1.
1You work as a desktop support technician at CertKiller.com. The
CertKiller.com network consists of a single Active Directory domain
named CertKiller.com. The CertKiller.com network contains both desktop
and laptop workstations.
You are responsible for managing a desktop workstation named
CERTKILLER-WS620. CERTKILLER-WS620 is configured to run Windows Vista.
You install Windows 7 on a new partition on CERTKILLER-WS620 but you
want Windows Vista to be booted by default on CERTKILLER-WS620 and not
Windows 7.
What should you do?
Correct Answer
A. You should consider running Bcdedit.exe and specifying the /default parameter.
Explanation
To modify the boot parameters in Vista and Windows 7, use the command line tool Bcdedit.exe. Using the /default switch will allow you to set the default system to boot. BCD = Boot Configuration Data You can also change the default boot settings in Control Panel -> System & Security -> System -> Advanced System Settings (on the left hand side), -> Startup & Recovery -> Settings Incorrect answers B: The Boot.ini file is no longer used by Vista or Windows 7.
C: MSCONFIG is not used to specify which operating system to boot. D: Since the boot.ini file is no longer used, the command bootcfg.exe is not applicable.
2.
2You work as a desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. You are responsible for maintaining CertKiller.com's Windows 7 workstations.You want to configure all Windows 7 workstations to produce a new Security ID (SID) as well as a Welcome screen when the workstation is booted.What should you do?
Correct Answer
D. You should consider running Sysprep.exe /oobe /generalize on all Windows 7 workstations.
Explanation
The utility Sysprep is used to prepare systems before imaging and deployment. The switch/ oobe means "Out Of the Box Experience" which will cause the new image to start up fresh just as if in came out of the shrink-wrap. The /generalize command is required in order for the install to create a new SID.
Incorrect Answers:
A: Msconfig is a utility that is used to change the behavior of the boot sequence for diagnostic purposes. This utility is not used in the Windows 7 deployment process. B: Audit mode enables OEMs and corporations to customize a Windows installation before shipping the computer to an end-user. In audit mode, you can install applications, add device drivers, run scripts, and test the validity of a Windows installation. Audit mode is a networked- enabled environment that does not require settings in Windows Welcome to be applied.
C: Bootcfg is not to rebuild a boot.ini file. Boot.ini files are no longer used in Windows 7.
3.
3You work as a desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com.CertKiller.com purchases a new client computer named CERTKILLER-WS680. You have been instructed to perform an automated installation of Microsoft Windows 7 on CERTKILLER-WS680 using the Microsoft Windows 7 DVD.What should you do?
Correct Answer
D. You should consider creating an answer file named autounattend.xml and copying it to a removable drive.
Explanation
When Windows 7 is booted from the DVD, it automatically searches for an answer file called autounattend.xml. If it finds such a file, it will use that to answer all of the configuration questions. Incorrect Answers: B: Winnt.sif is the Windows XP auto-answer file name.
C: The file should be named autounattend.xml not autounattend.sif.
4.
4You work as the desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com.You need to perform a clean installation of Microsoft Windows 7 Professional on the workstations in the Research department. All workstations in the Research department have identical hardware as listed below: 1.2 GHz Dual-Core processor.1024 MB of RAM.20 GB hard drive.DirectX 10 video display card.Integrated sound card.10/100 integrated network adapter.You need to ensure that the workstations able to support Windows 7 and are able to support Windows XP mode.What should you do? (Each correct answer presents part of the solution. Choose two.)
Correct Answer(s)
B. You should upgrade the RAM.
D. You should upgrade the hard drive.
Explanation
Although the workstations meet the system requirements for Windows 7, and additional 1 GB of RAM and an additional 15 GB hard drive space is required to support Windows XP Mode.
5.
5You work as the Desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com.The CertKiller.com management has instructed you to install Microsoft Windows 7 on all the client computers at CertKiller.com. You need to create a Windows 7 image that includes the Office 2007 Microsoft Installer Package (MSI) package for the installation. What should you do?
Correct Answer
C. You should consider installing the MSI package by using the Msiexec command with the /package switch
Explanation
When deploying Windows 7, you first build a reference computer with all settings, configurations and application required. This includes installing applications. To install Office using an MSI file, you run the windows installer program MSIEXEC.EXE. The /package switch directs the installer to run and install the msi file listed. e.g . msiexec /package Office64MUI.msi. The switch /package can be abbreviated to / i as in " msiexec / i Office64MUI.msi". (Yes, / i not /p)
Incorrect Answers:
A: You should use the msiexec command, not the update command. B: You would not run the /uninstall switch with the install command /package. The /uninstall switch uninstalls applications. D: You should use the msiexec command, not the install command.
6.
6CertKiller.com has employed you as a network Administrator. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. You are in the process of planning the installation of Windows 7 on a client computer named CERTKILLER-WS06. CERTKILLER-WS06 contains a single hard disk drive that is connected to a RAID controller.Whilst doing the installation you notice that the installation media of Windows 7 does not include the necessary files to install the RAID controller. You need to make sure that you are able to install Windows 7 on the hard disk drive.What should you do?
Correct Answer
A. You should consider having CERTKILLER-WS04 started from the Windows installation media. Then Load Driver should be clicked from the Install Windows dialog box.
7.
7You work as the network Administrator at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. The CertKiller.com network client computers currently make use of Microsoft Windows XP Professional. You receive an instruction from Management to upgrade a client computer named CERTKILLER-WS25 to Windows 7. You decide to do the installation using the Windows 7 DVD so you log in to CERTKILLER-WS25 and insert the CD.What should you do next? (Choose all that apply. Each answer is a complete solution)
Correct Answer(s)
C. One option would be to run setup.exe from the DVD in order to start a clean Windows 7 installation.
D. One option would be to make use of the autorun feature on the DVD in order to start a clean installation.
Explanation
The correct answers are to run setup.exe from the DVD to start a clean Windows 7 installation and to use the autorun feature on the DVD to start a clean installation. Both of these options will allow for a fresh installation of Windows 7, which is necessary when upgrading from Windows XP Professional. This will ensure that any incompatible or outdated settings from the previous operating system are not carried over, resulting in a more stable and optimized installation of Windows 7.
8.
8You are employed as the network Administrator at CertKiller.com. The CertKiller.com network client computers currently make use of Microsoft Windows XP Professional. CertKiller.com has recently decided to have the client computers upgraded to Microsoft Windows 7 with all the installed applications. You receive an instruction from management to identify the volume types that is not used by Windows 7.
Correct Answer
D. In Windows 7 NFS is not a volume type
Explanation
In Windows 7, NFS is not a volume type. This means that Windows 7 does not support the Network File System (NFS) as a type of volume. NFS is a protocol commonly used for sharing files and directories over a network, typically used in UNIX and Linux environments. However, Windows 7 does not natively support NFS as a volume type, so it cannot be used for sharing files and directories in a Windows 7 environment.
9.
9You are the newly appointed network Administrator at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. The CertKiller.com network client computers currently make use of Microsoft Windows XP Professional. CertKiller.com has recently decided to have the client computers upgraded to Microsoft Windows 7 with all the installed applications. You are in the process of informing the newly appointed users in your department when the Aero Shake feature will work.What should you inform them? (Choose all that apply.)
Correct Answer(s)
A. The Aero Shake feature will work if the Windows Experience Index is 3 or greater.
C. The Aero Shake feature will work if the display adapter is compatible with the installed WDDM.
Explanation
The Aero Shake feature will work if the Windows Experience Index is 3 or greater because this feature requires a certain level of performance from the computer. The Aero Shake feature will also work if the display adapter is compatible with the installed WDDM because the display adapter is responsible for rendering the visual effects of Aero Shake.
10.
10CertKiller.com has hired you as a network Administrator for their network. The CertKiller.com network client computers currently make use of Microsoft Windows XP Professional. You receive an instruction from one of the senior managers to upgrade his workstation to Windows 7. The senior manager also informs you that he wants the Windows 7 games as well as Titan Chess installed on his workstation. You therefore need to identify the Windows 7 versions that will comply with the senior mangers request.What should you do? (Choose all that apply.)
Correct Answer(s)
A. Your best option would be to install Windows Ultimate Edition.
E. Your best option would be to install Windows Enterprise Edition.
Explanation
The correct answer is to install Windows Ultimate Edition and Windows Enterprise Edition. Both of these editions of Windows 7 include the Windows 7 games and Titan Chess, which complies with the senior manager's request. The other editions listed do not include these games, so they would not meet the manager's requirements.
11.
11You work as the network Administrator at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. The CertKiller.com network client computers currently make use of Microsoft Windows XP Professional. CertKiller.com has recently decided to have the client computers upgraded to Microsoft Windows 7. You receive an instruction from the CIO to ensure that the Active Directory domain can be joined by the Windows 7 Edition.What should you do? (Choose all that apply).
Correct Answer(s)
A. Your best option would be to install the Windows Professional Edition.
B. Your best option would be to install the Windows Ultimate Edition.
D. Your best option would be to install the Windows Enterprise Edition.
Explanation
To ensure that the client computers can join the Active Directory domain, the best options would be to install the Windows Professional Edition, Windows Ultimate Edition, and Windows Enterprise Edition. These editions of Windows 7 have the necessary features and capabilities to join an Active Directory domain. The Windows Home Premium Edition, Windows Home Basic Edition, and Windows Starter Edition do not have the required functionality to join an Active Directory domain.
12.
12You are employed as the network Administrator at CertKiller.com. The CertKiller.com network client computers currently make use of Microsoft Windows XP Professional. CertKiller.com has recently decided to have the client computers upgraded to Microsoft Windows 7. You decide to check whether the current workstations comply with the minimum hardware requirements. You therefore need to identify the minimum requirement necessary to install Windows 7.Which of the following are minimum requirements? (Choose all that apply)
Correct Answer(s)
A. You will require a 16 GB available disk space (32-bit)/20 GB (64-bit).
B. You will require a 1 GHz or faster 32-bit (x86) or a 64-bit (x64) processor.
D. You will require a DirectX 9 grapHics processor with WDDM 1.0 or higher driver.
Explanation
The minimum requirements to install Windows 7 are a 16 GB available disk space (32-bit)/20 GB (64-bit), a 1 GHz or faster 32-bit (x86) or a 64-bit (x64) processor, and a DirectX 9 graphics processor with WDDM 1.0 or higher driver. These requirements ensure that the computer has enough storage space, processing power, and graphics capabilities to run Windows 7 smoothly.
13.
13You are employed as the network Administrator at CertKiller.com. The CertKiller.com network client computers are configured to either use Windows XP Professional or Windows Vista. You receive an instruction from management to identify the statement that is regarding Windows 7.What should you do?
Correct Answer
C. You should inform management that Windows 7 does not come with a preinstalled mail client.
Explanation
The correct answer is that Windows 7 does not come with a preinstalled mail client. This means that Outlook Express, Microsoft Mail, and Windows Live Mail are not included with Windows 7. It is important to inform management about this to ensure that they are aware of the limitations and can make appropriate decisions regarding email clients for the network client computers.
14.
14CertKiller.com has hired you as a network Administrator for their network. All servers on the CertKiller.com network run Windows Server 2008. Half the client computers run Windows Vista and the rest Windows XP Professional. You are in the process of identifying the utilities that cannot be identified as a Windows PE tool.What should you identify?
Correct Answer
C. You should consider identifying Subinacl
Explanation
The correct answer is "You should consider identifying Subinacl". Subinacl is a command-line tool that is used to manage security information on Windows systems. It is not a Windows PE (Preinstallation Environment) tool, which is a lightweight version of Windows that is used for deployment and recovery purposes. Therefore, Subinacl does not belong to the category of utilities that cannot be identified as a Windows PE tool.
15.
15You are the newly appointed network Administrator at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. The CertKiller.com network client computers currently make use of Microsoft Windows XP Professional. You receive an instruction from the CIO to install Windows 7 on a computer named CERTKILLER-SR01. During a test installation you discover that the Online Compatibility Check has failed. You therefore need to determine the reason this occurred.What should you identify? (Choose all that apply.)
Correct Answer(s)
B. The error occurred due to a display adapter without WDDM Support but with SVIDEO Support.
C. The error occurred due to 512MB of RAM.
Explanation
The error occurred due to a display adapter without WDDM Support but with SVIDEO Support because Windows 7 requires a display adapter with WDDM (Windows Display Driver Model) support in order to function properly. The error also occurred due to 512MB of RAM because Windows 7 requires a minimum of 1GB of RAM to run smoothly.
16.
16You work as a network administrator at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. The servers on the network run Microsoft Windows Server 2008 and the client computers run Microsoft Windows 7.During the course of the day you receive instruction from CertKiller.com to create an unattended answer file which will be used to have Microsoft Windows 7 installed automatically. CertKiller.com additionally requested that you select the appropriate utilities that can be used to create the unattended answer file.What should you do? (Choose two)
Correct Answer(s)
C. You should consider making use of the Windows SIM tool in Windows AIK.
D. You should consider making use of Microsoft Notepad.
Explanation
The Windows SIM tool in Windows AIK (Automated Installation Kit) is used to create unattended answer files for Windows installations. It allows you to customize various settings and configurations that will be applied during the automated installation process. Microsoft Notepad is also a suitable utility for creating and editing the answer file as it is a simple text editor that can be used to modify the XML-based answer file. Both of these utilities are commonly used in the process of creating unattended answer files for automated Windows installations.
17.
17You work as a network administrator at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. The servers on the network run Microsoft Windows Server 2008 and the client computers run Microsoft Windows Vista (x86).During the course of the day you receive instruction from CertKiller.com to perform a clean installation of Microsoft Windows 7 (64-bit) on a user named Rory Allen's computer.What should you do?
Correct Answer
B. You should consider having the computer started using the Windows 7 installation media. You should then select the Custom (advanced) option from the Install Windows dialog box.
Explanation
Part 2: Upgrade to Windows 7 from previous versions of Windows (10 Questions)
18.
18You work as a desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com.A CertKiller.com user named Rory Allen uses of a Microsoft Windows 7 Professional client computer named CERTKILLER-WS680. During the course of the day Rory Allen attaches a USB disk to CERTKILLER-WS680. However, Rory Allen cannot enable BitLocker To Go on the USB disk. You need to ensure that Rory Allen can enable BitLocker To Go on the USB disk.What should you do?
Correct Answer
A. You should consider upgrading CERTKILLER-WS680 to Microsoft Windows 7 Ultimate.
Explanation
Explanation:
BitLocker To Go is a feature ONLY available on Windows 7 Ultimate and Windows 7 Enterprise.
Incorrect Answers:
B: A Trusted Platform Module is required for BitLocker but won't help in this scenario. C: BitLocker uses a single encryption key that is either stored locally in the TLM or on a separate removable drive. Certificates are neither used nor required since Bitlocker does not use Public Key encryption. D: IPSEC is used to encrypt network data, not drives.
19.
19You work as a desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. All client computers on the CertKiller.com network run Windows XP Professional with Service Pack 1 (SP1).You have been assigned a client computer named CERTKILLER-WS270. You want to upgrade CERTKILLER-WS270 to Windows 7 Professional without needing to install any of your applications. You verify that CERTKILLER-WS270 meets the system requirements for Windows 7 by installing and running the Windows 7 Upgrade Advisor.What should you do next?
Correct Answer
A. You should consider upgrading CERTKILLER-WS270 to Microsoft Windows Vista Business, and then upgrade it to Windows 7 Professional.
Explanation
To upgrade from Windows XP Professional to Windows 7 Professional without having to reinstall applications, you would need to upgrade to Windows Vista first.
20.
20You work as a desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. The client computers on the CertKiller.com network run a mix of Windows 2000 Professional with Service Pack 4 (SP4), Windows XP Professional with Service Pack 3 (SP3), Windows Vista Business and Windows Vista Ultimate.You have received instructions to upgrade some of the client computers to Windows 7 Professional.What should you do?
Correct Answer
C. You should consider upgrading the Microsoft Windows Vista Business computers to Windows 7 Professional
Explanation
Only Windows Vista Business can be upgraded to Windows 7 Professional.
21.
21You work as the desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. All client computers on the CertKiller.com network run Windows Vista Business.You have been instructed to upgrade a client computer named CERTKILLER-WS620 to Microsoft Windows 7 Professional. CERTKILLER-WS620 has the following specifications: Drive C (system drive) has 12 gigabytes (GB) of free space.Drive D (data drive) has 40 GB of free space. Four memory slots with two occupied by 512 megabyte (MB) memory sticks. One 2.0 gigahertz (GHz) 32-bit processor.You need to ensure that Windows 7 Professional can be installed on CERTKILLER-WS620.What should you do?
Correct Answer
B. You should consider creating more free space on Drive C.
Explanation
During an upgrade, the Operating Systems must be installed on the system drive. However, the system drive on CERTKILLER-WS620 has only 12 GB of free space. Therefore you should free up space on Drive C because Windows 7 requires 16 GB of free space for installation purposes.
22.
22You work as the desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. All client computers on the CertKiller.com network run Windows XP Professional.You have been instructed to upgrade the Windows XP Professional client computers to Windows 7. However, before you proceed you need to determine if the current applications on the Windows XP Professional computers will run on Windows 7. You want to accomplish this task using the least amount of administrative effort.What should you do?
Correct Answer
A. You should run the Application Compatibility Toolkit (ACT) 5.5.
Explanation
Application Compatibility Toolkit (ACT) 5.5 collects information about the applications that are installed on the network computers and provides information about the applications that are incompatible with Windows Vista. Windows Vista Upgrade Adviser can also be used for the same purpose but it requires a massive amount of administrative effort because it needs to be run separately on each computer.
23.
23You are employed as the network Administrator at CertKiller.com. The CertKiller.com network client computers currently make use of Windows Vista Enterprise (x86). You are responsible for managing a client computer named CERTKILLER-WS20. During the course of the day you receive instructions from CertKiller.com to identify the Windows 7 version and edition CERTKILLER-WS20 can directly upgrade to.What should you do?
Correct Answer
D. Your best option would be to make use of Windows 7 Ultimate (x86).
Explanation
The client computer, CERTKILLER-WS20, is currently running Windows Vista Enterprise (x86). To upgrade to Windows 7, the best option would be to choose a version and edition that is compatible with the current operating system. In this case, Windows 7 Ultimate (x86) is the best option as it matches the current version and edition of Windows Vista.
24.
24You work as the network Administrator at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. You are in the process of determining when you need to execute a migration rather that an upgrade.Select all answers that apply.
Correct Answer(s)
A. Your best option would be to migrate Windows Vista Business (x86) to Windows 7 Professional (x64).
D. Your best option would be to migrate Windows Vista Home Premium (x64) to Windows 7 Home Premium (x86).
E. Your best option would be to migrate Windows XP Professional (x64) to Windows 7 Professional (x64).
Explanation
The correct answers for this question are based on the compatibility and upgrade paths between different versions of Windows. In this case, the best option for migration is to upgrade from Windows Vista Business (x86) to Windows 7 Professional (x64) because both versions are the same edition (Professional) and the migration is from a 32-bit to a 64-bit architecture. Additionally, migrating from Windows Vista Home Premium (x64) to Windows 7 Home Premium (x86) is also a valid option because it is the same edition and the migration is from a 64-bit to a 32-bit architecture. Finally, migrating from Windows XP Professional (x64) to Windows 7 Professional (x64) is another valid option because it is the same edition and the migration is within the same 64-bit architecture.
25.
25You are the newly appointed network Administrator at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. You are responsible for a computer named CERTKILLER-WS04. CERTKILLER-WS04 is configured to run Windows Vista Service Pack 2 (SP2). During the course of the week you receive an instruction from the CIO to have CERTKILLER-WS04 upgraded to Windows 7.How would you do this?
Correct Answer
D. This can be accomplished from Windows Vista by running Setup.exe from the Windows 7 installation media. Thereafter the Upgrade option should be selected.
Explanation
The correct answer explains that to upgrade CERTKILLER-WS04 from Windows Vista to Windows 7, the network administrator needs to run Setup.exe from the Windows 7 installation media on the Windows Vista machine. After running Setup.exe, the administrator should select the Upgrade option to perform the upgrade.
26.
26You work as a network administrator at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com.The servers on the network run Microsoft Windows Server 2008 and the client computers run Microsoft Windows 7.A CertKiller.com employee named Rory Allen has a computer at home with a cable modem connection. Rory Allen has recently requested that you guide him by selecting the appropriate method to upgrade from Microsoft Windows 7 Home Premium to Microsoft Windows 7 Ultimate.What should you do?
Correct Answer
B. You should instruct Rory Allen that Windows Anytime Upgrade can be used.
27.
27You work as a network administrator at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. The servers on the network run Microsoft Windows Server 2008 and the client computers run Microsoft Windows Vista. During the course of the day a network user named Mia Hamm asked you which of the Microsoft tools can be used to determine if your installed applications have known problems with Microsoft Windows 7.What should you do?
Correct Answer
C. You should consider instructing Mia Hamm that the Windows 7 Upgrade Advisor Microsoft tool can be used.
Explanation
Part 3: Migrate user profiles (5 Questions)
28.
28You work as a desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com.You are responsible for managing a workstation named CERTKILLER-WS624. CERTKILLER- WS624 is configured to run Windows Vista and contains an accounting application named accapp.exe. CertKiller.com purchases a new Windows 7 workstation that will replace CERTKILLER-624. You need to export the user state as well as the settings of the accapp.exe application so that it can be migrated to the Windows 7 workstation.What should you do?
Correct Answer
A. You should consider modifying the migapp.xml file on CERTKILLER-WS624 and then run Scanstate.exe with the /i parameter.
Explanation
In order to migrate a user from Vista to Windows 7run the User State Migration toolkit (USMT). ScanState collects the files and settings from the source computer. Run LoadState to restore the user state onto the destination computer. Incorrect Answers:
B: USMT is not the correct tool to use. C: /migapp is not a valid switch for Scanstate.exe. D: Migapp.exe is not the correct tool to use.Reference: http://technet.microsoft.com/en- us/library/cc721992(
29.
29You work as a desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. You are assigned two workstations named CERTKILLER-WS625 and CERTKILLER-WS680. CERTKILLER-WS625 is configured to run Windows Vista and CERTKILLER-WS680 is configured to run Windows 7.You receive an instruction to migrate the user files and profiles from CERTKILLER-WS625 to CERTKILLER-WS680. To accomplish this you want to determine the amount space needed to accomplish the migration.What should you do?
Correct Answer
B. You should consider running Scanstate c:\store /nocompress /p on CERTKILLER-WS625.
Explanation
You should use the Scanstate command. /p Generates a space-estimate file called Usmtsize.txt that is saved to StorePath . This option does not collect the user state. You must also specify / nocompress . The command must be run locally on CERTKILLER625 (The source computer). The storage location may be on the network or local.
Incorrect Answers:
A: USMT is not the correct command. C: migapp is not the correct command. D: Sysprep is not the correct command.
30.
30You work as the Desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. The CertKiller.com network contains 300 Windows XP Professional workstations and 200 Windows Vista Ultimate workstations.You have been instructed to migrate all Windows XP Professional workstations to Windows 7 Ultimate. You need to ensure that user files and setting are retained. However, several CertKiller.com users have used Encrypting File System (EFS) to encrypt their user files. You therefore need to migrate the Encrypting File System (EFS) encrypted files and certificates. InMicrosoft 70-680: Practice Examaddition you need to ensure that you are able to encrypt the migration store during the migration.What should you do?
Correct Answer
A. On Windows XP make use of the User State Migration Tool (USMT) 3.0.
Explanation
USMT 3.0 or higher should be used on Windows XP to migrate EFS files and certificates and also encrypt the migration store. With USMT 3.0 you can specify the / efs :copyraw switch to automatically migrate the EFS files and certificates to the destination computer that is running Windows Vista. To encrypt the store, you should use the /encrypt switch.
31.
31You work as the Desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. You have been instructed to perform a clean installation of Microsoft Windows 7 on the CertKiller.com client computers that are currently running Microsoft Windows Vista.You need to be able to migrate user data and settings to Windows 7. The computers running Windows Vista currently have a single partition of 80 GB with 60 GB of free disk space. You need to use the User State Migration Tool (USMT) to migrate user state data while keeping network traffic to a minimum.What should you do?
Correct Answer
C. You should use third-party tools to resize the 80 GB partition and create a second partition to store the user data.
Explanation
Resizing the 80 GB partition with a third-party tool and creating a second partition to store the user state data will keep the network traffic to a minimum. If you want to store user state data on a network share and the computer does not have a secondary partition, you should resize the partition.
32.
32You work as a network administrator at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. The servers on the network run Microsoft Windows Server 2008 and the client computers run Microsoft Windows 7. During the course of the day a network user named Dean Austin asked you which of the Microsoft operating systems supports offline migration using USMT.What should you do? (Choose all that apply)
Correct Answer(s)
A. You should consider instructing Dean Austin that Microsoft Windows Vista supports offline migration using USMT
B. You should consider instructing Dean Austin that Microsoft Windows XP Professional with SP2 or later supports offline migration using USMT.
C. You should consider instructing Dean Austin that Microsoft Windows XP Professional supports offline migration using USMT.
D. You should consider instructing Dean Austin that Microsoft Windows 7 supports offline migration using USMT.
Explanation
The correct answer is that Microsoft Windows Vista, Microsoft Windows XP Professional with SP2 or later, Microsoft Windows XP Professional, and Microsoft Windows 7 all support offline migration using USMT.
33.
33You work as a desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com.You are busy with a deployment of an image of a computer. You have created an answer file named answer.xml. You want to ensure that the installation applies the answer file after the deployment of the image.What should you do?
Correct Answer
B. You should consider running Sysprep.exe /generalize /oobe /unattend:answer.xml before you capture the image
Explanation
The System Preparation ( Sysprep ) tool prepares an installation of Windows 7 for duplication, auditing, and customer delivery. You can use an answer file with Sysprep to configure unattended Setup settings. The /generalize command removes any machine specific attributes such as the Security ID (SID).
The / oobe command tells the image to start with the normal "Out-Of-The-Box" experience. Just as if you bought a retail new copy.
The / unattend : command tells the image to use the answer file
Incorrect Answers:
D: You don't run setup.exe to use an answer file.
34.
34You work as a desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. The CertKiller.com network contains 120 workstations.CertKiller.com is currently in the process of migrating all of its workstations to Windows 7. In preparation of the migration, you have installed Windows 7 on a computer named CERTKILLER- WS680. You now need to create an image of CERTKILLER-WS680, which will be deployed to all workstations on the CertKiller.com network.What should you do before creating the image on CERTKILLER-WS680?
Correct Answer
A. You should consider running the System Preparation tool (Sysprep)
Explanation
Sysprep is used to prepare the image to be installed on other machines. Sysprep will remove the SID, Reset the Activation to 30 days, add an answer file if desired and reset the install to an "Out-Of-The-Box" experience.
Any method of moving a Windows image to a new computer, either through imaging, hard disk duplication, or other method, must be prepared with the sysprep /generalize command. Moving or copying a Windows image to a different computer without running the Sysprep /generalize command is not supported.
The following command-line options are available for Sysprep : sysprep.exe [ / oobe | /audit ] [ /generalize ] [ /reboot | /shutdown | /quit ] [ /quiet ] [ / unattend : answerfile ] Incorrect Answers: B: RIS was used in Windows 2000. It is not required here. C: It is not necessary to disable the System Protection settings. D: WDS is a server service. It is not something you run on a workstation prior to taking an image.
35.
35You work as the Desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. You have been instructed to deploy Microsoft Windows 7 on all of the CertKiller.com client computers.You have installed Windows Automated Installation Kit (Windows AIK) on a reference computer. You then created an answer file for a Windows 7 unattended installation. You now need to validate the answer file before deploying Windows 7 to the CertKiller.com client computers.What should you do?
Correct Answer
D. You should consider using the Windows System Image Manager (Windows SIM) tool.
Explanation
The Windows SIM tool is used to create an answer file, as well as to validate the answer file to ensure that the file is working.
36.
36You work as the Desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com.You have been instructed to deploy Microsoft Windows 7 on all the CertKiller.com client computers. You want to deploy Windows 7 on the client computers in unattended mode. You install Windows 7 on a reference computer named CERTKILLER-WS680 that will be used to build a master image. You then manually create the answer file that will be required for the unattended installation.What should you do next?
Correct Answer
C. You should use Windows System Image Manager (Windows SIM) to validate the answer file.
Explanation
When manually creating an answer file, you should always validate the answer file using SIM. Validating will ensure that the values in the answer file are correct. If you neglect to validate after manually creating the answer file, you may encounter errors when deploying Windows 7 and will then have to validate the answer file.
Incorrect answers : A : Sysprep.exe is used to prepare CERTKILLER-WS680 after validating the answer file. B : ImageX is used to capture the image after preparing CERTKILLER-WS680. It is not used after manually creating the answer file. D : Setup Manager Tool or Setupmgr.exe is used in earlier versions of Windows operating systems.
37.
37You work as the Desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. You have received instructions to deploy Windows 7 on all the CertKiller.com client computers that have CD-ROM drives.You decide to create a custom Windows 7 image on spanned media using the Createspannedshares.cmd script. However, you are unable run the Createspannedshares.cmd script.What should you do?
Correct Answer
B. You should consider installing Windows Automated Installation Kit (Windows AIK) prior to creating the spanned media
Explanation
To be able to create the spanned media to install Windows 7 on the CD-ROM client computers you need to install Windows AIK on a computer from where you plan to create the spanned media. Only after the installation of Windows AIK will you be able to run the Createspannedshares.cdm script to create the spanned media.
38.
38You work as the Desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com.The CertKiller.com management has instructed you to install Microsoft Windows 7 on all the client computers at CertKiller.com. You have installed Windows Deployment Service (WDS) on a server named CERTKILLER-SR05. You want to use a client computer named CERTKILLER-WS680 as a reference computer from which you want to create the image for the deployment. You now need to remove hardware-specific information from the Windows installation on CERTKILLER-WS680.What should you do?
Correct Answer
A. You should consider running the Sysprep.exe utility with the /oobe and /generalize switches on CERTKILLER-WS680.
Explanation
Part 2: Prepare a system image for deployment (4 Questions)
39.
39You work as the Desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. The CertKiller.com network contains 5 Windows Server 2008 servers, 200 Windows Vista Business client computers and 300 Windows 7 Professional client computers.You have been instructed to deploy Microsoft Windows 7 on the 200 Windows Vista Business client computers. There is an existing offline Windows 7 image on a client computer named CERTKILLER-WS680. However, you need to add updated device drivers to this image.What should you do?
Correct Answer
E. You should consider using the Deployment Image Servicing and Management (DISM) tool.
Explanation
The Deployment Image Servicing and Management (DISM) tool replaces the Pkgmgr.exe utility and is used to update images by adding or removing device drivers and language packs, enabling or disabling Windows features, and adding and configuring Windows updates. Incorrect Answers:
D: Windows SIM is used to create answer files. It is not used to update existing images.
40.
40You work as the Desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. CertKiller.com has its headquarters in London and a regional office in New York. All client computers on the CertKiller.com network run Windows 7 Ultimate. You are responsible for managing CertKiller.com's operating system deployment images.CertKiller.com is in the process of opening a European regional office in Rome. You are required to ensure that a Windows 7 image with support for Italian is available for deployment in the Rome office.What should you do?
Correct Answer
D. You should consider using the Windows System Image Manager (Windows SIM) to create an answer file and then use the Deployment Image Servicing and Management (DISM) tool to apply it to the Windows 7 image
Explanation
The Deployment Image Servicing and Management (DISM) tool allows you to add or remove packages to or from an offline image or an image that is currently running on a computer. You can also add or remove Windows features, apply unattended installation answer file settings, and perform the offline installation of language packs and out-of-box driver packages specified in an answer file.
41.
41You work as the Desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. CertKiller.com has its headquarters in London and a regional office in New York. All client computers on the CertKiller.com network run Windows 7 Ultimate. You are responsible for managing CertKiller.com's operating system deployment images.CertKiller.com is in the process of opening a European regional office in Rome. You are required to ensure that support for Italian is available for the Windows 7 deployment in the Rome office. However, you need to install the Italian language pack without editing the Windows 7 image.What should you do?
Correct Answer
B. You should consider copying the Italian language pack to the Windows distribution folder.
Explanation
To ensure support for Italian in the Windows 7 deployment in the Rome office without editing the Windows 7 image, it is recommended to copy the Italian language pack to the Windows distribution folder. This will allow the language pack to be installed during the deployment process without modifying the original image. By copying the language pack to the distribution folder, it will be available for installation on the client computers in the Rome office.
42.
42You are employed as the network administrator at CertKiller.com. The CertKiller.com network contains 150 client computers currently running Microsoft Windows XP Professional.CertKiller.com has recently decided to deploy Windows 7 to 80 client computers on the CertKiller.com network. You decide to install Windows 7 on a computer named CERTKILLER- WS06 and prepare it to be imaged. You therefore need to determine what you should be doing prior to creating the image of CERTKILLER-WS06.What should you do?
Correct Answer
C. You should consider running Sysprep.
Explanation
Part 3: Deploy a system image (4 Questions)
43.
43You work as the desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. The CertKiller.com network contains two Windows Server 2008 computers named CERTKILLER-SR01 and CERTKILLER-SR02 and 500 Windows Vista Ultimate client computers. CERTKILLER-SR01 functions as a Domain Controller (DC) while CERTKILLER-SR02 functions as a Domain Name System (DNS) server.CertKiller.com purchases 200 new client computers that have the following resources: 2.33 GHz Dual-Core processor.2 GB of RAM.80 GB hard drive.DirectX 10 video display card.Integrated sound card.10/100/1000 integrated network adapter.You need to perform a clean installation of Microsoft Windows 7 Ultimate on the new client computers. You use one of the new client computers as a reference computer from which you build a custom image and an answer file. You want to deploy the image to the new client computers over the network using Windows Deployment Services (WDS).What should you do?
Correct Answer
B. You should install a Dynamic Host Configuration Protocol (DHCP) server on the network
Explanation
The network must have a DHCP server with an active scope as Windows Deployment Services uses PXE, which relies on DHCP for IP addressing.
44.
44You work as the Desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. You have been instructed to deploy Microsoft Windows 7 on all the CertKiller.com client computers.You use a client computer named CERTKILLER-WS680 as a reference computer to create a custom image and an answer file that will be used to automate the deployment of Windows 7 on the client computers. You want to complete the task with the least amount of administrative effort.What should you do?
Correct Answer
B. You should consider installing the Windows Automated Installation Kit (Windows AIK) on CERTKILLER-WS680
Explanation
WAIK is a set of tools that will aid you in deploying Windows 7 on target computers. You can create an answer file and capture an image of a reference computer by making use of Windows AIK.
Incorrect answers : A : Installing SMS OSD feature pack on CERTKILLER-WS680 will help to prepare the reference computer to capture an image to be deployed on all computers, but this approach will require more administrative time and effort than making use of Windows AIK. C : Windows SIM is used to create answer file to automate Windows 7 deployment and is a part of Windows AIK. Windows SIM does not create a custom image. D : The ImageX command-line utility is used to capture volume images to the Windows Imaging Format (WIM) file and is a part of Windows AIK. ImageX does not create an answer file.
45.
45You work as the Desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. You have been instructed to deploy Microsoft Windows 7 on CertKiller.com client computers that do not support PXE.You install Windows Deployment Service (WDS) on a server named CERTKILLER-SR05 and create a discover image for the deployment. You now need to identify the best method for creating bootable media that will be used to deploy Windows 7 on the non-PXE supporting client computers.What should you do?
Correct Answer
B. You should consider installing the Windows Automated Installation Kit (Windows AIK) on CERTKILLER-SR05.
Explanation
Bootable media that will be used to deploy Windows 7 to client computers must be created after a discover image is created. WAIK will provide the tools that are required to create the bootable media.
46.
46You work as a Desktop support technician at CertKiller.com. You have been assigned the task of installing Windows 7 on 10 network computers using custom WIM image.You have the Windows Automated Installation Kit (Windows AIK) installed on one of the computers. You now want to create a WinPE CD to capture or apply the custom WIM image of Windows 7 from the master computer.What should you do? (Each correct answer presents part of the solution. Choose three.)
Correct Answer(s)
B. You should run Copype.cmd to install Windows PE to a directory and then copy the imagex.exe file to ISO folder under WinPE_x86 directory
C. You should create wimscript.ini configuration file in notepad. Save the file in the same directory as imagex.exe.
E. You should run Oscdimg.exe to create an ISO image of WinPE. Burn the image on a CD.
Explanation
To create a WinPE CD and to initiate Windows 7 installation using a custom WIM image of Windows 7, you need to first run Copype.cmd to install Windows PE to a directory and then copy the imagex.exe file to ISO folder under WinPE_x86 directory, then create wimscript.ini configuration file in notepad and save the file in the same directory as imagex.exe, and then finally run Oscdimg.exe to create an ISO image of WinPE and then burn the image on a CD.
Part 4: Configure a VHD (6 Questions)
47.
47You work as a desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com.The CertKiller.com network contains a client computer named CERTKILLER-WS679 with a Virtual Hard Disk (VHD). You have installed Windows 7 on the Virtual Hard Disk (VHD). You now want to boot CERTKILLER-WS679 from the Virtual Hard Disk (VHD).What should you do?
Correct Answer
C. Ou should consider running the Bcdedit.exe command and modifying the Windows Boot Manager settings.
Explanation
If you are deploying the VHD to a computer with an existing Windows7 or Windows Server®2008R2 installation, you can use the BCDedit tool to make the new VHD bootable and add it to the boot menu. Using BCDedit , you obtain the GUID from the VHD boot disk and then using BCDedit , set that GUID to be the default boot device.
Incorrect Answers:
A: Msconfig does not set the boot order. B: The boot.ini file is no longer used in Windows 7.
48.
48You work as a desktop support technician at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com.You have created a Virtual Hard Disk (VHD) with a disk image that you want to add to a client computer named CERTKILLER-WS680. You have copied the VHD to CERTKILLER-WS680 and attached it using the attach vdisk command. You now want to add the Virtual Hard Disk (VHD) to the Windows 7 boot menu.What should you do?
Correct Answer
C. You should consider using the BCDboot utility to copy the boot environment files and Boot Configuration Data (BCD) configuration from the \Windows directory in the VHD to CERTKILLER- WS680
Explanation
To deploy a VHD image: 1. On the source computer, use the Diskpart tool to create, attach, partition, and format a new virtual hard disk. 2. Use Use ImageX to apply the . wim file to the primary partition of the VHD. 3. Use the DiskPart tool to detach the virtual disk after applying the image. Copy the VHD file to a network share or USB hard drive 4. Boot the target computer with Boot PE and prepare the hard drive using Diskpart 5. Copy the VHD to the drive and attach using Diskpart 6. Use the BCDboot tool, located in the \System32 directory of the Windows7 VHD or in a Windows®7 WindowsPE media, to copy the boot-environment files from the \Windows directory in the VHD to the system partition. The BCDboot tool will create the BCD configuration to boot from the VHD. 7. Use Diskpart to detach the VHD and then restart the computer.
Incorrect Answers:
A: Sysprep is not used to configure boot partitions. B: Disk Manager is used to allocate space and partition drives.
49.
49You work as the network Administrator at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. CertKiller.com has acquired a new computer named CERTKILLER-WS25 that has no operating system (OS) installed.There is a virtual hard disk (VHD) in your department that contains an installation of Windows 7. You therefore decide to start CERTKILLER-WS25 from the Windows Preinstallation Environment (Windows PE). You then create a partition on CERTKILLER-WS25 and copy the VHD to it. Your next step is to configure CERTKILLER-WS25 to start from the virtual hard disk.What should you do?
Correct Answer
D. Your best options would be to make use of Diskpart.exe and Bcdboot.exe.
50.
50You work as a network administrator at CertKiller.com. The CertKiller.com network consists of a single Active Directory domain named CertKiller.com. The servers on the network run Microsoft Windows Server 2008 and the client computers run Microsoft Windows 7.During the course of the day you receive instruction from CertKiller.com to create a 20-GB native VHD which will be named KingSystem located in a folder KingWindows which resides on an external hard disk assigned the H: drive designation.What should you do?
Correct Answer
D. You should consider making use of the create vdisk file=h:\kingwindows\kingsystem.vhd maximum=20000 command.
