    What's the best definition of a resistor?

    • Component made of material that opposes flow of current.
    • A two terminal device that conducts in only one direction.
    • An electrical device used to store electrical charge.
Please wait...
About This Quiz

This quiz covers basics such as Scientific Notation, Engineering Notation, SI prefixes, resistor color codes, capacitors, and vocabulary.

Digital Electronics Quizzes & Trivia

Quiz Preview

  • 2.

    What's the best definition of a digital multimeter?

    • Insulating board containing conductive tracks for circuit connections.

    • A device to measure capacitance, inductance, current gain of transistors, and/or anything else that can be measured electronically.

    • A two terminal device that conducts in only one direction.

    • An electrical device used to store electrical charge.

    Correct Answer
    A. A device to measure capacitance, inductance, current gain of transistors, and/or anything else that can be measured electronically.
    Explanation
    A digital multimeter is a device that is used to measure various electronic properties such as capacitance, inductance, and current gain of transistors. It is capable of measuring any electronic property that can be measured electronically.

    Rate this question:

  • 3.

    What does LED stand for?

    • Low Energy Device

    • Light Energy Diode

    • Low Emitting Device

    • Light Emitting Diode

    Correct Answer
    A. Light Emitting Diode
    Explanation
    LED stands for Light Emitting Diode. This is a semiconductor device that emits light when an electric current is passed through it. LEDs are commonly used in various applications such as lighting, displays, and indicators due to their energy efficiency, long lifespan, and low power consumption.

    Rate this question:

  • 4.

    What is the value of a resistor with a color scheme of Brown, Green, Red, Silver? (order from 0 to 9: black,brown,red,orange,yellow,green,blue,violet,gray,white)

    • 1.6kOhms +-10%

    • 1.5 kOhms +- 10%

    • 2.6 kOhms +- 10%

    • 1.5 kOhms +- 5%

    Correct Answer
    A. 1.5 kOhms +- 10%
    Explanation
    The color scheme of Brown, Green, Red corresponds to the values 1, 5, and 2 respectively. The fourth band, Silver, represents a multiplier of 0.01. Therefore, the value of the resistor can be calculated as (15 * 0.01) kOhms, which is equal to 0.15 kOhms or 150 Ohms. The tolerance of +-10% indicates that the actual value of the resistor can be 10% higher or lower than the stated value. So, the correct answer is 1.5 kOhms +- 10%.

    Rate this question:

  • 5.

    Express the number 469200000 in Scientific Notation.

    • 469.2 x 10^6

    • 469.2 M

    • 4.692 x 10^8

    • 4.692 M

    Correct Answer
    A. 4.692 x 10^8
    Explanation
    The number 469200000 can be expressed in scientific notation as 4.692 x 10^8. In scientific notation, the number is written as a decimal between 1 and 10 (in this case, 4.692) multiplied by 10 raised to a certain power (in this case, 8). This notation is used to represent very large or very small numbers more conveniently.

    Rate this question:

  • 6.

    Express the number 0.054 Amps in SI Notation.

    • 54 mA

    • 5.4 x 10^(-2)A

    • 54 x 10^(-3)A

    • 54 kA

    Correct Answer
    A. 54 mA
    Explanation
    The correct answer is 54 mA. This is because "mA" represents milliamperes, which is a unit of electric current in the International System of Units (SI). 54 mA is equivalent to 0.054 Amps.

    Rate this question:

  • 7.

    What is the value of a resistor with a color scheme of Green, Orange, Brown, Gold? (order from 0 to 9: black,brown,red,orange,yellow,green,blue,violet,gray,white)

    • 6300 Ohms +-5%

    • 4300 Ohms +- 10%

    • 53 Ohms +- 10%

    • 530 Ohms +- 5%

    Correct Answer
    A. 530 Ohms +- 5%
    Explanation
    The resistor with a color scheme of Green, Orange, Brown, Gold has a value of 530 Ohms with a tolerance of +- 5%. The first two bands, Green and Orange, represent the digits 5 and 3 respectively. The third band, Brown, represents the multiplier 10^1. The fourth band, Gold, represents the tolerance of +- 5%. Therefore, the resistor has a value of 53 * 10^1 Ohms, which simplifies to 530 Ohms. The tolerance of +- 5% indicates that the actual value of the resistor can vary by 5% from the stated value of 530 Ohms.

    Rate this question:

  • 8.

    Which of the following should be used to extinguish an electrical fire?

    • Class A fire extinguisher

    • Class B fire extinguisher

    • Class C fire extinguisher

    • None of these

    Correct Answer
    A. Class C fire extinguisher
    Explanation
    A Class C fire extinguisher should be used to extinguish an electrical fire because it is specifically designed to handle fires involving energized electrical equipment. This type of extinguisher contains non-conductive agents that can safely smother the fire without conducting electricity, reducing the risk of electrocution. Using a Class A or Class B fire extinguisher on an electrical fire can be dangerous as it may cause the fire to spread or result in electric shock. Therefore, the correct choice is a Class C fire extinguisher.

    Rate this question:

  • 9.

    What's the best definition of SI notation?Numbers entered as a number from one to ten multiplied by a power of ten.

    • A floating point system in which numbers are expressed as products consisting of a number greater than one multiplied by an appropriate power of ten that is some multiple of three.

    • Numbers entered as a number from one to ten multiplied by a power of ten.

    • Abbreviation of System International, a system of practical units based on the meter, kilogram, second, ampere, Kelvin, mole, and candela.

    Correct Answer
    A. Abbreviation of System International, a system of practical units based on the meter, kilogram, second, ampere, Kelvin, mole, and candela.
    Explanation
    SI notation refers to the abbreviation of System International, which is a system of practical units based on various fundamental quantities such as meter, kilogram, second, ampere, Kelvin, mole, and candela. This system provides a standardized and consistent way of measuring and expressing physical quantities.

    Rate this question:

  • 10.

    Express the number 68100 Volts in Engineering Notation.

    • 68.1 kV

    • 68.1 x 10^3 V

    • 6.81 x 10^4 V

    • 68.1 x 10^(-3) V

    Correct Answer
    A. 68.1 x 10^3 V
    Explanation
    The correct answer is 68.1 x 10^3 V. Engineering notation is used to express numbers in a more convenient and standardized format. In this case, the number 68100 volts is expressed as 68.1 x 10^3 V, where the decimal point is moved three places to the left and the exponent of 10 indicates the number of decimal places moved.

    Rate this question:
