1. In most cases, the refrigerant leaving the evaporator must be ____ percent vapor.

Explanation

The refrigerant leaving the evaporator must be 100 percent vapor because the purpose of the evaporator is to absorb heat from the surroundings and convert the liquid refrigerant into vapor. This vapor is then compressed and condensed in the condenser to release the absorbed heat. Therefore, for the evaporator to effectively perform its function, the refrigerant leaving it should be completely in the vapor state.

Submit
Please wait...
About This Quiz
AC 432 Refrigeration Systems - Quiz

Refrigeration is used in different appliances around us, most commonly in refrigerators in our houses and places of work. How conversant are you with the refrigeration system, functionality... see moreand how to repair broken parts? Give this test on the system a try and polish up what you have forgotten before the finals. see less

2. In a water-cooled condenser, the leaving water temperature is normally ____°F lower than the condensing temperature of the refrigerant.

Explanation

In a water-cooled condenser, the leaving water temperature is normally 10°F lower than the condensing temperature of the refrigerant. This temperature difference is necessary to ensure efficient heat transfer between the refrigerant and the water. By maintaining a lower water temperature, the condenser can effectively remove heat from the refrigerant, allowing it to condense and convert back into a liquid state. This helps in maintaining the overall cooling efficiency of the system.

Submit
3. The automatic expansion valve maintains a constant ____.

Explanation

The automatic expansion valve is designed to regulate and maintain a constant pressure. It ensures that the pressure in the system remains consistent, preventing any fluctuations that could affect the performance or efficiency of the system. By maintaining a constant pressure, the valve helps to ensure optimal operation and stability in various applications such as refrigeration or air conditioning systems.

Submit
4. Refrigerant entering the evaporator is approximately ____% liquid.

Explanation

The correct answer is 75 because the evaporator is the part of the refrigeration system where the refrigerant absorbs heat and evaporates. As the refrigerant enters the evaporator, it is in a liquid state. Therefore, approximately 75% of the refrigerant entering the evaporator is in liquid form.

Submit
5. The TX valve maintains a constant ____.

Explanation

The TX valve maintains a constant superheat temperature. The superheat temperature refers to the temperature of the refrigerant vapor above its boiling point in the evaporator coil. The TX valve regulates the flow of refrigerant into the evaporator coil to ensure that the superheat temperature remains constant. This is important for the efficient operation of the refrigeration system and to prevent any damage to the compressor.

Submit
6. The low form of plant life that grows in condenser water is ____.

Explanation

The low form of plant life that grows in condenser water is algae. Algae are simple, non-flowering plants that can grow in various aquatic environments, including condenser water. They are capable of photosynthesis and can thrive in moist and nutrient-rich conditions. The presence of algae in condenser water can cause problems such as clogging, reduced heat transfer efficiency, and corrosion. Therefore, it is important to regularly monitor and control algae growth in condenser water systems.

Submit
7. As a rule of thumb, the temperature of the evaporator should be about ____ °F colder than the box temperature.

Explanation

The temperature of the evaporator should be about 15°F colder than the box temperature. This temperature difference ensures that the evaporator can effectively absorb heat from the box and maintain the desired temperature. If the evaporator temperature is not sufficiently colder than the box temperature, the cooling process may be inefficient and the desired temperature may not be achieved. Therefore, maintaining a temperature difference of 15°F helps optimize the cooling efficiency and ensures proper temperature control.

Submit
8. An evaporative condenser uses ____ and ____ as the transfer medium for system heat.

Explanation

An evaporative condenser uses air and water as the transfer medium for system heat. The air absorbs heat from the condenser coils, causing the refrigerant to condense and release heat. The water is then used to cool down the hot refrigerant and remove the heat from the system. This process allows for efficient heat transfer and helps in the cooling of the system.

Submit
9. If an air-cooled condenser's fan motor stops running, the heat pressure will ____ and the amount of subcooling will ____.

Explanation

If an air-cooled condenser's fan motor stops running, it will result in a decrease in airflow over the condenser coils. This decrease in airflow will cause the heat pressure to increase since the condenser coils will not be able to dissipate heat effectively. Additionally, the decrease in airflow will also lead to a decrease in subcooling, which refers to the temperature decrease of the refrigerant below its saturation point. Therefore, the correct answer is that the heat pressure will increase and the amount of subcooling will decrease.

Submit
10. In order for a flooded condenser type head pressure control system to operate, a device called a ____ has to be added to the system because of the extra refrigerant.

Explanation

A receiver is a device that is added to a flooded condenser type head pressure control system to accommodate the extra refrigerant. This is necessary because the flooded condenser system operates by having excess refrigerant in the condenser, which helps to maintain a constant head pressure. The receiver acts as a storage tank for the excess refrigerant, allowing it to be stored and released as needed to maintain the desired head pressure in the system. Without a receiver, the system would not be able to properly control the head pressure and may result in inefficient operation or damage to the equipment.

Submit
11. The correct term for a coil using a low side float is ____.

Explanation

A coil that uses a low side float is referred to as "flooded." This means that the coil is submerged in the refrigerant, allowing for efficient heat transfer. The low side float helps maintain the desired level of refrigerant in the coil, ensuring optimal performance.

Submit
12. One large problem designer's face when designing air-cooled refrigeration and air conditioning equipment is a changing ambient from the changing seasons.

Explanation

The statement is true because the changing seasons result in varying ambient temperatures, which can pose a challenge for designers of air-cooled refrigeration and air conditioning equipment. As the ambient temperature fluctuates, the equipment needs to be able to adjust and maintain the desired temperature efficiently. Designers must consider these changing conditions to ensure that the equipment functions effectively in different seasons.

Submit
13. As the evaporator load increases, an automatic expansion valve will ____ to reduce the evaporator pressure while a thermostatic expansion valve will ____ to reduce the evaporator superheat.

Explanation

As the evaporator load increases, an automatic expansion valve will close to reduce the evaporator pressure. This is because a closed valve restricts the flow of refrigerant into the evaporator, reducing the pressure and preventing excess refrigerant from entering the system. On the other hand, a thermostatic expansion valve will open to reduce the evaporator superheat. Opening the valve allows more refrigerant to flow into the evaporator, increasing the cooling capacity and reducing the superheat of the refrigerant leaving the evaporator.

Submit
14. The refrigerant in the evaporator must be colder than the air passing over it for heat to transfer to the evaporator.

Explanation

This statement is true because heat transfer occurs from a higher temperature region to a lower temperature region. In the case of an evaporator, heat is transferred from the air passing over it to the refrigerant. Therefore, the refrigerant in the evaporator must be colder than the air for heat transfer to occur.

Submit
15. Low suction pressures, iced coils, short-cycling, and inefficient cooling can also result from low head pressures.

Explanation

Low suction pressures, iced coils, short-cycling, and inefficient cooling can indeed result from low head pressures. When the head pressure is low, it means that there is not enough refrigerant being condensed in the condenser. This can lead to a decrease in the suction pressure, causing the coils to ice up and the system to short-cycle. Additionally, the cooling efficiency of the system will be compromised, resulting in inefficient cooling. Therefore, the statement is true.

Submit
16. The two primary functions of an evaporator are to remove ____ and ____ from the refrigerated space.

Explanation

The correct answer is "moisture, heat". An evaporator is a component in a refrigeration system that absorbs heat from the refrigerated space and removes moisture from the air. As the refrigerant evaporates, it absorbs heat from the surrounding air, thereby cooling the space. At the same time, the evaporator also helps in dehumidifying the air by condensing the moisture present in it. Therefore, the primary functions of an evaporator are to remove moisture and heat from the refrigerated space.

Submit
17. When the velocity of the air moving over an evaporator is slow, the "air film" acts as an insulator and slow the rate of heat exchange.

Explanation

When the velocity of the air moving over an evaporator is slow, the "air film" refers to a layer of air that forms on the surface of the evaporator. This air film acts as an insulator, meaning that it inhibits the transfer of heat between the evaporator and the air. As a result, the rate of heat exchange is slowed down. Therefore, the statement is true.

Submit
18. Evaporative condensers operate more efficiently in climates where the wet bulb temperature is a great deal lower than the dry bulb temperature.

Explanation

Evaporative condensers operate more efficiently in climates where the wet bulb temperature is significantly lower than the dry bulb temperature because the condenser uses the evaporation of water to cool the refrigerant. When the wet bulb temperature is lower, the water evaporates more easily, resulting in better cooling efficiency. This means that the condenser can effectively remove heat from the refrigerant, allowing the system to function optimally.

Submit
19. If a low temperature evaporator is forming excess ice, which of the following could be a possible problem?

Explanation

If a low temperature evaporator is forming excess ice, all of the given options could be possible problems. A defective evaporator fan motor can cause insufficient air circulation, leading to ice formation. If the unit is not staying in defrost long enough, the ice on the evaporator may not melt completely, resulting in excess ice buildup. A defective defrost heater can also prevent proper melting of ice during the defrost cycle, leading to excess ice formation. Therefore, all of the mentioned issues could contribute to the formation of excess ice on the low temperature evaporator.

Submit
20. A typical evaporator operating temperature in an air-conditioning system is ____.

Explanation

A typical evaporator operating temperature in an air-conditioning system is 40°F because this temperature allows for efficient cooling of the air. At this temperature, the evaporator coil can effectively absorb heat from the surrounding air, causing the refrigerant to evaporate and cool the air passing through the system. This temperature is also suitable for maintaining a comfortable indoor environment without causing excessive cooling or freezing of the air.

Submit
21. A typical superheat for an evaporator operating under normal conditions would be ____.

Explanation

A typical superheat for an evaporator operating under normal conditions would be 8 to 12°F. Superheat is the temperature difference between the actual temperature of the refrigerant vapor and its saturation temperature at a given pressure. It is important to have a certain amount of superheat in the evaporator to ensure that the refrigerant is fully vaporized before it leaves the evaporator. A superheat of 8 to 12°F is considered normal and allows for efficient heat transfer and prevents liquid refrigerant from entering the compressor.

Submit
22. The capacity of an evaporator is affected by ____.

Explanation

The capacity of an evaporator is affected by all of the above factors. The saturation pressure of the low side of the system determines the temperature at which the refrigerant evaporates, thus affecting the heat transfer process. Similarly, the saturation pressure of the high side of the system affects the condensing temperature and the overall efficiency of the system. Additionally, the amount of evaporator superheat, which is the temperature rise above the refrigerant's saturation temperature, also impacts the evaporator's capacity as it affects the heat transfer rate. Therefore, all of these factors play a role in determining the capacity of an evaporator.

Submit
23. The condenser in a refrigeration system ____.

Explanation

The condenser in a refrigeration system performs multiple functions. Firstly, it desuperheats the vapor from the compressor, removing excess heat and reducing the temperature. Secondly, it condenses the vapor, converting it back into a liquid state. Lastly, it subcools the liquid refrigerant before it leaves the condenser, further lowering its temperature. Therefore, the correct answer is "all of the above" as the condenser performs all these tasks in a refrigeration system.

Submit
24. If a spring pressure of a water regulating valve is increased, the system head pressure will also increase.

Explanation

Increasing the spring pressure of a water regulating valve will result in an increase in the force exerted by the valve on the water flowing through it. This increased force will cause the valve to close more tightly, reducing the flow rate and increasing the system head pressure. Therefore, it is true that increasing the spring pressure of a water regulating valve will also increase the system head pressure.

Submit
25. When the quantity of refrigerant flow to an evaporator is reduced, the amount of superheat in the vapor leaving the coil will ____.

Explanation

When the quantity of refrigerant flow to an evaporator is reduced, there will be less refrigerant available to absorb heat from the surroundings. As a result, the evaporator coil will not be able to remove as much heat from the system, leading to an increase in the temperature of the refrigerant leaving the coil. This increase in temperature is known as superheat, so when the quantity of refrigerant flow is reduced, the amount of superheat in the vapor leaving the coil will rise.

Submit
26. Condensing temperatures in an air-cooled condensing unit can be reduced by ____.

Explanation

By increasing the condensing surface area, more heat can be dissipated, resulting in lower condensing temperatures. Similarly, increasing the cfm (cubic feet per minute) through the condenser increases the rate of heat transfer, leading to lower temperatures. Additionally, decreasing the temperature of the air entering the condenser provides a cooler environment for heat exchange, further reducing condensing temperatures. Therefore, all of these actions can contribute to reducing the condensing temperatures in an air-cooled condensing unit.

Submit
27. A defrost system that pipes the compressor discharge vapor directly to the evaporator is called a ____ type.

Explanation

A defrost system that pipes the compressor discharge vapor directly to the evaporator is called a hot gas defrost type. In this type of system, the hot gas from the compressor is used to heat up the evaporator coil, melting any ice or frost that has accumulated on it. This hot gas is then condensed back into a liquid state and returned to the compressor to continue the refrigeration cycle. This method is efficient and helps to quickly defrost the evaporator, allowing it to resume normal cooling operations.

Submit
28. The two pressures that push to close a thermostatic expansion valve are the ____ pressure and the ____ pressure.

Explanation

The spring pressure in a thermostatic expansion valve acts as a force that pushes to close the valve. This pressure is created by the compression of the spring within the valve. The evaporator pressure, on the other hand, refers to the pressure within the evaporator coil of a refrigeration system. This pressure also contributes to the closing of the expansion valve as it creates a back pressure that helps to keep the valve closed. Therefore, both the spring pressure and the evaporator pressure work together to push the thermostatic expansion valve to close.

Submit
29. A stamped plate evaporator usually does not use a fan to move air across it.

Explanation

A stamped plate evaporator is designed in such a way that it promotes natural convection for heat transfer. It consists of multiple thin plates with small channels or passages for the refrigerant to flow through. These plates are typically arranged in a stack, allowing for a larger surface area for heat exchange. Due to this design, a fan is not required to move air across the evaporator as the natural convection currents created by the temperature difference between the refrigerant and the surrounding air are sufficient for efficient heat transfer. Therefore, the statement "A stamped plate evaporator usually does not use a fan to move air across it" is true.

Submit
30. Hard starting may also occur in a low ambient conditions causing low head pressures.

Explanation

Hard starting refers to difficulties in starting a machine or engine. In low ambient conditions, such as cold weather, the head pressures in the system may be low. This can result in hard starting because the system may not be able to build up the necessary pressure to start properly. Therefore, the statement that hard starting may occur in low ambient conditions causing low head pressures is true.

Submit
31. If an evaporator has a pressure drop of 10 psig and the low side pressure is 15 psig, what is the pressure at the inlet of the evaporator?

Explanation

The pressure at the inlet of the evaporator is 25 psig because the pressure drop is subtracted from the low side pressure. In this case, the pressure drop is 10 psig, so when it is subtracted from the low side pressure of 15 psig, the result is 25 psig.

Submit
32. A large capacity evaporator would probably have ____.

Explanation

A large capacity evaporator would probably have multiple refrigerant circuits. This is because a larger evaporator requires more refrigerant to be evaporated in order to cool a larger space or handle a higher cooling load. Having multiple refrigerant circuits allows for better distribution of the refrigerant and helps to ensure efficient and effective cooling throughout the evaporator.

Submit
33. If an R-12 refrigeration system has its air-cooled condensing unit on a 100°F roof and the condenser outlet temperature (refrigerant) is 115°F, with how much subcooling is the condenser operating?

Explanation

The condenser is operating with 15°F of subcooling. Subcooling is the temperature difference between the liquid refrigerant leaving the condenser and its saturation temperature. In this case, the condenser outlet temperature is 115°F, which is 15°F higher than the saturation temperature. Therefore, the condenser is operating with 15°F of subcooling.

Submit
34. The refrigerant in a condenser in a refrigeration system ____.

Explanation

In a refrigeration system, the condenser is responsible for releasing heat from the refrigerant. As the refrigerant flows through the condenser, it undergoes a phase change from a high-pressure vapor to a high-pressure liquid. During this process, the refrigerant gives up heat to the surroundings, which allows it to cool down and condense. Therefore, the correct answer is "gives up heat."

Submit
35. If an R-12 refrigeration system is operating with a 25.4 psig suction pressure, what is the evaporator superheat if the evaporator outlet temperature is 34°F?

Explanation

The evaporator superheat is the difference between the actual evaporator outlet temperature and the saturation temperature at the corresponding evaporator pressure. In this case, the evaporator outlet temperature is given as 34°F and the suction pressure is given as 25.4 psig. By looking up the saturation temperature of R-12 at 25.4 psig, we can find that it is 25°F. Therefore, the evaporator superheat is 34°F - 25°F = 9°F.

Submit
36. Mineral deposits in the water portion of a water-cooled condenser act as ____.

Explanation

Mineral deposits in the water portion of a water-cooled condenser act as an insulator. This means that they hinder the transfer of heat between the water and the condenser. Insulators are substances that do not conduct heat well, so when mineral deposits build up in the condenser, they create a barrier that prevents efficient heat transfer. As a result, the condenser may become less effective in cooling the water, leading to decreased efficiency and potential operational issues.

Submit
37. The desired water flow through a condenser connecting to a recirculating water system is 3 gallons per minute.

Explanation

The statement is true because it states that the desired water flow through a condenser connecting to a recirculating water system is 3 gallons per minute. This means that the condenser is designed to operate efficiently with a flow rate of 3 gallons per minute, indicating that any other flow rate may not be optimal for the system.

Submit
38. If the application requires a coil design to operate below 32°F, there must be provision for ____.

Explanation

If the application requires a coil design to operate below 32°F, there must be provision for defrost. This is because when operating at such low temperatures, ice can build up on the evaporator coil, reducing its efficiency and potentially causing damage. Defrosting is necessary to remove the ice buildup and ensure proper functioning of the coil.

Submit
39. The shell and tube condenser is cleaned ____.

Explanation

The shell and tube condenser is cleaned with a brush after removing the end caps. This is because the brush allows for effective scrubbing and removal of any debris or buildup inside the condenser tubes. Removing the end caps provides access to the tubes, making it easier to clean them thoroughly. Using a brush ensures a physical cleaning action, which can be more effective than solely relying on chemicals, compressed air, or a vacuum cleaner.

Submit
40. A forced draft high temperature evaporator would ____.

Explanation

A forced draft high temperature evaporator would have its fins very close together and not need to be defrosted. This is because the close proximity of the fins allows for efficient heat transfer, preventing the formation of ice and frost. Additionally, the forced draft design ensures a continuous flow of air, further preventing the need for defrosting. Therefore, both options a and b are correct.

Submit
41. If the waterflow is reduced, the temperature difference across a condenser will ____.

Explanation

When the waterflow is reduced in a condenser, it means that there is less water available to remove heat from the condenser. This leads to a decrease in the overall heat transfer rate, resulting in a higher temperature difference across the condenser. Therefore, the temperature difference across the condenser will increase when the waterflow is reduced.

Submit
42. During the defrost cycle of a forced draft low temperature evaporator, the evaporator fan would ____.

Explanation

During the defrost cycle of a forced draft low temperature evaporator, the evaporator fan would turn off. This is because during the defrost cycle, the heat from the defrost heaters is used to melt the ice that has accumulated on the evaporator coils. If the evaporator fan remains on, it would blow the warm air away from the coils, reducing the effectiveness of the defrosting process. Therefore, turning off the fan allows the heat to be concentrated on the coils, speeding up the defrosting process.

Submit
43. Control of the head pressure in an air-cooled condenser is done by ____.

Explanation

The control of head pressure in an air-cooled condenser can be achieved through multiple methods. One way is by cycling the condenser fan, which adjusts the air flow and helps regulate the condenser temperature. Another method is by controlling dampers in the airstream through the condenser, which allows for better control of the air flow and heat transfer. Lastly, flooding the condenser with refrigerant can also help in controlling the head pressure. Therefore, all of the above options are correct ways to control the head pressure in an air-cooled condenser.

Submit
44. If a high temperature evaporator is forming ice, which of the following is a possible problem?

Explanation

If a high temperature evaporator is forming ice, a possible problem could be that the evaporator fan is not running. The evaporator fan is responsible for circulating air over the evaporator coil, which helps to remove heat and prevent ice formation. If the fan is not running, the air flow will be restricted, causing the evaporator coil to become too cold and resulting in ice formation.

Submit
45. Fewer fins per inch on an evaporator allow more ice to build between defrost cycle.

Explanation

Fewer fins per inch on an evaporator means that there is more space between the fins for ice to accumulate. This allows for more ice to build up between defrost cycles because there is more surface area available for ice formation. Therefore, the statement is true.

Submit
46. A refrigeration system designed for the storage of flowers or candy is considered a ____ type.

Explanation

A refrigeration system designed for the storage of flowers or candy is considered a high temperature type because it is not meant to freeze or cool the items to extremely low temperatures. Instead, it is designed to maintain a slightly cooler temperature than the surrounding environment to prevent spoilage or melting, but not cold enough to freeze the products.

Submit
47. A normally operating water-cooled condenser is operating with a 10° differential between water in and water out. If scale forms on the water tubes and the entering water is 85°F, which of the following is possible?

Explanation

Both options a and b are correct because when scale forms on the water tubes, it acts as an insulating layer, reducing the heat transfer efficiency. As a result, the outlet water temperature will increase, causing the outlet water to be 88°F instead of the usual 85°F. Additionally, the reduced heat transfer efficiency will cause the system head pressure to rise as the condenser struggles to remove heat effectively. Therefore, both a and b are possible outcomes in this scenario.

Submit
48. An air-cooled condenser that is operating in a climate that has four distinct seasons must ____.

Explanation

An air-cooled condenser that is operating in a climate that has four distinct seasons must have some type of head pressure control because the temperature and humidity levels can vary greatly throughout the year. Head pressure control helps to maintain the condenser's operating pressure within a desired range, ensuring efficient heat transfer and preventing the condenser from becoming overworked or damaged. By adjusting the head pressure, the condenser can effectively cool the refrigerant and maintain optimal performance regardless of the changing outdoor conditions.

Submit
49. The water circuit in shell and coil and coil-type tube-in-a-tube condensers must be cleaned ____.

Explanation

The water circuit in shell and coil and coil-type tube-in-a-tube condensers must be cleaned chemically. This is because chemical cleaning is the most effective method to remove any buildup or deposits that may accumulate in the water circuit. Chemical cleaners are specifically designed to dissolve and remove scale, rust, and other contaminants, ensuring optimal performance and efficiency of the condenser.

Submit
50. The device used to feed refrigerant to multiple circuits in an evaporator is called a flow circuit.

Explanation

The device used to feed refrigerant to multiple circuits in an evaporator is not called a flow circuit. The correct term for this device is a distributor. The distributor evenly distributes the refrigerant to each circuit in the evaporator, ensuring efficient cooling throughout the system.

Submit
51. A direct expansion-type evaporator is also called a ____.

Explanation

A direct expansion-type evaporator is also called a dry-type evaporator because it operates by directly expanding the refrigerant inside the evaporator coils. This type of evaporator does not use a liquid refrigerant, hence the term "dry-type". Instead, the refrigerant evaporates directly from a gaseous state to a vapor state in the coils, absorbing heat from the surrounding air or liquid in the process. This design allows for efficient heat transfer and is commonly used in air conditioning systems and refrigeration units.

Submit
52. A forced draft medium temperature evaporator would ____.

Explanation

A forced draft medium temperature evaporator would be defrosted by off-cycle defrost. Off-cycle defrost is a method of defrosting where the refrigeration system is temporarily shut down, allowing the accumulated ice on the evaporator to melt off naturally. In a forced draft evaporator, air is forced across the evaporator coils by a fan, which helps to enhance the heat transfer process. This forced air movement helps to prevent ice buildup on the coils. However, if any ice does accumulate, it can be easily melted off using off-cycle defrost, without the need for additional heating elements or a hot gas defrost system.

Submit
53. Excess evaporator superheat ____.

Explanation

Excess evaporator superheat refers to the temperature difference between the refrigerant entering the evaporator and its saturation temperature. When there is too much superheat, it means that the refrigerant is not fully evaporated before entering the compressor. This can lead to a decrease in the cooling capacity of the system because the compressor is designed to compress vapor, not liquid. Therefore, the correct answer is that excess evaporator superheat will reduce the cooling capacity of the system.

Submit
54. When a system with a water-cooled condenser cycles off, the water regulating valve should ____.

Explanation

When a system with a water-cooled condenser cycles off, the head pressure is lower because the compressor is not running and there is no heat being generated. Therefore, the water regulating valve should close to prevent unnecessary water flow and conserve energy.

Submit
55. Which of the following can be used to maintain the head pressure of a system with an air-cooled condenser?

Explanation

All of the options mentioned can be used to maintain the head pressure of a system with an air-cooled condenser. Fan cycling helps to control the speed of the condenser fan, thereby regulating the head pressure. The condenser flooding valve adjusts the flow of refrigerant to the condenser, which also affects the head pressure. Dampers or louvers can be adjusted to control the airflow through the condenser, thus influencing the head pressure. Therefore, all of these options can be utilized to maintain the head pressure of a system with an air-cooled condenser.

Submit
56. If a low temperature evaporator is forming ice, which of the following is a possible problem?

Explanation

not-available-via-ai

Submit
57. In a water-cooled condenser with dirty condenser tubes, the temperature difference between the refrigerant and the leaving water will be ____ when the tubes are clean.

Explanation

When the condenser tubes are dirty, the efficiency of heat transfer between the refrigerant and the water is reduced. This results in a smaller temperature difference between the refrigerant and the leaving water. Therefore, when the tubes are clean, the heat transfer efficiency improves, leading to a larger temperature difference between the refrigerant and the leaving water. Hence, the temperature difference will be greater than when the tubes are dirty.

Submit
58. An evaporator made up of two or more pieces of sheet metal dimpled to create tubes is called a ____type.

Explanation

An evaporator made up of two or more pieces of sheet metal dimpled to create tubes is called a stamped-plate type. This type of evaporator is constructed by stamping or forming the sheet metal into a series of dimples or depressions, which create the tubes for heat exchange. The dimples increase the surface area of the evaporator, allowing for more efficient heat transfer between the refrigerant and the surrounding air or liquid. The stamped-plate design also provides structural integrity and durability to the evaporator.

Submit
59. Which of the following would allow a system to operate more efficiently?

Explanation

A condenser that has refrigerant leaving with 15° of subcooling would allow a system to operate more efficiently. Subcooling refers to the cooling of a liquid refrigerant below its saturation temperature. By having the refrigerant leave the condenser with 15° of subcooling, it means that the refrigerant is being cooled further, which increases its density. This increased density allows for better heat transfer in the evaporator, resulting in improved system efficiency.

Submit
60. Which of the following condensers is the most efficient?

Explanation

Water-cooled counter flow condensers are the most efficient because they allow for maximum heat transfer between the refrigerant and the cooling water. In a counter flow configuration, the refrigerant and the cooling water flow in opposite directions, which creates a large temperature difference between them. This temperature difference enhances the heat transfer process, resulting in higher efficiency compared to other condenser types. Additionally, water-cooled condensers generally have a higher heat transfer coefficient than air-cooled condensers, further contributing to their superior efficiency.

Submit
61. SEER is calculated based on the total amount of ____ the system will provide over the entire season, divided by the total number ____it will consume.

Explanation

SEER (Seasonal Energy Efficiency Ratio) is a measure of the efficiency of an air conditioning system. It is calculated by dividing the total amount of cooling in Btu (British thermal units) that the system provides over the entire season by the total number of watt-hours it consumes. This ratio helps consumers compare the energy efficiency of different air conditioning systems. By considering both the cooling capacity and the energy consumption, SEER provides a standardized way to evaluate and compare the efficiency of air conditioners.

Submit
62. Every central split cooling system manufactured in the USA today must have a Seasonal Energy Efficiency Ratio (Seer) of at least 10.

Explanation

The statement is false because every central split cooling system manufactured in the USA today must have a Seasonal Energy Efficiency Ratio (SEER) of at least 13, not 10. The SEER rating is a measure of the cooling efficiency of the system, and a higher SEER rating indicates greater energy efficiency. Therefore, a SEER rating of 10 would not meet the minimum requirement for central split cooling systems in the USA.

Submit
63. High head pressures from low ambients can cause insufficient refrigerant flow rates through metering devices, which in turn starve evaporators.

Explanation

High head pressures from low ambients can indeed cause insufficient refrigerant flow rates through metering devices, leading to inadequate cooling of the evaporators. However, the statement in the question is incorrect as it states the opposite. Therefore, the correct answer is False.

Submit
64. A water regulating valve helps maintain in a system's head pressure by modulating the flow of refrigerant through the condenser.

Explanation

A water regulating valve does not help maintain a system's head pressure by modulating the flow of refrigerant through the condenser. A water regulating valve is used to control the flow of water in a system, typically in a cooling tower or a chilled water system. It does not have any direct impact on the flow of refrigerant or the head pressure in a refrigeration system. Therefore, the statement is false.

Submit
65. A normally operating water-cooled condenser is operating with a 10° differential between water in and water out. If the amount of 85°F water going through the condenser is reduced, which of the following is a possible temperature of the water leaving the condenser?

Explanation

If the amount of 85°F water going through the condenser is reduced, it means that less heat is being transferred from the condenser to the water. As a result, the temperature of the water leaving the condenser would increase. Therefore, a possible temperature of the water leaving the condenser could be 105°F.

Submit
66. In a water-cooled condenser, a regulating valve is used to control the ____.

Explanation

In a water-cooled condenser, a regulating valve is used to control the refrigerant condensing temperature. This valve adjusts the flow of water through the condenser, which in turn affects the temperature at which the refrigerant condenses. By regulating the condensing temperature, the system can maintain optimal operating conditions and improve overall efficiency.

Submit
67. The heat required for off-cycle defrost is obtained from ____.

Explanation

The heat required for off-cycle defrost is obtained from the space temperature when the compressor is off. During off-cycle defrost, the compressor is not running, so there is no heat generated by the system. Instead, the heat needed for defrosting is taken from the surrounding air or space temperature. This heat is used to melt any ice or frost that has accumulated on the evaporator coil, allowing the system to operate efficiently once the compressor starts again.

Submit
68. What can be used to maintain the head pressure of a system with a water-cooled condenser?

Explanation

A water regulating valve can be used to maintain the head pressure of a system with a water-cooled condenser. This valve allows for precise control of the water flow rate to the condenser, which in turn helps regulate the condenser's temperature and pressure. By adjusting the water flow, the valve ensures that the head pressure remains at the desired level, optimizing the system's performance and efficiency. Fan cycling and dampers or louvers may also be used in conjunction with the water regulating valve to further control the head pressure, but they are not the only options and may not be necessary in all cases.

Submit
View My Results

Quiz Review Timeline (Updated): Mar 21, 2023 +

Our quizzes are rigorously reviewed, monitored and continuously updated by our expert board to maintain accuracy, relevance, and timeliness.

  • Current Version
  • Mar 21, 2023
    Quiz Edited by
    ProProfs Editorial Team
  • Feb 18, 2010
    Quiz Created by
    Azortex
Cancel
  • All
    All (68)
  • Unanswered
    Unanswered ()
  • Answered
    Answered ()
In most cases, the refrigerant leaving the evaporator must be ____...
In a water-cooled condenser, the leaving water temperature is normally...
The automatic expansion valve maintains a constant ____.
Refrigerant entering the evaporator is approximately ____% liquid.
The TX valve maintains a constant ____.
The low form of plant life that grows in condenser water is ____.
As a rule of thumb, the temperature of the evaporator should be about...
An evaporative condenser uses ____ and ____ as the transfer medium for...
If an air-cooled condenser's fan motor stops running, the heat...
In order for a flooded condenser type head pressure control system to...
The correct term for a coil using a low side float is ____.
One large problem designer's face when designing air-cooled...
As the evaporator load increases, an automatic expansion valve will...
The refrigerant in the evaporator must be colder than the air passing...
Low suction pressures, iced coils, short-cycling, and inefficient...
The two primary functions of an evaporator are to remove ____ and ____...
When the velocity of the air moving over an evaporator is slow, the...
Evaporative condensers operate more efficiently in climates where the...
If a low temperature evaporator is forming excess ice, which of the...
A typical evaporator operating temperature in an air-conditioning...
A typical superheat for an evaporator operating under normal...
The capacity of an evaporator is affected by ____.
The condenser in a refrigeration system ____.
If a spring pressure of a water regulating valve is increased, the...
When the quantity of refrigerant flow to an evaporator is reduced, the...
Condensing temperatures in an air-cooled condensing unit can be...
A defrost system that pipes the compressor discharge vapor directly to...
The two pressures that push to close a thermostatic expansion valve...
A stamped plate evaporator usually does not use a fan to move air...
Hard starting may also occur in a low ambient conditions causing low...
If an evaporator has a pressure drop of 10 psig and the low side...
A large capacity evaporator would probably have ____.
If an R-12 refrigeration system has its air-cooled condensing unit on...
The refrigerant in a condenser in a refrigeration system ____.
If an R-12 refrigeration system is operating with a 25.4 psig suction...
Mineral deposits in the water portion of a water-cooled condenser act...
The desired water flow through a condenser connecting to a...
If the application requires a coil design to operate below 32°F,...
The shell and tube condenser is cleaned ____.
A forced draft high temperature evaporator would ____.
If the waterflow is reduced, the temperature difference across a...
During the defrost cycle of a forced draft low temperature evaporator,...
Control of the head pressure in an air-cooled condenser is done by...
If a high temperature evaporator is forming ice, which of the...
Fewer fins per inch on an evaporator allow more ice to build between...
A refrigeration system designed for the storage of flowers or candy...
A normally operating water-cooled condenser is operating with a 10° ...
An air-cooled condenser that is operating in a climate that has four...
The water circuit in shell and coil and coil-type tube-in-a-tube...
The device used to feed refrigerant to multiple circuits in an...
A direct expansion-type evaporator is also called a ____.
A forced draft medium temperature evaporator would ____.
Excess evaporator superheat ____.
When a system with a water-cooled condenser cycles off, the water...
Which of the following can be used to maintain the head pressure of a...
If a low temperature evaporator is forming ice, which of the following...
In a water-cooled condenser with dirty condenser tubes, the...
An evaporator made up of two or more pieces of sheet metal dimpled to...
Which of the following would allow a system to operate more...
Which of the following condensers is the most efficient?
SEER is calculated based on the total amount of ____ the system will...
Every central split cooling system manufactured in the USA today must...
High head pressures from low ambients can cause insufficient...
A water regulating valve helps maintain in a system's head pressure by...
A normally operating water-cooled condenser is operating with a 10° ...
In a water-cooled condenser, a regulating valve is used to control...
The heat required for off-cycle defrost is obtained from ____.
What can be used to maintain the head pressure of a system with a...
Alert!

Advertisement
