet layer of the TCP/IP architecture. TCP operates at the host-to-host layer of the TCP/IP architecture. SMTP operates at the application layer of the TCP/IP architecture. UDP operates at the host-to-host layer of the TCP/IP architecture.

While the 802.11 standard defines wireless LANs transmitting at 1Mbps or 2Mbps using the 2.4GHz spectrum, 802.11b provides for bandwidth up to 11Mbps. Both the 802.11a standard and 802.11g standard provide wireless bandwidth of up to 54Mbps, but in different spectrums.

Network File System (NFS) is the default file-sharing protocol for Unix-based systems. Internetwork Packet Exchange/Sequenced Packet Exchange (IPX/SPX) is a networking protocol proprietary to Novell that was used with NetWare 4.x and earlier versions. Network Basic Input Output System (NetBIOS) is the native networking protocol of Windows-based PCs. NetBIOS Extended User Interface (NetBEUI) is used to transport NetBIOS across the LAN.

The FTP control channel is port 21. The FTP data channel is port 20. Telnet uses port 23. Simple Mail Transfer Protocol (SMTP) uses port 25. For more information, see Chapter 3 in the Security+ Study Guide, 4th Edition from Sybex.

Internet Control Message Protocol (ICMP) is used to verify that remote hosts are reachable. File Transfer Protocol (FTP) is used to transfer files from one host to another. Telnet is a protocol/service that allows remote users to access a system using terminal emulation. Domain Name Service (DNS) is used to resolve host names to IP addresses.

To see whether port 25 is available, use Telnet, and give it the address and port number to try: telnet www.edulaney.com 25. All the other options will not perform the desired test.

TCP operates at the host-to-host layer of the TCP/IP architecture, and UDP operates at the host-to-host layer of the TCP/IP architecture. SMTP operates at the application layer of the TCP/IP architecture. IP operates at the Internet layer of the TCP/IP architecture.

Routing Information Protocol (RIP) operates at the application layer of the TCP/IP architecture. All the other options operate at the Internet layer.

Three technologies are used with the 802.11 standard to provide backward compatibility with 802.11b: Direct-Sequence Spread Spectrum (DSS), Orthogonal Frequency Division Multiplexing (ODFM), and Frequency-Hopping Spread Spectrum (FHSS). EGRP is a routing protocol and not used to provide backward compatibility with 802.11b.

The 802.11a standard provides wireless bandwidth of up to 54Mbps in the 5GHz spectrum. The 802.11 standard defines wireless LANs transmitting at 1Mbps or 2Mbps using the 2.4GHz spectrum. The 802.11b standard provides for bandwidth up to 11Mbps in the 2.4GHz spectrum. The 802.11g standard provides for bandwidth up to 54Mbps in the 2.4GHz frequency spectrum.

Simple Network Management Protocol (SNMP) uses port 161, while traps use port 162. Port 137 is used by the NetBIOS name service. Port 138 is used by the NetBIOS datagram service.

A packet filter firewall passes or blocks traffic to specific addresses based on the type of application. A stateful inspection firewall keeps records, in a state table, and tracks every communication channel. A proxy firewall intercepts and examines all packets between the internal and external networks. There is no such firewall type as ACPI.

A site survey involves listening in on an existing wireless network using commercially available technologies. Doing so allows intelligence, and possibly data capture, to be performed on systems in your wireless network. The other terms listed do not imply listening in on an existing wireless network using commercially available technologies.
