VESDA-E Technical Accreditation Quiz!

Approved & Edited by ProProfs Editorial Team
The editorial team at ProProfs Quizzes consists of a select group of subject experts, trivia writers, and quiz masters who have authored over 10,000 quizzes taken by more than 100 million users. This team includes our in-house seasoned quiz moderators and subject matter experts. Our editorial experts, spread across the world, are rigorously trained using our comprehensive guidelines to ensure that you receive the highest quality quizzes.
Learn about Our Editorial Process
| By Hkhalifa
H
Hkhalifa
Community Contributor
Quizzes Created: 4 | Total Attempts: 1,023
Questions: 30 | Attempts: 238

SettingsSettingsSettings
Accreditation Quizzes & Trivia

Questions and Answers
  • 1.

    The VESDA-E has a number of detector display options. Those options are:

    • A.

      LEDs only

    • B.

      3.5 inch touch screen display

    • C.

      7 inch touch screen display

    • D.

      All of the above

    Correct Answer
    D. All of the above
    Explanation
    The VESDA-E offers multiple detector display options, including LEDs only, a 3.5 inch touch screen display, and a 7 inch touch screen display. Therefore, the correct answer is "All of the above."

    Rate this question:

  • 2.

    The VESDA-E has a new detection chamber called the flair chamber. The Flair chamber was built on Xtralis’ core competencies of Image processing, optics, interpretation of light and:

    • A.

      Video Transmission

    • B.

      Air Sampling

    • C.

      Electronics manufacturing

    • D.

      Particle Counting

    Correct Answer
    B. Air Sampling
    Explanation
    The correct answer is Air Sampling. The VESDA-E has a new detection chamber called the flair chamber, which utilizes air sampling as a method of detecting particles in the air. This chamber is built on Xtralis' core competencies of image processing, optics, and interpretation of light, but the crucial aspect of the chamber is its ability to sample the air and analyze it for any potential threats or hazards.

    Rate this question:

  • 3.

    The VESDA-E has the greatest sensitivity range of any Xtralis air sampling smoke detector to date. The VESDA-E sensitivity range is:

    • A.

      0.0015-6.25%obs/ft (0.005-20%obs/m)

    • B.

      0.0003-6.25%obs/ft (0.001-20%obs/m)

    • C.

      0.008-6.25%obs/ft (0.025-20%obs/m)

    • D.

      None of the above

    Correct Answer
    B. 0.0003-6.25%obs/ft (0.001-20%obs/m)
    Explanation
    The correct answer is 0.0003-6.25%obs/ft (0.001-20%obs/m). This is because the VESDA-E has the greatest sensitivity range among all Xtralis air sampling smoke detectors. The sensitivity range refers to the ability of the detector to detect smoke particles in the air. The wider the range, the more sensitive the detector is to detecting even small amounts of smoke. Therefore, the VESDA-E has the ability to detect smoke particles ranging from 0.0003%obs/ft to 6.25%obs/ft, or from 0.001%obs/m to 20%obs/m.

    Rate this question:

  • 4.

    The VESDA-E Fire 1 Alarm Threshold can be more sensitive than the VLP Fire 1 Alarm Threshold by:

    • A.

      100 times

    • B.

      50 percent

    • C.

      25 Pascals

    • D.

      15 times

    Correct Answer
    D. 15 times
    Explanation
    The VESDA-E Fire 1 Alarm Threshold is 15 times more sensitive than the VLP Fire 1 Alarm Threshold. This means that the VESDA-E system can detect smoke or fire at a much lower concentration or pressure level compared to the VLP system. This increased sensitivity allows for earlier detection of potential fire hazards, providing more time for evacuation or intervention measures to be taken.

    Rate this question:

  • 5.

    Inherent Absolute Calibration, particle classification, and operating temperature stability are some of the ways the VESDA-E detection chamber achieves its superior detection reliability.

    • A.

      True

    • B.

      False

    Correct Answer
    A. True
    Explanation
    The statement suggests that the VESDA-E detection chamber achieves superior detection reliability through various means such as Inherent Absolute Calibration, particle classification, and operating temperature stability. This indicates that the VESDA-E detection chamber has been designed with features that enhance its ability to accurately detect particles and maintain stable performance regardless of temperature fluctuations. Therefore, the statement is true.

    Rate this question:

  • 6.

    The enclosure for the VESDA-E was designed for both aesthetics and durability. The VESDA-E enclosure is:

    • A.

      Made of durable plastic with an IP rating of 40

    • B.

      Made of brushed aluminum with an IP rating of 40

    • C.

      Made of Stainless steel with an IP rating of 40

    • D.

      None of the above

    Correct Answer
    B. Made of brushed aluminum with an IP rating of 40
  • 7.

    The VESDA-E was designed for the ease of cable entry and interconnection wiring to external monitoring devices by the use of a hinged door on the fascia, removable wiring terminals, and:

    • A.

      4 sealed conduit knockouts

    • B.

      4 removable conduit access points

    • C.

      2 sealed conduit knockouts

    • D.

      2 removable conduit access points

    Correct Answer
    B. 4 removable conduit access points
    Explanation
    The VESDA-E has been designed to facilitate cable entry and interconnection wiring to external monitoring devices. It achieves this through a hinged door on the fascia, removable wiring terminals, and 4 removable conduit access points. These access points allow for easy installation and maintenance of the wiring, ensuring a seamless and efficient connection between the VESDA-E and the external monitoring devices.

    Rate this question:

  • 8.

    The single-stage replaceable air sampling filter on the VESDA-E is designed to filter out larger particles above what size?

    • A.

      60 Micron

    • B.

      30 Micron

    • C.

      20 Micron

    • D.

      10 Micron

    Correct Answer
    C. 20 Micron
    Explanation
    The single-stage replaceable air sampling filter on the VESDA-E is designed to filter out larger particles above 20 Micron in size.

    Rate this question:

  • 9.

    The single-stage filter has a chip fitted which registers the following:

    • A.

      Type of filter inserted.

    • B.

      Total smoke hours.

    • C.

      Total dust count.

    • D.

      All of the above.

    Correct Answer
    D. All of the above.
    Explanation
    The single-stage filter has a chip fitted that registers the type of filter inserted, the total smoke hours, and the total dust count. This means that the chip is capable of recording all of the mentioned information, making the answer "All of the above" correct.

    Rate this question:

  • 10.

    The inlet manifold on the VESDA-E utilizes Ultrasonic Flow Sensors per inlet Pipe for precise sampled airflow monitoring. The Ultrasonic Flow sensors then allow the VESDA-E to provide how many programmable flow faults?

    • A.

      Two - High air flow and Low air flow

    • B.

      Four - Major High, Major Low, Minor High, Minor Low

    • C.

      One – General Flow Fault

    • D.

      Sixteen – Major High, Major Low, Minor High, Minor Low per individual inlet pipe

    Correct Answer
    D. Sixteen – Major High, Major Low, Minor High, Minor Low per individual inlet pipe
    Explanation
    The correct answer is Sixteen – Major High, Major Low, Minor High, Minor Low per individual inlet pipe. The explanation is that the VESDA-E system utilizes Ultrasonic Flow Sensors per inlet pipe, which allows for precise sampled airflow monitoring. These sensors are able to detect and provide information on various flow faults, including Major High, Major Low, Minor High, and Minor Low. Since there are multiple inlet pipes, the system can provide these programmable flow faults for each individual inlet pipe, resulting in a total of sixteen possible flow faults.

    Rate this question:

  • 11.

    The VESDA-E aspirator is a new design that is more efficient and quieter than other aspirators used in previous VESDA air sampling smoke detectors. The VESDA-E aspirator has how many programmable speed settings?

    • A.

      5

    • B.

      10

    • C.

      15

    • D.

      20

    Correct Answer
    B. 10
    Explanation
    The VESDA-E aspirator is a new design that offers programmable speed settings. The question asks how many programmable speed settings the VESDA-E aspirator has. The correct answer is 10, indicating that the VESDA-E aspirator can be adjusted to operate at 10 different speed settings.

    Rate this question:

  • 12.

    The maximum area a single VESDA-E detector can protect is:

    • A.

      5,000 sq. feet (465 sq. meters)

    • B.

      10,000 sq. feet (929 sq. meters)

    • C.

      20,000 sq. feet (2000 sq. meters)

    • D.

      25,000 sq. feet (2300 sq. meters)

    Correct Answer
    C. 20,000 sq. feet (2000 sq. meters)
    Explanation
    The maximum area a single VESDA-E detector can protect is 20,000 sq. feet (2000 sq. meters). This means that the detector is capable of covering an area of up to 20,000 sq. feet, providing effective smoke detection and early warning in case of fire. It is important to note that exceeding this maximum area may result in reduced detection capabilities and compromised safety.

    Rate this question:

  • 13.

    Together with the Flair smoke chamber and newly designed aspirator, the VESDA-E will allow for longer pipe runs compared to previous VESDA detectors. What is the maximum allowable aggregate pipe length for a single VESDA-E detector using a branched sample pipe network?

    • A.

      1312 feet (400 meters)

    • B.

      1500 feet (450 meters)

    • C.

      2624 feet (800 meters)

    • D.

      None of the above

    Correct Answer
    C. 2624 feet (800 meters)
    Explanation
    The correct answer is 2624 feet (800 meters). The explanation for this is that the VESDA-E detector, along with the Flair smoke chamber and newly designed aspirator, allows for longer pipe runs compared to previous VESDA detectors. This means that the detector can cover a larger area with its sampling pipe network. Therefore, the maximum allowable aggregate pipe length for a single VESDA-E detector using a branched sample pipe network is 2624 feet (800 meters).

    Rate this question:

  • 14.

    When mounting a VESDA-E detector to the wall a minimum of 2 inches (50mm) of space is required between the ceiling and the detector. If a Stax module is to be added to the top of the detector the minimum space between the detector and the ceiling shall be:

    • A.

      3 feet (1 Meter)

    • B.

      2 feet (60 cm)

    • C.

      1 foot (30 cm)

    • D.

      .5 foot (15 cm)

    Correct Answer
    C. 1 foot (30 cm)
    Explanation
    The correct answer is 1 foot (30 cm) because when a Stax module is added to the top of the detector, it requires additional space between the detector and the ceiling. Since the minimum space required between the ceiling and the detector without the Stax module is 2 inches (50mm), adding the Stax module would increase the required space. Therefore, the minimum space between the detector and the ceiling with the Stax module would be 1 foot (30 cm).

    Rate this question:

  • 15.

    All three display versions of the VESDA-E detector (LED, 3.5”, 7 “) have a reset/disable push button switch. How long must the reset/disable switch be depressed to put the VESDA-E detector in Disable Mode?

    • A.

      3 seconds

    • B.

      30 seconds

    • C.

      60 seconds

    • D.

      None of the above

    Correct Answer
    D. None of the above
  • 16.

    The 3.5-inch VESDA-E touch screen display has 3 distinct screens. These screens are the Main Screen, the Airflow screen, and the:

    • A.

      Status Screen

    • B.

      Maintenance Screen

    • C.

      Fault Screen

    • D.

      Front Door Screen

    Correct Answer
    A. Status Screen
    Explanation
    The 3.5-inch VESDA-E touch screen display has 3 distinct screens: the Main Screen, the Airflow screen, and the Status Screen. The Status Screen provides information about the current status of the VESDA-E system, including any faults or issues that may be present. This screen allows users to easily monitor the system and quickly identify any problems that need to be addressed.

    Rate this question:

  • 17.

    The VESDA-E detector comes with seven programmable, form C relays. The seven relays include Fire 1, Action, Alert, Isolate, Urgent Fault, Minor Fault, and:

    • A.

      General Trouble

    • B.

      General Maintenance

    • C.

      General Tso

    • D.

      Fire 2

    Correct Answer
    D. Fire 2
    Explanation
    The VESDA-E detector comes with seven programmable, form C relays, including Fire 1, Action, Alert, Isolate, Urgent Fault, Minor Fault, and Fire 2. This suggests that the detector has the capability to detect and respond to two separate fire incidents, hence the inclusion of Fire 2 as one of the relays.

    Rate this question:

  • 18.

    The VESDA-E detector has two power wiring terminals, one for power in the other for power out to other VESDA-E detectors. What is the acceptable input voltage for powering a VESDA-E detector?

    • A.

      220VAC

    • B.

      110VAC

    • C.

      24VDC

    • D.

      18-30VDC

    Correct Answer
    D. 18-30VDC
    Explanation
    The acceptable input voltage for powering a VESDA-E detector is 18-30VDC. This means that the detector can be powered by a direct current voltage ranging from 18 to 30 volts.

    Rate this question:

  • 19.

    Besides the on-board relays provided by the VESDA-E detector, there are three additional ways the detector can communicate with external devices/systems. Those communication methods are:

    • A.

      USB, USA, USSR

    • B.

      USB, Ethernet, Blue Tooth

    • C.

      USB, Modbus, WiFi

    • D.

      USB, Ethernet, WiFi

    Correct Answer
    D. USB, Ethernet, WiFi
    Explanation
    The VESDA-E detector can communicate with external devices/systems using USB, Ethernet, and WiFi. These communication methods allow for easy connectivity and data transfer between the detector and other devices or systems. USB provides a universal connection for various devices, Ethernet enables communication over a local network, and WiFi allows for wireless communication. This range of communication options ensures flexibility and compatibility with different setups and devices.

    Rate this question:

  • 20.

    In order for the VESDA-E to communicate via Ethernet or WiFi, a number of parameters need to be programmed into the detector using Xtralis VSC software and a USB serial connection. Those parameters include the devices IP (Internet Protocol) address and:

    • A.

      Detector Password

    • B.

      Detector Serial number

    • C.

      Detector MAC Address

    • D.

      None of the above

    Correct Answer
    A. Detector Password
    Explanation
    To communicate via Ethernet or WiFi, the VESDA-E detector needs to have certain parameters programmed into it using Xtralis VSC software and a USB serial connection. One of these parameters is the detector password. This password is necessary for authentication and ensuring secure communication between the detector and the network. Without the correct password, the detector would not be able to establish a connection and communicate effectively. Therefore, the correct answer is the "Detector Password".

    Rate this question:

  • 21.

    The VESDA-E can communicate to several Xtralis software applications including VSC, VSM, and iVESDA using the WiFi communications protocol. The key element required for the VESDA-E detector to communicate to any Xtralis software package is:

    • A.

      A Blue Tooth adaptor

    • B.

      A WiFi Access point or WiFi Router

    • C.

      A flux capacitor

    • D.

      None of the above

    Correct Answer
    B. A WiFi Access point or WiFi Router
    Explanation
    The VESDA-E detector can communicate with Xtralis software applications such as VSC, VSM, and iVESDA using the WiFi communications protocol. In order for the detector to establish this communication, it requires a WiFi Access point or WiFi Router. This device acts as a bridge between the VESDA-E detector and the software applications, allowing them to exchange data and information wirelessly. A Bluetooth adapter or a flux capacitor would not fulfill this requirement, making them incorrect choices.

    Rate this question:

  • 22.

    The iVESDA application can be used to:

    • A.

      Monitor all devices on VESDAnet

    • B.

      Monitor only VESDA-E devices on VESDAnet

    • C.

      Monitor only legacy detectors on VESDAnet

    • D.

      None of the above

    Correct Answer
    A. Monitor all devices on VESDAnet
    Explanation
    The iVESDA application is capable of monitoring all devices on VESDAnet. This means that it can monitor not only VESDA-E devices but also legacy detectors on the VESDAnet. Therefore, the correct answer is to monitor all devices on VESDAnet.

    Rate this question:

  • 23.

    The VESDA-E detector has a built-in virtual HLI. If a VESDA-E detector is placed on an existing VESDAnet network, the VESDA-E can communicate with other VESDA devices (including VLP, VLC, etc) via its VESDAnet ports and also communicate to external devices through one of its other communication ports (USB, Ethernet, WiFi). This means that an external HLI (High Level Interface) is no longer required.

    • A.

      True

    • B.

      False

    Correct Answer
    A. True
    Explanation
    The VESDA-E detector has a built-in virtual HLI, allowing it to communicate with other VESDA devices via its VESDAnet ports and also communicate with external devices through one of its other communication ports (USB, Ethernet, WiFi). This eliminates the need for an external HLI, making the statement true.

    Rate this question:

  • 24.

    The VESDA-E USB communication port can be used for other tasks other than connecting a serial cable between the detector and a computer. The USB port can also be used to download detector event logs, upload detector configuration parameters, and upload detector firmware upgrades using what device?

    • A.

      Hand held programmer

    • B.

      Memory Stick

    • C.

      Vesda Laser Compact

    • D.

      All of the above

    Correct Answer
    B. Memory Stick
    Explanation
    The VESDA-E USB communication port can be used to download detector event logs, upload detector configuration parameters, and upload detector firmware upgrades. This can be done using a memory stick, which can be connected to the USB port. Therefore, the correct answer is "Memory Stick".

    Rate this question:

  • 25.

    The VESDA-E detector has two GPI (General Purpose Inputs) used for things such as remote reset, power supply monitoring, standby by mode, remote disable, etc. One of the GPI is monitored and the other is unmonitored.

    • A.

      True

    • B.

      False

    Correct Answer
    A. True
    Explanation
    The VESDA-E detector indeed has two GPIs (General Purpose Inputs) that serve various purposes such as remote reset, power supply monitoring, standby mode, and remote disable. One of the GPIs is monitored, meaning that its status is actively monitored by the system, while the other GPI is unmonitored, implying that its status is not actively monitored.

    Rate this question:

  • 26.

    The VESDA-E has a number of field replaceable parts. These parts include the Aspirator, the sampling module, the smoke chamber, and the:

    • A.

      Filter

    • B.

      Chassis

    • C.

      Static eradicator

    • D.

      None of the above

    Correct Answer
    A. Filter
    Explanation
    The VESDA-E system is equipped with field replaceable parts to ensure efficient functioning. The Aspirator, sampling module, and smoke chamber are some of these replaceable parts. Considering this, it is logical to conclude that the missing part mentioned in the question is the Filter. Filters are crucial components in smoke detection systems as they help in capturing and removing smoke particles from the air. Therefore, the correct answer is Filter.

    Rate this question:

  • 27.

    The VESDA-E detector can easily replace an older VESDA VLP detector because both units share the same footprint, conduit pitch, and:

    • A.

      Aspirator

    • B.

      Mounting Bracket

    • C.

      Relay order

    • D.

      DNA

    Correct Answer
    C. Relay order
    Explanation
    The VESDA-E detector can easily replace an older VESDA VLP detector because both units share the same footprint, conduit pitch, and relay order. This means that the physical dimensions and installation requirements of the two detectors are identical, making it a seamless transition to replace the older detector with the newer model. The relay order being the same ensures that the wiring and connections for the detectors remain unchanged, further simplifying the replacement process.

    Rate this question:

  • 28.

    The VESDA-E can be mounted in two different ways. The first way is utilizing the mounting keyways located on the back of the unit. The other mounting method is using the:

    • A.

      Supplied wood screws

    • B.

      Optional mounting bracket

    • C.

      Cable ties

    • D.

      None of the above

    Correct Answer
    B. Optional mounting bracket
    Explanation
    The VESDA-E can be mounted in two different ways. The first way is utilizing the mounting keyways located on the back of the unit. The other mounting method is using the optional mounting bracket. This means that the VESDA-E can be securely mounted using either the keyways or the optional mounting bracket, providing flexibility in installation options. The supplied wood screws and cable ties are not mentioned as mounting options, so they are not the correct answer.

    Rate this question:

  • 29.

    When designing a sample pipe network for the VESDA-E detector, the sample pipe parameters HAVE to be entered and verified into what hydraulic calculation program?

    • A.

      Aspire 1

    • B.

      Aspire 2

    • C.

      Aspire 3

    • D.

      Aspire-E

    Correct Answer
    D. Aspire-E
    Explanation
    The correct answer is Aspire-E because it is specifically mentioned that the sample pipe parameters need to be entered and verified into a hydraulic calculation program. Aspire-E is the only option that is a hydraulic calculation program, while the other options (Aspire 1, Aspire 2, and Aspire 3) do not specify that they are hydraulic calculation programs. Therefore, Aspire-E is the correct choice for entering and verifying the sample pipe parameters.

    Rate this question:

  • 30.

    When mounting the VESDA-E using the keyways located on the back of the unit, what provided items should always be used to ensure a neat, proper installation?

    • A.

      Installation instructions

    • B.

      Installation instructions and mounting template

    • C.

      Installation instructions and plastic shipping packaging

    • D.

      None of the above

    Correct Answer
    B. Installation instructions and mounting template
    Explanation
    To ensure a neat and proper installation when mounting the VESDA-E using the keyways located on the back of the unit, it is important to use the installation instructions and mounting template. The installation instructions provide step-by-step guidance on how to correctly install the unit, while the mounting template helps to accurately position the unit on the mounting surface. By using both of these provided items, the installer can ensure that the VESDA-E is installed correctly and securely.

    Rate this question:
