1) A triangular roof truss has a 40° pitch angle. If half the base is 5 m, what is the rise (nearest tenth)?
Submit
Please wait...
About This Quiz
Engineering Design Roof Truss Analysis - Quiz

Strong roofs start with strong trusses — and trigonometry is at the heart of their design. In this quiz, you’ll calculate angles, rises, and side lengths in triangular roof trusses. You’ll see how engineers and architects use mathematical modeling to ensure both strength and symmetry in every build. Step by... see morestep, you’ll connect geometry with real construction principles that make modern structures reliable and efficient. see less

2)
We’ll put your name on your report, certificate, and leaderboard.
2) A roof truss has two equal sides of 11 m each and a base of 14 m. What is the peak angle (nearest degree)?
Submit
3) Each side beam is 8 m long and the peak angle is 60°. What is the base length?
Submit
4) A truss has a base of 18 m and a pitch angle of 35°. What is the rise (nearest tenth)?
Submit
5) A truss has a base of 12 m and a pitch angle of 30°. Find the rise.
Submit
6) A truss has a rise of 5 m and half the base is 7 m. What is the pitch angle (nearest degree)?
Submit
7) A roof beam is 10 m long and makes a 45° angle with the base. What is the rise?
Submit
8) A truss has a base of 20 m and rise of 12 m. Find the pitch angle (nearest degree).
Submit
9) A triangular truss is isosceles with two equal sides of 15 m and base 18 m. Find the peak angle.
Submit
10) A truss with a rise of 6 m and base half of 8 m has what pitch angle?
Submit
11) A roof truss has equal sides of 9 m and a base of 10 m. What is the peak angle (nearest degree)?
Submit
12) A truss has a rise of 4 m and half the base is 6 m. Find the pitch angle.
Submit
13) If a truss has side beams 12 m and peak angle 40°, what is the base length?
Submit
14) A truss supports a roof with base 16 m and rise 8 m. What is the pitch angle?
Submit
15) A truss has a rise of 7 m and half the base is 10 m. What is the pitch angle (nearest degree)?
Submit
16) A truss has side beams of 10 m each and a base of 12 m. What is the height at the peak (nearest tenth)?
Submit
17) If the rise is 9 m and the half-base is 9 m, what is the pitch angle?
Submit
18) A truss has equal sides of 6 m and base of 6 m. What is the peak angle?
Submit
19) A truss has a base of 14 m and rise of 10 m. What is the length of the side beam?
Submit
20) If a truss has side beams of 20 m and peak angle 50°, what is the base length?
Submit
