(209) On the ESTS, on the system controller keyboard, what key(s) suspends display activity until another key is pressed?
- Esc (Escape)
- Pause (Break)
- Enter (Carriage Return)
- Ctrl, Alt, and Del (Control, Alternate, and Delete)

Mhafb CDC 2a051t Vol. 2 F-15 And F-16 Test Equipment - Quiz

About This Quiz

This quiz assesses knowledge on the ESTS, focusing on the programming and voltage range of AC and DC power supply modules, and the configuration of RF VXI assembly. It is crucial for professionals handling F-15 and F-16 test equipment in aerospace engineering.

Quiz Preview

2.

Within the GPITM GPIU, if multiple BIT failures occur for multiple CCAs and the I/F chassis bus extendor is one of the CCAs that has failed BIT, what action should be taken?
- Ignore all other CCA BIT failures until the I/F chassis bus extender CCA fail is corrected
- Start from tier A and reset each CCA one at a time and then rerun BIT after each reset
- Reload system software because multiple CCA BIT fails indicate a software problem
- Power down and back-up the test station, this will reset all CCA firmware
Correct Answer

A. Ignore all other CCA BIT failures until the I/F chassis bus extender CCA fail is corrected

Explanation

When multiple BIT failures occur for multiple CCAs within the GPITM GPIU and the I/F chassis bus extender CCA is one of the failed CCAs, the correct action is to ignore all other CCA BIT failures until the I/F chassis bus extender CCA fail is corrected. This means that the focus should be on fixing the issue with the I/F chassis bus extender CCA before addressing any other CCA failures.

Rate this question:
3.

(208) The system controller operator interface on the ESTS consists of the flat panel display, integral resistive technology touchscreen, the 101-key keyboard, and
- Sound card
- Microphone
- Video graphics adapter
- Head phones and speakers
Correct Answer

A. Video graphics adapter

Explanation

The system controller operator interface on the ESTS consists of the flat panel display, integral resistive technology touchscreen, and the 101-key keyboard. The video graphics adapter is responsible for generating and displaying the visual output on the flat panel display. It connects the display to the computer system and ensures that the graphics are rendered correctly. Therefore, the video graphics adapter is an essential component of the system controller operator interface.

Rate this question:
4.

What programmable sttributes are avaliable for the output signal from the IAIA pulse generator output CCA?
- Amplitude and offset
- Offset and transition time
- Amplitude and transition time
- Amplitude, offset, and transition time
Correct Answer

A. Amplitude, offset, and transition time

Explanation

The output signal from the IAIA pulse generator output CCA has programmable attributes such as amplitude, offset, and transition time. This means that the user can adjust the signal's amplitude (the maximum value it reaches), offset (the DC voltage added to the signal), and transition time (the time it takes for the signal to change from one level to another). These programmable attributes allow for customization and fine-tuning of the output signal to suit specific requirements or applications.

Rate this question:
5.

(203) On the ESTS, each switch module No. 1 and No. 2 (A6A3 and A6A4) consist of 211 relays. What type of relays are they?
- SPST
- SPDT
- DPST
- DPDT
Correct Answer

A. DPDT

Explanation

The switch modules No. 1 and No. 2 (A6A3 and A6A4) on the ESTS consist of 211 relays, and these relays are DPDT (Double Pole Double Throw) type.

Rate this question:
6.

(209) On the ESTS, what is used on the system controller external CD-ROM when it is not possible to open the CD-ROM drive using the Open-Close pushbutton?
- Reset power
- Remove lock nut
- Manual release lever
- Emergency eject access hole
Correct Answer

A. Emergency eject access hole

Explanation

The correct answer is "Emergency eject access hole." On the ESTS, when it is not possible to open the CD-ROM drive using the Open-Close pushbutton, the emergency eject access hole is used. This access hole allows manual ejection of the CD-ROM by inserting a small tool, such as a paperclip, into the hole and pushing it gently. This is a useful feature in case of a malfunction or power failure where the CD-ROM drive cannot be opened using the regular method.

Rate this question:
7.

(210) What does the ESTS main menu option TPS allow the operator to perform?
- ESTS system shutdown
- LRU testing
- Copy, print, and display calibration data
- Change voltage parameters and signal paths
Correct Answer

A. LRU testing

Explanation

The ESTS main menu option TPS allows the operator to perform LRU testing. This means that the operator can test the Line Replaceable Units (LRUs) in the system to ensure their functionality and identify any issues or faults. This testing is important for maintaining the overall performance and reliability of the ESTS system.

Rate this question:
8.

(211) On the ESTS, at what internal temperature does the signal analyzers VOLT/TEMP indicator light?
- 50 degress Celsius
- Between 50 and 75 degrees Celsius
- 75 degress Celsius
- When it exceeds 75 degrees Celsius.
Correct Answer

A. When it exceeds 75 degrees Celsius.

Explanation

The VOLT/TEMP indicator light on the ESTS signal analyzer lights up when the internal temperature exceeds 75 degrees Celsius.

Rate this question:
9.

(212) Which spectrum analyzer MARKER key in RF equipment assembly No. 2, places a marker at the highest point on a signal trace and accesses a menu of marker functions?
- MKR key
- --> MKR Key
- FREQ COUNT key
- PEAK SEARCH key
Correct Answer

A. PEAK SEARCH key

Explanation

The correct answer is the PEAK SEARCH key. This key in the spectrum analyzer MARKER menu allows the user to place a marker at the highest point on a signal trace and access a menu of marker functions. This function is useful for analyzing and measuring the peak levels of signals in RF equipment assembly No. 2.

Rate this question:
10.

(213) Which tier(s) of the GPIU form the interface test connector?
- A and B
- B and C
- A only
- B only
Correct Answer

A. A and B

Explanation

The GPIU form the interface test connector consists of tiers A and B. This means that both tiers A and B are involved in forming the interface test connector.

Rate this question:
11.

(214) The GPITM power-on and initiated are two of the three types of BITs. What is the third type?
- Nonstop
- Permanent
- Continuous
- Uninterrupted
Correct Answer

A. Continuous

Explanation

The third type of BIT is Continuous. The question asks for the third type of BIT, and the options provided are Nonstop, Permanent, Continuous, and Uninterrupted. Out of these options, Continuous is the only one that matches the criteria.

Rate this question:
12.

(202) On the ESTS, in what slot of the RF VXI assembly (A5) is the VXI bus extender module (A5A1) located?
- 0
- 1
- 2
- 3
Correct Answer

A. 0

Explanation

The VXI bus extender module (A5A1) is located in slot 0 of the RF VXI assembly (A5) on the ESTS.

Rate this question:
13.

(202) On the ESTS, which connector on the VXI bus extender module is a 52-pin connector?
- TRIG OUT
- EXT CLK
- TRIG IN
- MXI bus
Correct Answer

A. MXI bus

Explanation

The correct answer is MXI bus. The MXI bus is a 52-pin connector on the VXI bus extender module. It is used to connect the VXI bus extender module to other devices or modules in the VXI system. This connector allows for communication and data transfer between different components of the system.

Rate this question:
14.

(207) On the ESTS, when installing the interconnecting box A15 (maintenance ITA), the A15 mating is completed by
- Rotating the two connectors engagement handles one turn clockwise
- Installing four locking bolts and tightening them
- Securing the locking clamps on both sides
- Locking the four engagement pins
Correct Answer

A. Rotating the two connectors engagement handles one turn clockwise

Explanation

When installing the interconnecting box A15 (maintenance ITA) on the ESTS, the mating process is completed by rotating the two connectors engagement handles one turn clockwise. This action ensures a secure connection between the two connectors, allowing for proper functioning of the interconnecting box. The other options mentioned, such as installing locking bolts, tightening them, securing locking clamps, or locking engagement pins, are not mentioned as necessary steps in completing the mating process for the A15 connectors.

Rate this question:
15.

(211) On the ESTS, the RF generator No. 1 is capable of delivering what type of RF outputs(s)?
- Amplitutde only
- Amplitude and pulse modulated only
- Frequency and pulse modulated only
- Amplitude, frequency, and pulse modulated
Correct Answer

A. Amplitude, frequency, and pulse modulated

Explanation

The RF generator No. 1 on the ESTS is capable of delivering RF outputs that are amplitude, frequency, and pulse modulated. This means that it can vary the amplitude (strength), frequency (rate), and pulse modulation (on-off pattern) of the RF signal it generates.

Rate this question:
16.

If a GPITM spurious overcurrent interrupt occurs during BIT, what symbol (indicator) will be displayed by the statur indicator for the circuit card assembly being tested when the interrupt occurred?
- Dash (-)
- Zero (0)
- Percent (%)
- Asterisk (*)
Correct Answer

A. Percent (%)

Explanation

During the Built-In Test (BIT), if a GPITM (General Purpose Interrupt) spurious overcurrent interrupt occurs, the status indicator for the circuit card assembly being tested will display the symbol for percent (%).

Rate this question:
17.

The overall function of the RITM is to select and complete signal paths between the station RF automatic test equipment and what devices/component?
- UUT
- Digitizer oscilloscope
- Frequency synthesizer
- GPITM
Correct Answer

A. UUT

Explanation

The RITM's main purpose is to choose and finalize signal paths between the station RF automatic test equipment and the UUT (Unit Under Test). This means that the RITM is responsible for connecting the test equipment to the specific device or component being tested, allowing for accurate and efficient testing processes. The other options, such as the digitizer oscilloscope, frequency synthesizer, and GPITM, are not directly related to the RITM's function of selecting and completing signal paths for the UUT.

Rate this question:
18.

Which CCA of the IAIS test station computer communication with the photometer and theodolite components of the optical bench?
- Processor
- RS-232 serical interface
- Computer test station interface
- Small computer system interface
Correct Answer

A. RS-232 serical interface

Explanation

The RS-232 serial interface is responsible for facilitating the communication between the IAIS test station computer and the photometer and theodolite components of the optical bench. This interface allows for the transfer of data and commands between the computer and the components, enabling the computer to control and receive information from the photometer and theodolite.

Rate this question:
19.

When operating under manual control, the IAIS blower unit
- Overrides the general-purpose interface blower bus mode.
- Protects the unit from drawing too much current.
- Regulates air outlet temperature.
- Operates at minimum speed.
Correct Answer

A. Overrides the general-purpose interface blower bus mode.

Explanation

When operating under manual control, the IAIS blower unit overrides the general-purpose interface blower bus mode. This means that the blower unit takes control and disregards any instructions or settings from the general-purpose interface blower bus mode. It operates independently and according to its own manual control settings.

Rate this question:
20.

(202) On the ESTS, in what slots of the RF VXI assembly (A5) is the RF counter (A5A9) located?
- 1, 2, and 3
- 6, 7, and 8
- 9, 10, and 11
- 11, 12, and 13
Correct Answer

A. 9, 10, and 11

Explanation

The RF counter (A5A9) is located in slots 9, 10, and 11 of the RF VXI assembly (A5) on the ESTS.

Rate this question:
21.

(210) On the ESTS, which TPS main menu option performs a test on a specific LRU SRU?
- LOAD OFP
- READ/VERIFY OFP
- INDIVIDUAL TESTING
- END-TO-END
Correct Answer

A. INDIVIDUAL TESTING

Explanation

The correct answer is "INDIVIDUAL TESTING". This option allows the user to perform a test on a specific Line Replaceable Unit (LRU) System Replaceable Unit (SRU) on the ESTS (Electronic System Test Set). This option is useful for troubleshooting and diagnosing issues with a particular LRU SRU, allowing the user to isolate and test individual components of the system.

Rate this question:
22.

Which GPIU CCA is not one of the tier C plug in CCAs?
- 1553 CCA
- Display CCA
- Manchester CCA
- Test module adapter CCA
Correct Answer

A. Manchester CCA

Explanation

The Manchester CCA is not one of the tier C plug in CCAs.

Rate this question:
23.

Regarding tyhe RITM stimulus assembly, where is the low-band noise contained?
- Modulation assembly/modulation CCA
- Modulation assembly/noise CCA
- Noise assembly/ modulation CCA
- Noise assembly/ noise CCA
Correct Answer

A. Noise assembly/ noise CCA

Explanation

The low-band noise is contained in the Noise assembly/noise CCA.

Rate this question:
24.

What optical test bench assembly provides stimulus to the ambient light sensors of the wide-angle conventional HUD unit and diffractive optics HUD unit?
- Light source
- Digital theodolite
- Photometric adapter
- Theodolite interface
Correct Answer

A. Light source

Explanation

The correct answer is a light source. In order to test the ambient light sensors of the wide-angle conventional HUD unit and diffractive optics HUD unit, a stimulus is needed. This stimulus is provided by a light source, which emits light that can be detected by the sensors. The light source allows for the sensors to be accurately tested and calibrated, ensuring their proper functioning in the HUD units.

Rate this question:
25.

(209) On the ESTS, on the system controller external CD-ROM, what decrements the CD track selection?
- SCSI ID select switch
- Forward track pushbutton
- Back track pushbutton
- Feature selector switch
Correct Answer

A. Back track pushbutton

Explanation

The back track pushbutton on the system controller external CD-ROM decrements the CD track selection.

Rate this question:
26.

What two GPITM CCA are required to test every CCA withing the GPIU?
- Special function interface and the signal conditioner
- ICA I/F and the monitor select
- ARB waveform generator and the HDR
- TMA and the ICA A/F
Correct Answer

A. TMA and the ICA A/F

Explanation

The TMA (Test Measurement Adapter) and the ICA A/F (Interface Control Assembly Analog/Frequency) are required to test every CCA (Circuit Card Assembly) within the GPIU (Generic Processor Interface Unit). These two components provide the necessary interface and control for conducting the tests on the CCAs.

Rate this question:
27.

What assembly(s) in the RITM stimulus assembly generates noise in two band, a low band and a high band?
- Microwave counter test module
- Power amplifiers no 1 and no 2
- Frequency generators
- Noise assembly
Correct Answer

A. Noise assembly

Explanation

The correct answer is Noise assembly. The Noise assembly is responsible for generating noise in two bands, a low band and a high band. This means that it produces noise signals in both the lower frequency range and the higher frequency range. The other options, such as the Microwave counter test module, Power amplifiers no 1 and no 2, and Frequency generators, do not specifically mention generating noise in two bands.

Rate this question:
28.

(204) On the ESTS, digital word generators 5 and 6 are what type of digital word generators?
- High-density
- High-speed
- Low-density
- Low-speed
Correct Answer

A. High-density

Explanation

Digital word generators 5 and 6 on the ESTS are classified as high-density digital word generators. This means that they are capable of generating a large number of digital words in a given time period. High-density digital word generators are designed to produce a high volume of data, making them suitable for applications that require a large amount of information to be processed or transmitted quickly.

Rate this question:
29.

(206) On the ESTS, which connections on the interconnect assembly A12 (SIA3) connect to the system controller (A9)?
- P1 and P2
- P3 and P4
- J1 and J2
- P1 and J1
Correct Answer

A. J1 and J2

Explanation

The correct answer is J1 and J2.

Rate this question:
30.

(208) What kind of Pentium processor does the ESTS system controller have?
- 1 GHz
- 500 MHz
- 120 Mhz
- 90 MHz
Correct Answer

A. 90 MHz

Explanation

The ESTS system controller has a 90 MHz Pentium processor.

Rate this question:
31.

(208) On the ESTS, the SCSI card controls the magneto-optical drive, the removeable hard drive, and
- CD-ROM drive
- Floppy controller
- 3.5 inch floppy disk drive
- 64 Mb RAM
Correct Answer

A. CD-ROM drive

Explanation

The SCSI card on the ESTS controls the magneto-optical drive, the removable hard drive, and the CD-ROM drive. This means that the SCSI card is responsible for managing the communication and data transfer between the ESTS and these devices. The other options listed (floppy controller, 3.5 inch floppy disk drive, 64 Mb RAM) are not controlled by the SCSI card in this scenario.

Rate this question:
32.

(209) On the ESTS, what type of switch is used to control the configuratioin on the system controller external CD-ROM's feature selector switch?
- Dip
- Toggle
- Pushbutton
- Thumbwheel
Correct Answer

A. Dip

Explanation

The correct answer is Dip. A Dip switch, also known as a dual in-line package switch, is a type of switch that is commonly used to control the configuration settings on electronic devices. It consists of a series of tiny switches that can be set to either an on or off position. In the context of the ESTS system controller external CD-ROM's feature selector switch, a Dip switch would be used to control the configuration settings of the switch.

Rate this question:
33.

(210) On the ESTS, which F-15 TPS selection menu option is the best method if you only know the name (nomenclature) of the LRU you are about to bench check?
- Alphabetical index listing
- LRU work unit code
- TPS list number
- List scrolling
Correct Answer

A. List scrolling

Explanation

List scrolling is the best method on the ESTS if you only know the name (nomenclature) of the LRU you are about to bench check. This option allows you to scroll through a list of LRUs to find the specific one you are looking for. It is a convenient and efficient way to locate the LRU without having to know its work unit code or TPS list number. The alphabetical index listing may not be as efficient if you do not know the exact alphabetical order of the LRU's name. The LRU work unit code and TPS list number options require prior knowledge of the specific codes or numbers assigned to the LRUs.

Rate this question:
34.

Regarding the fifth IF assembly that is part of the RITMs measurement assembly, the fifth IF frequency is produced by heterodyning on of four LO frequencies with what else that is supplied by the test station?
- Third IF
- Fourth IF
- 10 MHz clock channel
- 100 MHz clock channel
Correct Answer

A. Fourth IF

Explanation

The correct answer is the 100 MHz clock channel.

Rate this question:
35.

On the IAIS general-purpose switch CCA, operational control signals for relays K26 through K30 come from the UUT
- Only
- Or the computer
- The computer, or the modular relay driver
- Or a combination of the station computer and modular relay driver
Correct Answer

A. Or the computer

Explanation

The operational control signals for relays K26 through K30 on the IAIS general-purpose switch CCA can come from either the computer, the modular relay driver, or a combination of both the station computer and modular relay driver.

Rate this question:
36.

What IAIS IUB CCA provides the video and synchronization signals used to display raster patterns on the UUT?
- Timing generator
- Discrete I/O
- Raster video generator "A"
- Synchro generator/measurement
Correct Answer

A. Raster video generator "A"

Explanation

The correct answer is Raster video generator "A". The IAIS IUB CCA provides the video and synchronization signals used to display raster patterns on the UUT. The raster video generator "A" is responsible for generating these signals, which are necessary for displaying the raster patterns accurately on the UUT.

Rate this question:
37.

(202) On the ESTS, what type of power meter is power meter (A5A8)?
- Dual input
- Dual output
- Single input
- Single output
Correct Answer

A. Dual input

Explanation

The correct answer is "Dual input" because power meter (A5A8) on the ESTS has two input ports, allowing it to measure power from two different sources simultaneously.

Rate this question:
38.

(204) On the ESTS, digital word generators 1, 2, and 3 are what type of digital word generators?
- High-density
- High-speed
- Low-density
- Low-speed
Correct Answer

A. High-speed

Explanation

The digital word generators 1, 2, and 3 on the ESTS are classified as high-speed digital word generators.

Rate this question:
39.

(205) What are the power requirements for ESTS operation?
- 220 VAC single-phase
- 115 VAC single-phase
- 220 VAC 3-phase
- 115 VAC 3-phase
Correct Answer

A. 115 VAC single-phase

Explanation

The power requirements for ESTS operation are 115 VAC single-phase.

Rate this question:
40.

(210) Which ESTS main menu optioin provides ESTS configuration/status?
- TPS (debug mode)
- Resource management
- System services
- Shutdown
Correct Answer

A. Resource management

Explanation

The correct answer is Resource management. This option in the ESTS main menu allows users to configure and check the status of the ESTS system. This includes managing resources such as memory, disk space, and network connections. It provides a way to monitor and control the overall performance and functionality of the ESTS system.

Rate this question:
41.

How are the FREQ adjustments made to the IAIS 10- MHz standard?
- BFREQ adjustments cannot be made to the 10-MHz standard; instead, its oscillator assembly must be replaced if it is out of tolerance
- By adjusting the output of the 10-MHz oscillator on the trigger selector CCA
- By adjusting the output of the FREQ input select circuit on the advanced counter/timer CCA
- By adjusting the on-board trim potentiometer
Correct Answer

A. By adjusting the on-board trim potentiometer

Explanation

The correct answer is by adjusting the on-board trim potentiometer. This means that the FREQ adjustments for the IAIS 10-MHz standard can be made by adjusting the trim potentiometer that is located on the board. This allows for fine-tuning the frequency output of the standard without the need to replace the entire oscillator assembly if it is out of tolerance.

Rate this question:
42.

When viewed from the optical bench's digital theodolite,what established the optical reference?
- 2-inch mirror
- 4- inch mirror
- Precision gimbal
- Calibration fixture assembly
Correct Answer

A. Calibration fixture assembly

Explanation

The calibration fixture assembly is the component that establishes the optical reference when viewed from the digital theodolite on the optical bench. It is likely that the calibration fixture assembly is designed to provide a stable and accurate reference point for the theodolite measurements. The 2-inch mirror, 4-inch mirror, and precision gimbal may be other components of the optical bench, but they do not specifically establish the optical reference as mentioned in the question.

Rate this question:
43.

(206) On the ESTS, which connector(s) of the interconnect assembly A10 (SIA1) connects to power distribution internconnections?
- P1 only
- P1 and P2 only
- P1, P2, and P3 only
- P1, P2, P3, and P4
Correct Answer

A. P1, P2, P3, and P4

Explanation

The interconnect assembly A10 (SIA1) connects to power distribution internconnections through connectors P1, P2, P3, and P4.

Rate this question:
44.

Regarding the RF assemblies of the RITM measurement assembly, which of the LO signals is supplied by the station spectrum analyzer and varies from 10.5 to 18.5 GHz?
- TLO
- SLO
- VLO
- BIT LO
Correct Answer

A. SLO

Explanation

The LO signal supplied by the station spectrum analyzer and varies from 10.5 to 18.5 GHz is the SLO.

Rate this question:
45.

(201) On the ESTS, what voltage programming range do the AC power supply modules provide?
- 0 to 135 VDC
- 0 to 135 VAC
- 135 to 220 VDC
- 135 to 220 VAC
Correct Answer

A. 0 to 135 VAC

Explanation

The AC power supply modules on the ESTS provide a voltage programming range of 0 to 135 VAC. This means that the modules can be adjusted to output any voltage within this range, allowing for flexibility and customization in power supply.

Rate this question:
46.

The programmable output range of the variable DC power supply on the optical test bench is
- 0 to +5VDC; 0.8 amp
- 0 to +10 VDC; 1.2 amp
- 0 to +18VDC; 1.6 amp
- 0 to +24 VDC; 2.0 amp
Correct Answer

A. 0 to +18VDC; 1.6 amp

Explanation

The correct answer is 0 to +18VDC; 1.6 amp. This means that the variable DC power supply on the optical test bench can provide a range of voltage output from 0 to +18VDC and a maximum current output of 1.6 amp. This range allows for flexibility in powering different devices or components on the test bench, while ensuring that the current does not exceed 1.6 amp to prevent damage.

Rate this question:
47.

Which RITM assembly performs down conversion for the RF in the 18 to 40 GHZ band, input demodulation, and measurement?
- Power
- Control
- Stimulus
- Measurement
Correct Answer

A. Measurement

Explanation

The RITM assembly that performs down conversion for the RF in the 18 to 40 GHz band, input demodulation, and measurement is the Measurement assembly.

Rate this question:
48.

Within the RITM stimulus assembly what devise/assembly provides the required termination for the front panel connectors?
- Noise assembly
- Power amplifiers
- Modulation assembly
- Stimulus distribution assembly
Correct Answer

A. Stimulus distribution assembly

Explanation

The stimulus distribution assembly provides the required termination for the front panel connectors in the RITM stimulus assembly. This assembly is responsible for distributing the stimulus signals to the appropriate connectors and ensuring proper termination to prevent signal loss or interference. It acts as a central hub for connecting various devices and components in the assembly, allowing for efficient and effective distribution of stimuli.

Rate this question:
49.

Within the RITM stimulus assembly, what devise/assembly provides comparators to test all output paths of the stimulus assembly during BITs?
- Stimulus distribution assembly
- Modulation assembly
- Power amplifiers
- Noise assembly
Correct Answer

A. Stimulus distribution assembly

Explanation

The stimulus distribution assembly provides comparators to test all output paths of the stimulus assembly during BITs. This suggests that the stimulus distribution assembly is responsible for distributing the stimulus signals to different paths and comparing the output signals from each path to the expected values. This ensures that all output paths are functioning correctly and helps identify any faults or errors in the stimulus assembly.

Rate this question:

Quiz Review Timeline (Updated): Mar 21, 2023 +

Our quizzes are rigorously reviewed, monitored and continuously updated by our expert board to maintain accuracy, relevance, and timeliness.

Current Version
Mar 21, 2023

Quiz Edited by
ProProfs Editorial Team
Aug 10, 2010

Quiz Created by
F15 Ais Training

Back to top

Mhafb CDC 2a051t Vol. 2 F-15 And F-16 Test Equipment

(209) On the ESTS, on the system controller keyboard, what key(s) suspends display activity until another key is pressed?

Quiz Preview

Within the GPITM GPIU, if multiple BIT failures occur for multiple CCAs and the I/F chassis bus extendor is one of the CCAs that has failed BIT, what action should be taken?

(208) The system controller operator interface on the ESTS consists of the flat panel display, integral resistive technology touchscreen, the 101-key keyboard, and

What programmable sttributes are avaliable for the output signal from the IAIA pulse generator output CCA?

(203) On the ESTS, each switch module No. 1 and No. 2 (A6A3 and A6A4) consist of 211 relays. What type of relays are they?

(209) On the ESTS, what is used on the system controller external CD-ROM when it is not possible to open the CD-ROM drive using the Open-Close pushbutton?

(210) What does the ESTS main menu option TPS allow the operator to perform?

(211) On the ESTS, at what internal temperature does the signal analyzers VOLT/TEMP indicator light?

(212) Which spectrum analyzer MARKER key in RF equipment assembly No. 2, places a marker at the highest point on a signal trace and accesses a menu of marker functions?

(213) Which tier(s) of the GPIU form the interface test connector?

(214) The GPITM power-on and initiated are two of the three types of BITs. What is the third type?

(202) On the ESTS, in what slot of the RF VXI assembly (A5) is the VXI bus extender module (A5A1) located?

(202) On the ESTS, which connector on the VXI bus extender module is a 52-pin connector?

(207) On the ESTS, when installing the interconnecting box A15 (maintenance ITA), the A15 mating is completed by

(211) On the ESTS, the RF generator No. 1 is capable of delivering what type of RF outputs(s)?

If a GPITM spurious overcurrent interrupt occurs during BIT, what symbol (indicator) will be displayed by the statur indicator for the circuit card assembly being tested when the interrupt occurred?

The overall function of the RITM is to select and complete signal paths between the station RF automatic test equipment and what devices/component?

Which CCA of the IAIS test station computer communication with the photometer and theodolite components of the optical bench?

When operating under manual control, the IAIS blower unit

(202) On the ESTS, in what slots of the RF VXI assembly (A5) is the RF counter (A5A9) located?

(210) On the ESTS, which TPS main menu option performs a test on a specific LRU SRU?

Which GPIU CCA is not one of the tier C plug in CCAs?

Regarding tyhe RITM stimulus assembly, where is the low-band noise contained?

What optical test bench assembly provides stimulus to the ambient light sensors of the wide-angle conventional HUD unit and diffractive optics HUD unit?

(209) On the ESTS, on the system controller external CD-ROM, what decrements the CD track selection?

What two GPITM CCA are required to test every CCA withing the GPIU?

What assembly(s) in the RITM stimulus assembly generates noise in two band, a low band and a high band?

(204) On the ESTS, digital word generators 5 and 6 are what type of digital word generators?

(206) On the ESTS, which connections on the interconnect assembly A12 (SIA3) connect to the system controller (A9)?

(208) What kind of Pentium processor does the ESTS system controller have?

(208) On the ESTS, the SCSI card controls the magneto-optical drive, the removeable hard drive, and

(209) On the ESTS, what type of switch is used to control the configuratioin on the system controller external CD-ROM's feature selector switch?

(210) On the ESTS, which F-15 TPS selection menu option is the best method if you only know the name (nomenclature) of the LRU you are about to bench check?

Regarding the fifth IF assembly that is part of the RITMs measurement assembly, the fifth IF frequency is produced by heterodyning on of four LO frequencies with what else that is supplied by the test station?

On the IAIS general-purpose switch CCA, operational control signals for relays K26 through K30 come from the UUT

What IAIS IUB CCA provides the video and synchronization signals used to display raster patterns on the UUT?

(202) On the ESTS, what type of power meter is power meter (A5A8)?

(204) On the ESTS, digital word generators 1, 2, and 3 are what type of digital word generators?

(205) What are the power requirements for ESTS operation?

(210) Which ESTS main menu optioin provides ESTS configuration/status?

How are the FREQ adjustments made to the IAIS 10- MHz standard?

When viewed from the optical bench's digital theodolite,what established the optical reference?

(206) On the ESTS, which connector(s) of the interconnect assembly A10 (SIA1) connects to power distribution internconnections?

Regarding the RF assemblies of the RITM measurement assembly, which of the LO signals is supplied by the station spectrum analyzer and varies from 10.5 to 18.5 GHz?

(201) On the ESTS, what voltage programming range do the AC power supply modules provide?

The programmable output range of the variable DC power supply on the optical test bench is

Which RITM assembly performs down conversion for the RF in the 18 to 40 GHZ band, input demodulation, and measurement?

Within the RITM stimulus assembly what devise/assembly provides the required termination for the front panel connectors?

Within the RITM stimulus assembly, what devise/assembly provides comparators to test all output paths of the stimulus assembly during BITs?
